Print Server Installation Guide
For EPS2-100 and EPS4-100 Fast Ethernet Print Servers
Part Number 900-190
Rev. C 1/08

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EPS4-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lantronix EPS4-100

Summary of Contents for Lantronix EPS4-100

  • Page 1 Print Server Installation Guide For EPS2-100 and EPS4-100 Fast Ethernet Print Servers Part Number 900-190 Rev. C 1/08...
  • Page 2 ©2002, 2007 Lantronix. All rights reserved. No part of the contents of this book may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Printed in the United States of America. Ethernet is a trademark of XEROX Corporation. UNIX is a registered trademark of The Open Group. Windows 95, Windows 98, Windows 2000, and Windows NT are trademarks of Microsoft Corp.

  • Page 3: Table Of Contents

    Contents Print Server Installation Guide Introduction Installation Getting Started TCP/IP Configuration NetWare Configuration LAT Configuration AppleTalk Configuration LAN Manager/DLC Configuration Contact Information Troubleshooting Pinouts Updating Software Specifications Frequently-used Commands Warranty Statement...
  • Page 4 Declaration of Conformity Index...

  • Page 5: Introduction

    NOTE: In this manual, both the EPS2-100 and the EPS4-100 servers will be referred to as the EPS or as the Server unless a distinction needs to be made between the models.

  • Page 6: Getting Started

    Introduction 1.1 How to Use This Manual This guide is structured as follows: Chapter 2, Installation, explains how to physically install the Server. Chapter 3, Getting Started, explains the minimum configuration needed to operate the Server. Chapters 4 through 8 cover protocol-specific setup needed to install print queues and otherwise use the Server.

  • Page 7: Installation

    2.1 Product Description The front panel of the EPS has two RJ45 ports and either two DB25 ports (EPS2-100) or 4 DB25 ports (EPS4-100). The back panel of the EPS has one 10/100BASE-T port, a Test/Reset button, and a power plug.
  • Page 8 Installation The EPS has 7 LEDs on the top panel Figure 2-2: EPS LED Location LEDs LED functionality is explained in Table 2-1. 2 - 2...
  • Page 9 Installation Table 2-1: LED Functionality Function During Normal Operation SERIAL Blinks yellow to indicate serial port activity. PARALLEL Blinks yellow to indicate parallel port activity. NETWORK Blinks yellow to indicate Ethernet activity. Lights green (blinks occasionally) to indicate the unit is functioning properly. GOOD LINK Lights solid green to indicate a working Ethernet connection (either 10BASE-T or 100BASE-T).
  • Page 10 Installation 2.2 Installation The following diagram shows a properly-installed EPS. To install the server, complete the following steps in order. Refer to the numbers in the figure for help. 2 - 4...
  • Page 11 Installation Connect at least one printer to the EPS using an available serial or parallel port. If desired, connect a terminal to port 1 (the console port) to receive diagnostic and initial configuration messages. Connect the EPS to the 10/100BASE-T network. NOTE: The default serial port settings are 9600 baud, 8 bit characters, and no parity.

  • Page 13: Getting Started

    Getting Started 3 - Getting Started It is important to consider the following points before logging into and configuring the EPS: The EPS IP address must be configured before any TCP/IP functionality is available. (See Setting the IP Address on page 4-2.) There are two important passwords on the EPS: the privileged password and the login password.
  • Page 14 Your Server must have an IP address before EZWebCon can log into it for configura- tion purposes. See Setting the IP Address on page 4-2 for instructions. EZWebCon requires a Java Virtual Machine (JVM) on the client. Lantronix provides JVM installers for Solaris and 32-bit Windows users, as well as source code and instructions for compiling it for use on other systems.
  • Page 15 With few exceptions, a service must be created before print queues can be configured on the EPS. A service is a resource accessible to network hosts. A Lantronix service is also known as a remote printer name or remote queue name on many operating systems.
  • Page 16 Getting Started The default services on the serial ports have the TCP/IP, NetWare, LAN Manager, and AppleTalk protocols enabled. Parallel port services have TCP/IP, NetWare, and LAN Manager enabled. LAT is disabled by default on all services provided by the Server because many network managers object to the frequent LAT service announcements.

