Eneo PXB-2280Z10 D Quick Installation Manual

1/3” network camera, wdr, day&night, 1920 x 1080, 5.1-51mm, poe, infrared, 10x af zoom
Hide thumbs

Advertisement

Quick Links

Download this manual
EN
Quick Installation Guide
1/3" Network Camera, WDR,
Day&Night, 1920x1080, 5.1-
51mm, PoE, Infrared, 10x AF
Zoom
PXB-2280Z10 D

Advertisement

loading
Need help?

Need help?

Do you have a question about the PXB-2280Z10 D and is the answer not in the manual?

Questions and answers

Related Manuals for Eneo PXB-2280Z10 D

Summary of Contents for Eneo PXB-2280Z10 D

  • Page 1 Quick Installation Guide 1/3” Network Camera, WDR, Day&Night, 1920x1080, 5.1- 51mm, PoE, Infrared, 10x AF Zoom PXB-2280Z10 D...

  • Page 3: Safety Precaution

    NETWORK AF-ZOOM CAMERA Safety Precaution To prevent fire or shock hazard, do not expose the unit to rain or moisture. To prevent electric shocks and risk of fire hazards, do NOT use other than specific power source. CAUTION: TO REDUCE THE RISK OF ELECTIC SHOCK, DO NOT REMOVE COVER (OR BACK).
  • Page 4 NETWORK AF ZOOM CAMERA Safety Precaution NOTICE The image used in this instruction manual are processed to help comprehension and may differ from actual video of the camera. Avoid installing areas where has shock or vibration which results in the problems. Pay attention to safety when laying the connection cable and observe that the cable is not subjected to heavy loads, kinks or damage and no moisture can get Never open the device such as boards or lens.

  • Page 5: Table Of Contents

    NETWORK AF ZOOM CAMERA Contents p.03~04 Safety Precaution p.05 Contents p.06~07 Features p.07 Composition p.08 Dimensions p.08 Part Names p.09~11 Installation Instructions p.12~33 Operating Instructions p.34~35 Specifications...

  • Page 6: Features

    NETWORK AF ZOOM CAMERA Features Key Features • Full HD, 2.4 Mega Pixel, NETWORK CAMERA, 1920x1080(30p/25p) • ONVIF & PSIA Conformance • True WDR (Wide Dynamic Range) • Improved noise figure with 2D+3DNR • Built-in f=5.1~51mm, F1.6~F1.8 Day & Night zoom lens (Optical 10x Auto focus zoom / Digital 32x zoom) •...
  • Page 7 NETWORK AF ZOOM CAMERA Features General Description This camera realizes the natural and crisp image as you see the scene in front of you by adopting Auto Focus Full HD(1920x1080p) camera module. Highly detailed pictures can be achieved and color reproducibility deserves attention. •...

  • Page 8: Dimensions

    NETWORK AF ZOOM CAMERA Dimensions (unit : mm) 87.30 Part Names SUNSHIELD BOLT SUNSHIELD ETHERNET & POWER CABLE OSD Setup CONTROL COVER DUAL WINDOW EASY BRACKET BRACKET FRONT CASE REAR CASE LOCK/UNLOCK SCREW...

  • Page 9: Installation Instructions

    NETWORK AF ZOOM CAMERA Installation Instructions 1. Locate the mounting template at the installation position and drill the ceiling or wall if needed. ( *The easy bracket can not be installed on the ceiling) 2. Place the easy bracket on pre-drilled position and fix it through using mounting screws.
  • Page 10 NETWORK AF ZOOM CAMERA Installation Instructions Pan & Tilt adjustments • Unlock the screw on the camera bracket through using the torque wrench supplied • Set the camera’s viewing angle then lock the screw on the bracket. 1) Pan limit: Pan is limited to +/- 90°.
  • Page 11 NETWORK AF ZOOM CAMERA Installation Instructions Installation and commissioning Instructions • Make sure the power is removed before the installation. • After all connections are finished properly, follow the order for applying power. a) Plug the network cable into RJ-45 Ethernet Port. If PoE is the unique power, there will be no need to connect Power terminal.

