Services

Incoming Telnet is only possible if your EPS has an IP address configured. Incoming
Telnet is enabled by default to allow TCP/IP connections. To change this setting, use the
Define Server Incoming command described in the Command Reference chapter of the
Print Server Reference Manual located on the CD-ROM.
Incoming logins do not prompt for a login password, so you may wish to disable them for
security reasons. If it is undesirable to disable incoming logins, the EPS can be configured
to prompt for a password with the Define Server Incoming Password Enabled command.

3.1.3 Console Terminal

To configure the EPS via a console terminal, attach a terminal to the serial port and press
the Return key. You will see a Local> prompt at which you can enter configuration
commands.
3.2 Services
With few exceptions, you must create a service before you can configure print queues on
the EPS. A service is a resource accessible to network hosts. A Lantronix service is also
known as a remote printer name or remote queue name on many operating systems.
The EPS offers one login service and one default service per port. The service names are:
EPS_xxxxxx
EPS_xxxxxx_S1
EPS_xxxxxx_P1
EPS_xxxxxx_P2
The default service names are based on the server name; therefore the server name must be
no more than 13 characters. If you change the server name, the service names will change
as well. For example, changing the server name from EPS_xxxxxx to BIOLAB will change
the service names to BIOLAB_TEXTS1 and so on.
The default serial port services have the TCP/IP, NetWare, LAN Manager, and AppleTalk
protocols enabled. Parallel port services have TCP/IP, NetWare, and LAN Manager
enabled. LAT is disabled by default on all services provided by the EPS because many
network managers object to the frequent LAT service announcements. AppleTalk is
disabled on parallel port services because AppleTalk requires Bitronics mode, which is
disabled by default.
If you need to modify a default service, see the Server Configuration chapter of the Print
Server Reference Manual located on the CD-ROM.
3-2
Login service
Serial port (Port_1) service
Parallel port (Port_2) service
Parallel port (Port_2) service, EPS2 only