  • Page 17: Tcp/Ip Configuration

    Neither Windows for Workgroups nor Windows 95 support LPR directly; however, there are third party solutions available. For more information about recommended peer-to-peer printing solutions, see the Lantronix Windows 95 FAQ on the CD-ROM or the Lantronix web site. 4 - 1...

  • Page 18: Setting The Ip Address

    Start EZWebCon. Instructions for installing, running, and using EZWebCon can be found on the distribution CD-ROM. Click on the Lantronix logo menu in the bottom left corner of the EZWebCon window, then select Assign IP Address to Server. Fill in the following information: A.
  • Page 19 TCP/IP Configuration D. The IP address of the TFTP server you wish to use, if desired. Click OK. Cycle power on the server. EZWebCon will let you know whether the configuration was successful. 4.1.2 Using a Directed Ping Packet The ARP/ping method is available under UNIX, Windows 95, and Windows NT. If the EPS has no IP address, it will set its address from the first directed IP packet it receives.
  • Page 20 TCP/IP Configuration In order for the ARP command to work on Windows, the ARP table on the PC must have at least one IP address defined other than its own. If the ARP table is empty, the command will return an error message.
  • Page 21 Telnet into the EPS. Once logged in, the administrator can enter the Change IPaddress command to make the address permanent. % telnet 192.0.1.228 Trying 192.0.1.228 Lantronix Version n.n/n (yymmdd) Type Help at the ‘Local_>’ prompt for assistance. Enter Username> gopher Local> SET PRIVILEGED Password>...
  • Page 22 TCP/IP Configuration 4.1.3 Using a DHCP, BOOTP, or RARP Reply At boot time a host-based DHCP, BOOTP, or RARP server can respond to an EPS request for an available IP address. For information about configuring the DHCP, BOOTP, or RARP server, see your host documentation.
  • Page 23 TCP/IP Configuration 4.2 Notes About LPR There are four important things to note about the LPR printing method: Because of the way the LPR protocol is typically implemented on the host, the processing options and banner page are sent after the job data itself. The EPS will print a banner page at the end of a job, and cannot support most of the LPR options.
  • Page 24 TCP/IP Configuration 4.3 LPR on Windows NT 4.x NOTE: This installation assumes that TCP/IP, Simple TCP/IP, and Microsoft TCP/IP printing have been installed on the Windows NT host. In the Control Panel, double-click the Printers icon. Double-click the Add Printer icon. In the window that appears, choose My computer and click Next.
  • Page 25 TCP/IP Configuration Select the Add Port button and click Next. 4 - 9...
  • Page 26 TCP/IP Configuration Select LPR Port. NOTE: If LPR Port is not an option, refer to your Windows NT documentation for instructions on installing the Microsoft TCP/IP Printing service. Enter the name or IP address of your EPS on the first line, and enter the name of your EPS print service on the second line.
  • Page 27 TCP/IP Configuration Select the manufacturer and printer type. 4 - 11...
  • Page 28 TCP/IP Configuration Enter the queue name. 4 - 12...
  • Page 29 TCP/IP Configuration If applicable, choose Shared and select the type of operating system that the printer will be working with. (First confirm that the print queue is working.) 4 - 13...
  • Page 30 TCP/IP Configuration 10. Test the printer. 4 - 14...
  • Page 31 TCP/IP Configuration 4.4 LPR on UNIX Hosts The Berkeley remote printing system is supported on many machines, and is simple to configure. This section describes how to configure LPR print queues on generic UNIX hosts such as SUN hosts. There are slight variations in LPR configuration for AIX, HP, and SCO hosts, as will be explained in the following sections.
  • Page 32 TCP/IP Configuration This will create a host queue named eps_prt. The rm parameter is the name of the EPS in the host's address file, the rp parameter is the name of the service as it exists on the EPS, and the sd parameter specifies the name of a directory used to hold temporary spooling files. Create a world-writable spooling directory using the mkdir command.
  • Page 33 TCP/IP Configuration To create a print queue: At the host prompt type smit. Choose Print Spooling. Choose Manage Print Server and Start the Print Server Subsystem (lpd daemon). In the Start the Print Server Subsystem dialog box, type both in the first field. The message The lpd subsystem has been started will appear.
  • Page 34 TCP/IP Configuration The name of the EPS unit, The name of the EPS service, The type of print spooler on the remote server, and A description of the printer on the remote server. A dialog box will appear with the message Added print queue eps_prt. NOTE: If you are unable to use SMIT, see the Print Server Reference Manual for UNIX commands for setting up print queues.
  • Page 35 TCP/IP Configuration 4.4.2 LPR on HP Hosts The System Administration Manager (SAM) allows you to create print queues. NOTE: If you are unable to use SAM, the Print Server Reference Manual located on the CD-ROM described UNIX commands that can be used to set up print queues.
  • Page 36 TCP/IP Configuration 4.4.3 LPR on SCO UNIX Hosts LPR is supported in SCO V3.2 release 4 with TCP/IP Version 1.2 and greater. To configure a print queue using LPR: Issue the mkdev rlp command. This will install the Berkeley remote printing files and exe- cutable programs.
  • Page 37 TCP/IP Configuration Remote Printing Configuration Enter information for remote printers or local printers accepting remote printing requests Please enter the printer name (q to quit): backupprinter Is printer backupprinter a remote printer or a local printer? (r/l) r Please enter the name of the remote host that backupprinter is attached to: EPS_xxxxxx The backupprinter is connected to host EPS_xxxxxx.
  • Page 38 If the LPR method of printing is not adequate for an application (for example, if you need banners before jobs, or more flexibility), configure the Lantronix-supplied RTEL software on the host. After installing the software configuring the connections to the EPS, you can use normal UNIX print commands and queue utilities such as lpc and lpstat.
  • Page 39 TCP/IP Configuration See the README files in the created directories that describe the contents of the RTEL distribution and man pages that describe the actual software functionality. 4.6 Unix Host Troubleshooting Table 4-1: TCP Troubleshooting Area to Check Explanation The Server IP address and name are Telnet to the Server using the name in the host file and entered in the host file verify that the Server name is resolvable and that the Server...

