  • Page 1 Full Manual 1/2.9" Network Camera PXD-2080Z03 B...

  • Page 2: Table Of Contents

    Table of contents 1. Safety Instructions and Notes…....................... 2. General Descriptions................……………………………... 3. Supplied Items..................……………………………... 4. Part names…………………………….…...........…………………………... 5. Installation Instructions..................……………………... 6. Setup Menu ……………................…………………………... 7. Specifications ………………………………………………..............8. Dimensional Drawings ……………………………………………............
  • Page 3 WARNING To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert the user to the presence of important operating and maintenance(servicing) instructions in the literature accompanying the unit. The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage"...

  • Page 4: Safety Instructions And Notes

    1. Safety Instructions and Notes • Please read this safety and operating instructions before putting the camera into operation. • Keep the manual in a safe place for later reference. • Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get in.
  • Page 5 • SMART MOTION ZOOM(Automatic Zoom IN/OUT when motion is detected) • Pointing Zoom which enables the flexible zooming at any area • Motion Detection / Motion Deblur / Privacy Mask / Defog • Focusing Status Indicator on Screen  (Blue) Focusing in process ...

  • Page 6: Supplied Items

    3. Supplied Items • 1x MegaPixel Network AF Zoom Camera • 1x Installation and Operating Instructions • 1x ①Pipe hole cap • 1x ②Pipe Spacer • 1x ③L-shape hex wrench • 3x ④Wrench Bolt for surface mount • 4x ⑤Anchors •...

  • Page 7: Part Names

    ⓓ 4. Control and Part names ⓔ ⓐ ⓑ ⓒ ⓕ ⓖ ⓗ ⓘ ⓝ ⓜ ⓞ ⓟ ⓛ ⓚ ⓙ Surface Mount Base Dome Bubble Assembly ⓐ Lens ⓘ Mount holes(x3) for dome base ⓑ Light sensor for IR LEDs ⓙ...

  • Page 8: Installation Instructions

    5. Installation 5.1 Installation Instructions WARNING NEVER USE THIS CAMERA 1) in WATER. 2) in area where has SHOCK or VIBRATION which results in the problems for Auto Focus operation. • Make sure the power is removed before the installation. •...
  • Page 9 5.2 Surface mount Ceiling or wall Quick installation guides; Surface mount 1. Locate the mounting template at the installation position base and drill the ceiling or wall if needed. 2. Place Surface mount base on pre-drilled position and fix it through ⓙSurface mount holes(x4) by using ⑥Mount screws.
  • Page 10 5.3 Flush mount Ceiling or wall Quick installation guides; 1. Locate the mounting template at the installation position and drill the ceiling or wall if needed. Dome base 2. Open Dome bubble assembly by loosening ⓘRing cover assembly fixing screws(x3) CAUTION Extreme care should be taken NOT to scratch the dome ⑥Mount screws...
  • Page 11 5.4 Limit of pan and tilt 1. Pan limit Pan is limited to +/- 165°. Do NOT force to rotate the gimbal over the limit to prevent from the internal damage. 2. Tilt limit Tilt is limited to 15° min ~ 90° max. with reference to the ceiling when the inclination of camera module is 0°, that is, the image is aligned horizontally.
  • Page 12 5.5 Installation and commissioning Instructions • Make sure the power is removed before the installation. • After all connections are finished properly, follow the order for applying power. a) Plug the network cable into RJ-45 Ethernet Port at the rear panel. If PoE is the unique power, there will be no need to connect Power terminal.
  • Page 13 5.2.1 EMI Ferrite Core Connections Please connect EMI Ferrite Core as below photos. 50mm 50mm...