  • Page 41: Netware Configuration

    NetWare Configuration 5 - NetWare Configuration The EZWebCon configuration software is the easiest way to configure the EPS. The following sections cover print configuration methods for NetWare hosts. NOTE: The Server needs an IP address before you can use EZWebCon. See the Setting the IP Address section on page 4-2 for instructions.
  • Page 42 If you wish to create NDS print queues, you must read and complete an NDS registration form via one of the following methods: Using a forms-capable Internet browser, navigate to the Lantronix World Wide Web site (located at URL http://www.lantronix.com) and find the NDS Registration link.
  • Page 43 NetWare Configuration tree, see your host documentation. Define the directory service context in which the Server is located. Local>> DEFINE PROTOCOL NETWARE DSCONTEXT ou=kiwi.ou=exotic.o=fruit Enter the List Protocol NetWare Access command to ensure that at least one of the file servers in the directory service tree is in the access list.
  • Page 44 In the Directory Tree windows, select the context in which to install the printer. From the Menu Bar, select Tools: Print Services Quick Setup. In the Print Server Name field, enter the name of your Lantronix server (viewable by entering the Show Server command at the Local> prompt).
  • Page 45 NetWare Configuration 5.3 Creating NDS Print Queues Using PCONSOLE Log in as Admin on the file server you will be changing. Type PCONSOLE at the X: prompt to start the utility. For example, if your file server is mapped to the F: drive, you would use the F: prompt. From the main menu choose Quick Set-Up.

  • Page 46: Netware Host Troubleshooting

    NetWare Configuration 5.4 NetWare Host Troubleshooting Table 5-1: NetWare Host Troubleshooting (Bindery Mode) Area to Check Explanation The server and queue names in Use PCONSOLE to check. PCONSOLE match the print server name and its service name? The Server’s NetWare access table Use the Show Protocols NetWare Access command.
  • Page 47 NetWare Configuration Table 5-2: NetWare Host Troubleshooting (NDS), cont. Area to Check Explanation The print server has successfully Type NETSTAT at the Local> prompt. This will display attached to the queue information about fileservers, printers, and queues that the print server has found. If a queue is in JobPoll, the print server has successfully attached to the queue.
  • Page 48 NetWare Configuration Table 5-3: NDS Errors from the File Server Failure code Failure code meaning Remedy 0xfffffda7 Object could not be found in the Check the print server name, DScontext, and DStree to given context make sure that the printer server is set up correctly with PCONSOLE.
  • Page 49 NetWare access list. 2, 3 Unexpected response from Report the problem to Lantronix Technical Support. file server No printers found for the Ensure that there are printers for the print server, and the printer names Server match the service names on the print server.

  • Page 51: Lat Configuration

    NOTE: The Server needs an IP address before you can use EZWebCon. See the Setting the IP Address section on page 4-2 for instructions. NOTE: To use LAT you must obtain a LAT license from your dealer or Lantronix and use the Set/Define Protocol LAT License command on your EPS.
  • Page 52 LAT Configuration 6.1 Printing Directly to a Port Create a LAT application port that references the Server port. $ RUN SYS$SYSTEM:LATCP LATCP> CREATE PORT LTAnnn/APPLICATION LATCP> SET PORT LTAnnn/NODE=EPS_xxxxxx/PORT=Port_n LATCP> EXIT Create and start a print queue that uses the LAT application port. $ INITIALIZE/QUEUE/START/ON=LTAnnn:/PROCESSOR=LATSYM /RETAIN=ERROR queue_name Add the commands to the SYS$MANAGER:LAT$STARTUP.COM file so the required...
  • Page 53 LAT Configuration Print to the queue. $ PRINT/QUEUE=queue_name filename.txt 6.1.1 LAT Host Troubleshooting By default, the LAT error message codes on the host are not translated into text error messages. If a LAT job fails and appears in the queue with an eight-digit hex result code, the code can be translated by issuing the following commands: $ SHOW QUEUE/FULL/ALL queue_name (note the error code nnnnnnnn)
  • Page 54 Table 6-1: Troubleshooting LAT Configurations Using a Port Area to check Explanation The specified node name matches the Server’s Use the Show Server command. node name The specified port name matches the port’s name Use the List Port 1 command.

  • Page 55: Appletalk Configuration

    AppleTalk Configuration 7 - AppleTalk Configuration The EZWebCon configuration software is the easiest way to configure the EPS. The following sections cover print configuration methods for AppleTalk hosts. NOTE: The Server needs an IP address before you can use EZWebCon. See the Setting the IP Address section on page 4-2 for instructions.
  • Page 56 AppleTalk Configuration 7.2 Macintosh Services Before attempting to print from a Macintosh, ensure that AppleTalk and PostScript are both enabled on at least one service. Once the service is configured, it will appear in the Chooser in the same zone as the EPS. Select the service in the Chooser and complete the appropriate setup options.
  • Page 57 AppleTalk Configuration 7.3.1 AppleTalk Host Troubleshooting Table 7-1: AppleTalk Host Troubleshooting Area to Check Explanation The printer is available to be selected in Make sure the printer is in the right zone. the Chooser Bidirectional communication Lock the printer in PostScript mode and issue the Test Service PostScript Count n command.