  • Page 14: Setup Menu

    6. Setup Menu 6.1 Quick Network Setup The network camera‘s default IP address is: 192.168.1.10. Therefore, to access the camera for the first time, set the PC‘s address as 192.168.1.XX; for example: IP Address: 192.168.1.20 Subnet Mask: 255.255.255.0 • Enter the camera’s IP address in the URL bar of the Web browser window and hit “Enter.” •...
  • Page 15 If the Information message doesn‘t come out due to the problems like network failure, you can start the manual installation. Click the Install ActiveX Control, and the pop-up window will be displayed. After the installation is successfully completed, Smart Viewer window will be displayed. - Assigning an IP address To assign an IP address to the camera proceeded as follows: Click Network Configuration on the Network Configuration menu.
  • Page 16 Depending on the service type, the network configuration can be in any of Static IP, DHCP Client, or PPPoE. You need to set up the network camera according to your network type. For static IP, select static IP and input values for IP address, NetMask, Gateway, DNS1, DNS2 and click apply for saving settings.
  • Page 17 PPPoE is used to connect IPproducts to PPPoE modem provided by ISP. Since PPPoE needs verification, ID and password are necessary to access network. Type in ID and password.
  • Page 18 - Administrator password To change the password for the administrator, click Admin Password on System Configuration menu. Default ID for admin account is fixed as “root” and not allowed to change. In Old Password field, enter the current password. In both New Password and Confirm Password fields, enter the same new password.
  • Page 19 - Accessing the setup menu Camera SETUP menu can be accessed in two ways via web viewer. Most frequent controls are available with the parameters directly in the below table. More complicated settings such as PRIVACY, POINTING ZOOM & SMART MOTION settings are available via ‘ADVANCED CAMERA MENU’...
  • Page 20 6.2 Direct Control menu SPECIAL Default Descriptions Selects HDTV standards for US(60HZ) or EU(50HZ). TV SYSTEM By this selection, 2 analog video output switches to NTSC or PAL accordingly. ZOOM PUSH, AUTO and MANUAL modes are available for focusing. ZOOM PUSH – Focusing is activated only when zoom in/out is working. ZOOM FOCUS MODE AUTO –...
  • Page 21 Improves the visibility for the high bright area and the dark area by the double captures of image with LONG and SHORT exposures. With WDR ON, the frame rate becomes half by the double captures. ※CVBS video signal - Connecting 2nd video to CVBS port disables WDR function temporary. It should be considered when installer adjusts the video with installation monitor via CVBS video signal.
  • Page 22 ATW, ONE PUSH and MANUAL are available for the white balance modes. ATW – White balance is continuously working along with the color temperature changes in the range of 2,000K~8,500K. WHITE BAL ONE PUSH- White balance works only when ONE PUSH is selected. MANUAL –This mode can be used only when the color temperature does not vary.
  • Page 23 Display Title ON enables to display Camera Title on Monitor. IR LED Control(AUTO/OFF) is available with IR LED model only. If IR LED is set to OFF, IR LED will be turned OFF but IR LED Mode DAY or NIGHT is still determined by the built-in light photo sensor. IR LED Mode is workable with IR LED built-in model only.
  • Page 24 SPECIAL Default Descriptions 10 Privacy zones which can be enabled individually by ZONE DISP are available to mask the video. ZONE NUMBER – Set a number to select a privacy zone from 1~10. ZONE DISP – ON enables a relevant privacy zone. PRIVACY H-POS, V-POS, H-SIZE and V-SIZE –...
  • Page 25 SMART IR can be set to reduce the saturation by the strong IR illumination in the night in any menu of EXT, AUTO and B/W(NIGHT) SMART IR Setting SMART IR in any menu is identically applied to other menu. Zero(0) turns off SMART IR and High setting avoids the saturation strongly but the corners will be darker accordingly.
  • Page 26 6.3.1 SMART MOTION ZOOM SMART MOTION ZOOM enlarges the certain area defined by a yellow window to the full sized image when the motion is detected in the black window. SMART MOTION ZOOM window can be re-sized by adjusting D-ZOOM RATIO and moved by H-POINTER and V-POINTER.
  • Page 27 6.3.2 POINTING ZOOM This camera has a very useful and powerful feature, POINTING ZOOM, which can zoom in/out any area. UNLIKE the conventional zoom which can zoom in/out the center area of image only, by the flexible zoom location and area, POINTING ZOOM differentiate its usefulness from others. That is, a conventional camera installed on the corner of ceiling can zoom the center of the floor in a room and result in losing the image of door on the side wall.

  • Page 28: Specifications

    . Specifications PXD-2080Z03 B 207513 Imaging Sensor Sony Exmor 1 / 2.9” Progressive Scan CMOS Sensor Effective Pixels 1,936(H) x 1,097(V) Min. Illumination 0.0008 Lux (@AGC MAX, DSS x2) Output Video Resolution 1920x1080(30p/25p) TV system US(60Hz)(switchable to EU(50HZ)) EU(50Hz)(switchable to US(60Hz)) Sync.
  • Page 29 Power PoE(IEEE Std. 802.3af), 24V ~ 15VA / 12V, 1A DUAL POWER Circuit protection against faulty connection in Power Polarity Isolated power supply against ground loop problem Protection Rating IP67 / IK10 Mechanical Feature Changeable surface mount and flush mount / Perfect 3-Axis gimbal Installation Temperature -20ºC ~ +50 ºC (Humidity : 20%RH ~ 80%RH) Operating Temperature -30ºC ~ +50 ºC (Humidity : 20%RH ~ 80%RH) Housing Solid Aluminum Cast with Hard coated polycarbonate clear Bubble...

  • Page 30: Dimensional Drawings

    8. Dimensional Drawings (Unit: mm)