  • Page 59: Lan Manager/Dlc Configuration

    LAN Manager/DLC Configuration 8 - LAN Manager/DLC Configuration The EZWebCon configuration software is the easiest way to configure the EPS. This chapter explains DLC configuration for Windows NT 4.x hosts. Windows 95 does not support DLC printing (see Chapter 4, TCP/IP Configuration, for more information). NOTE: The Server needs an IP address before you can use EZWebCon.
  • Page 60 LAN Manager/DLC Configuration Double-click the Printers icon in the Control Panel. Double-click the Add Printer icon. In the window that appears select My Computer and click Next. Select the Add Port button. Select Hewlett-Packard Network Port and click New Port. If Hewlett-Packard port is not one of the available options, you must install DLC printing from your Windows NT system disks.

  • Page 61: Contact Information

    Technical Support Europe, Middle East, Africa Phone: +33 1 39 30 41 72 Email: eu_techsupp@lantronix.com or eu_support@lantronix.com When you report a problem, please provide the following information: Your name, and your company name, address, and phone number Lantronix model number...
  • Page 62 Status of the unit when the problem occurred (please try to include information on user and network activity at the time of the problem) A.2 Sales Offices For a list of our domestic and international sales offices, go to the Lantronix web site at www.lantronix.com/about/contact. A - 2...

  • Page 63: Troubleshooting

    Power-up diagnostic failure (hardware fail- Note which LED is blinking and its color, then contact your ure) dealer or Lantronix Technical Support. The Server boots but does not try to load the Press the Test button. A brief description of the problem will Flash ROM code be queued to the parallel port and printed.
  • Page 64 Troubleshooting I.2 Printing Problems Table I-2: General Printing Problems Area to Check Explanation Physical connection To test a non-PostScript printer use the Test Port 1 Count 100 command. This command will send 100 lines of test data out the parallel port. Service characteristics Use the Show Service Local Characteristics command from the Server’s Local>...
  • Page 65 Troubleshooting I.3 BOOTP Troubleshooting If the BOOTP request is failing and you have configured your host to respond to the request, check these areas: Table I-3: BOOTP Troubleshooting Area to Check Explanation BOOTP is in your system’s BOOTP must be an uncommented line in the /etc/services file. /etc/services file The Server is in the loadhost’s The Server must be in this file for the host to answer a BOOTP or...
  • Page 66 Troubleshooting I.4 DHCP Troubleshooting Table I-4: DHCP Troubleshooting Area to Check Explanation DHCP is enabled on the Server. Use the Define Server DHCP Enabled command. If you manually enter an IP address, DHCP is automatically disabled. Make sure the DHCP server is opera- Check to see that the DHCP server is on and is functioning tional.
  • Page 67 Troubleshooting I.5 RARP Troubleshooting Table I-5: RARP Troubleshooting Area to Check Explanation The Server’s name and hardware address The Server’s name and hardware address must be in this file in the host’s /etc/ethers file for the host to answer a RARP request. The Server’s name and IP address in the / The Server’s name and IP address must be in this file for the etc/hosts file...
  • Page 68 Troubleshooting I.6 PostScript Problems PostScript printers will silently abort jobs if they detect an error. Table I-6: PostScript Troubleshooting Area to Check Explanation The Server is communicating To test a PostScript printer use the Test Port 1 PostScript Count 2. with the printer This command will send 2 pages of PostScript data out the parallel port.
  • Page 69 Troubleshooting Table I-6: PostScript Troubleshooting, cont. Area to Check Explanation Port Counters If PostScript jobs appear to print but nothing comes out of the printer, verify the amount of data sent from the host. Issue the appropriate print command from the host system. After the job has completed, use the Show Port 1 Counters command.

  • Page 71: Pinouts

    J.2 Serial Information Lantronix servers are RS-423 compliant, and are thus limited by the equipment at the remote end of the serial line. If the Server is connected to an RS-232 device, it is subject to RS-232 limits: 15m (50 ft.) in length at 9600 baud, and to 2m (6 ft.) at 115.2K baud, although they will generally...
  • Page 72 Pinouts Figure J-1: Pinout of RJ45 Serial Ports J.2.1 RJ45 to DB25 If you are connecting an RJ45 port to a DTE device (such as a terminal) that has a DB25 connector, you will need to use an RJ45-DTE DB25 adapter. To connect an RJ45 port to a DB25 connector on a DCE device, you will need an RJ45-DCE DB25 adapter.
  • Page 73 Pinouts Figure J-2: Pinouts of RJ45-DB25 Connections The arrows in Figure J-2 represent the direction of the signal. The pinouts assume that the 8- conductor cable connecting the Server and the adapter block is a swapped cable. Both the transmit and receive ground signals on the Server connector are wired to the signal ground on a DB25 adapter.
  • Page 74 Pinouts A crimper block can be used to connect both transmit and receive grounds from the RJ45 cable to the single signal ground on the DB25. The connector internally splices the two wires together and provides one wire into the DB25 connector as shown below: Figure J-3: Wire Splicer Sealed at this end RJ45 Tx Return...
  • Page 75 Pinouts J.2.2 RJ45 to DB9 Figure J-4: RJ45-DTE DB9 Adapter J - 5...
  • Page 76 Pinouts The arrows in Figure J-4 represent the direction of the signal. The pinouts assume that the 8- conductor cable connecting the Server and the adapter block is a swapped cable. Both the transmit and receive ground signals on the Server connector are wired to the signal ground on a DB9 adapter.

  • Page 77: Updating Software

    Current software files are available on the distribution CD. Software updates and release notes for the Server can be downloaded directly from the Lantronix development systems in one of three ways: via the Lantronix World Wide Web site located at http://www.lantronix.com, using anonymous FTP through the Internet, and via dial-up modem.
  • Page 78 Updating Software K.2 Updating Using FTP The server software resides on the Lantronix FTP server (ftp.lantronix.com). Most of these files are binary data, so the binary option must be used to transfer the files. All released files are in the pub directory.
  • Page 79 K.3 Updating Using the BBS The Lantronix system uses high speed modems for the physical connection and allows file transfers using KERMIT, xmodem, ymodem, and zmodem. The modem phone number is (949) 367-1051. The account name is ets and the password is server.
  • Page 80 Last login: Mon Jun 5 13:21:13 from company.com SunOS Release 4.1.3_U1 (NEXUS) #2: Fri Dec 2 10:08:39 PST 1997 Welcome to the Lantronix BBS. Type ‘h’ for help userid (‘new’ for new user): new Welcome, new user! Enter a userid, 1-12 characters, no spaces.
  • Page 81 Updating Software Welcome to the "NEW" Lantronix Bulletin Board System. To access the files menu, type ‘f’ at the main menu. At the files menu, type ‘p’ to select a download protocol (a=ascii, k=kermit, x=xmodem, y=ymodem, z=zmodem) At the files menu, type ‘l’ to list available software directories.
  • Page 82 Updating Software Define commands must be used because Set configurations are cleared when the Server boots. Use the List Server Boot command to check set- tings before rebooting. NOTE: It is very important to check the Server settings before using the Initialize Reload command to ensure that you are reloading the correct software file.
  • Page 83 Updating Software K.4.2 NetWare The EPS.SYS file should be placed in the login directory on the NetWare file server. The Server cannot actually log into the file server (since it knows no username/password); it can only access files in the login directory itself. On the Server, specify the file server name, filename, and path. Local>...
  • Page 84 Updating Software hardware address, and download path and filename to the appropriate host file (usually /etc/ bootptab). Some BOOTP and TFTP implementations require a specific directory for the EPS.SYS file; in this case the path should not be specified in the bootptab file and the file must be placed in that directory.
  • Page 85 Updating Software The path and filename are case-sensitive and must be enclosed by quotation marks. When attempting to boot across an IP router, you must configure the router to proxy-ARP for the Server, or use the bootgateway feature. For more information, see Set/Define Bootgateway in the Commands chapter of the Print Server Reference Manual on CD-ROM.
  • Page 86 Updating Software K.5 Troubleshooting Flash ROM Updates Many of the problems that occur when updating the Flash ROM can be solved by completing the following steps: Table K-1: Flash ROM Troubleshooting Protocol Area to Check NetWare Ensure the file is in the login directory. Since the Server cannot actually log into the file server, it has very limited access to the server directories.
  • Page 87 Updating Software Table K-1: Flash ROM Troubleshooting, cont. Protocol Area to Check The Ethernet circuit must have the service characteristic enabled. Ensure that the MOM$LOAD search path includes the directory contain- ing the EPS.SYS file. Ensure that the files were transferred in Binary mode K - 11...
  • Page 88 Updating Software K - 12...

  • Page 89: Specifications

    Specifications L - Specifications L.1 Power Requirements Voltage: 95 - 250 Volts AC, 3-wire single phase, autoranging Frequency: 47-63 Hz Operating Current: 0.8 Amp (maximum) Power: 25 Watts L.1.1 Power Supply Cord Cord type: 3 conductors, 1.0 mm minimum conductor size (approximately 18 AWG) Rated for: 250 Volts AC, 10 Amps...
  • Page 90 Specifications L.2 Temperature Limitations Operating range: 0° to 50°C (32° to 122°F) Storage range: -40° to 66°C (-40° to 151°F) Max temperature 20°C (36°F) change per hour: Rapid temperature changes may affect operation. Therefore, do not operate the Server near heating or cooling devices, large windows, or doors that open to the outside.
  • Page 91 Specifications L.4 Relative Humidity Limitations Operating: 10% to 90% noncondensing (40% to 60% recommended)) Storage: 10% to 90% (noncondensing) L - 3...
  • Page 92 Specifications L - 4...

  • Page 93: Frequently-Used Commands

    Frequently-used Commands M - Frequently-used Commands This appendix lists some of the most frequently-used commands of the Print Server command set. More information about the command set, including additional options, can be found in the Print Server Reference Manual on the CD-ROM. Please note the following before continuing: Commands are divided into Server (general), Port, and Protocol sections.
  • Page 94 Frequently-used Commands M.1 Server Commands Table M-1: Frequently-used Server Commands Command Option(s) Description DEFINE SERVER BOOTP {EN|DIS} Enables or disables querying for a BOOTP host at system boot time. Enables or disables querying for a DHCP host at sys- DEFINE SERVER DHCP {EN|DIS} tem boot time.
  • Page 95 Frequently-used Commands Table M-1: Frequently-used Server Commands, cont. Command Option(s) Description Sets the Server’s network IP address. DEFINE SERVER IPADDRESS ipaddress Specifies the TCP/IP host from which the Server DEFINE SERVER LOADHOST ipaddress requests its run-time code. Sets a new password that will be required before DEFINE SERVER LOGIN PASSWORD incoming logins are accepted.
  • Page 96 Frequently-used Commands Table M-1: Frequently-used Server Commands, cont. Command Option(s) Description DEFINE SERVER SOFTWARE "filename" Specifies the name or path (TCP) of the software download file. The filename can be up to 11 charac- ters, and the pathname can be up to 26. The Server will add a ".SYS"...
  • Page 97 Frequently-used Commands Table M-1: Frequently-used Server Commands, cont. Command Option(s) Description Toggles whether the named service can be used to ser- DEFINE SERVICE APPLETALK vice networks running the specified protocol. RTEL "name" option {EN|DIS} applies to TCP/IP networks. LANMAN {EN|DIS} LAT {EN|DIS} NETWARE {EN|DIS} RTEL {EN|DIS}...
  • Page 98 Frequently-used Commands Table M-1: Frequently-used Server Commands, cont. Command Option(s) Description Specifies which service will handle print requests DEFINE SERVICE DLC {EN|DIS} from DLC hosts. DLC can be enabled on one service "name" option per Server. BANNER {EN|DIS} When Enabled, causes the Server to print a banner page before jobs.
  • Page 99 Frequently-used Commands Table M-1: Frequently-used Server Commands, cont. Command Option(s) Description Specifies a raw TCP listener socket for the service. DEFINE SERVICE TCPPORT string Enter a socket number (4000 to 4999) or the word "name" option none. TELNETPORT Specifies a TCP listener socket for the service. Unlike TCPport, this option performs Telnet IAC interpreta- string tion on the data stream.
  • Page 100 Frequently-used Commands Table M-1: Frequently-used Server Commands, cont. Command Option(s) Description Removes the definitions of all local services. PURGE SERVICE LOCAL option "service" Removes the definition of the specified service. SET PRIVILEGED Enters privileged mode, provided the user enters the proper privileged password when prompted.
  • Page 101 Frequently-used Commands M.2 Port Commands In the following commands, nn can be a single port number, a list of port numbers separated by commas, a range of port numbers separated by dashes, or the word all. Table M-2: Port Commands Command Option(s) Description...
  • Page 102 Frequently-used Commands Table M-2: Port Commands, cont. Command Option(s) Description When Enabled, the Server will not assert DTR on the port DEFINE PORT nn DTRWAIT {EN|DIS} when it is idle (no user logins or connections). DEFINE PORT nn Specifies CTS/RTS (hardware) flow control. FLOW option Activates or deactivates the currently-configured flow- {EN|DIS}...
  • Page 103 Frequently-used Commands Table M-2: Port Commands, cont. Command Option(s) Description Displays the port’s configuration characteristics once {SHOW|MONITOR} PORT nn (Show) or continually every three seconds (Monitor). Counters and Status keywords can be added. TEST PORT nn COUNT rows Sends an ASCII data stream to the port for the specified number of rows and/or columns.
  • Page 104 Frequently-used Commands M.3 Protocol Commands In the following table, PROTO is an abbreviation for the optional keyword PROTOCOL. Table M-3: Protocol Commands Command Option(s) Description Restricts connections to the specified IP address from DEFINE PORTS nn the specified ports, and connections from the IP address IPSECURITY to the specified ports.
  • Page 105 Enables or Disables the LAN Manager protocol for the DEFINE PROTO {EN|DIS} Server. LANMAN option DEFINE PROTO LAT {EN|DIS} Enables or Disables the LAT protocol for the Server. option Enables LAT on multi-port Servers. Enter the license LICENSE string string obtained from Lantronix. M - 13...
  • Page 106 Configures the NetWare Directory Services license DSLICENSE string needed to enable NDS on your Server. Enter the license string obtained from your dealer or Lantronix. Configures the NetWare Directory Services tree in DSTREE string which the Server is located. For more information about NDS trees, see your NDS documentation.
  • Page 107 Frequently-used Commands Table M-3: Protocol Commands, cont. Command Option(s) Description Same as DEFINE SERVER NETWARE LOADHOST DEFINE PROTO NETWARE LOADHOST server, page M-3. server PURGE IPSECURITY Removes the entire IP security table. option ipaddress Removes entries from the IP security table that are related to the specified IP address.
  • Page 108 Frequently-used Commands M - 16...

  • Page 109: Warranty Statement

    Warranty Statement For details on the Lantronix warranty replacement policy, go to our web site at http://www.lantronix.com/support/warranty/index.html...

  • Page 110: Declaration Of Conformity

    Warning: This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Manufacturer’s Contact: Director of Quality Assurance, Lantronix 15353 Barranca Parkway, Irvine, CA 92618 USA General Tel: 949/453-3990 Fax: 949/453-3995...