  • Page 12: Operating Instructions

    NETWORK AF ZOOM CAMERA Operating Instructions Using OSD controller Setup menu can be accessed and controlled by OSD control joy stick on the side of camera unit. Five commands are available with the joy stick. The design of OSD could be different according to the Model. Standard SD Card Slot IP RESET...
  • Page 13 NETWORK AF ZOOM CAMERA Operating Instructions Quick Network Setup NOTICE After the camera is connected with IP, its control is available via WEB Viewer. To access the ADMIN on IP INSTALLER ID: root PW: root The network camera‘s default IP address is: 192.168.1.10. Therefore, to access the camera for the first time, set the PC‘s address as shown.
  • Page 14 NETWORK AF ZOOM CAMERA Operating Instructions 1. Assigning an IP address To assign an IP address to the camera proceeded as follows: Click Network Configuration on the Network Configuration menu. • Depending on the service type, the network configuration can be in any of Static IP, DHCP Client, or PPPoE.
  • Page 15 NETWORK AF ZOOM CAMERA Operating Instructions • For DHCP, DHCP server must exist in the same network environment. Select DHCP Client from Network Configuration, click Apply. • PPPoE is used to connect IP products to PPPoE modem provided by ISP. Since PPPoE needs verification, ID and password are necessary to access network.
  • Page 16 NETWORK AF ZOOM CAMERA Operating Instructions 2. Administrator password To change the password for the administrator, click Admin Password on System Configuration menu. • Default ID for admin account is fixed as “root” and not allowed to change. In Old Password field, enter the current password. In both New Password and Confirm Password fields, enter the same new password.
  • Page 17 NETWORK AF ZOOM CAMERA Operating Instructions 3. Accessing the camera setup menu Camera SETUP menu can be accessed in two ways via web viewer and camera OSD control joystick. Refer using 5 command keys as below. OSD menu Startup Press OSD MENU key down or click MENU Enter button to access the setup menu mode.
  • Page 18 NETWORK AF ZOOM CAMERA Operating Instructions MENU ZOOM/FOCUS EXPOSURE WHITE BAL IMAGE INTELLIGENCE SPECIAL FUNC DISPLAY [ EXIT ] [ SAVE ] [ DFLT ] OSD menu Table MAIN MENU SUB MENU CONFIGURATION FOCUS AUTO, ONE PUSH, MANUAL ZOOM/FOCUS DISTANCE 0.1m, 1.0m, 3.0m, 5.0m, 10.0m ZOOM SPEED ONE PUSH...
  • Page 19 NETWORK AF ZOOM CAMERA Operating Instructions DAY&NIGHT AUTO DELAY 0~255sec EXPOSURE THRS 0~28 LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH OFF, ON IR DETECTION IRDET LEVEL LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH BURST OFF, ON DELAY 0~255sec EXT-IN BURST OFF, ON POLARITY ACTIVE LOW, ACTIVE HIGH BURST NIGHT OFF, ON...
  • Page 20 NETWORK AF ZOOM CAMERA Operating Instructions DEFECT SPECIAL FUNC FULL IMAGE RANGE COMP USER LEVEL (0~32) NTSC or PAL SYSTEM HD FORMAT 1080p/30(25)fps COMM ID, BAUD RATE, PROTOCOL DISP SEL DISPLAY ID, TITLE, ZOOM RATIO, SYSTEM MSG SET TITLE INIT SEL ID, BAUDRATE, PROTOCOL, VERSION, INIT MSG SET INIT MSG...
  • Page 21 NETWORK AF ZOOM CAMERA Operating Instructions OSD menu Setup MENU ZOOM/FOCUS ZOOM/FOCUS FOCUS EXPOSURE DISTANCE 1.0m WHITE BAL ZOOM SPEED IMAGE LENS REFRESH ONE PUSH INTELLIGENCE E.ZOOM SPECIAL FUNC ZOOM PRESET DISPLAY HOME POSITION [ EXIT ] [ SAVE ] [ DFLT ] [ BACK ] [ SAVE ]...
  • Page 22 NETWORK AF ZOOM CAMERA Operating Instructions 1-5. E. ZOOM (default: OFF) : E-ZOOM is available up to 32x. It starts working when the optical zoom reaches its maximum tele-position. Zoom ratio is displayed on the right bottom corner of the monitor if DISPLAY>DISP SEL>ZOOM RATIO is set to ON. ※...
  • Page 23 NETWORK AF ZOOM CAMERA Operating Instructions Setting for Zoom Function with NVR or VMS ● Enter the MENU : Press buttons 9+5+PSET (PRESET) ● Set the Preset Zoom : Press buttons 1(or ~4)+PSET (PRESET) ● Move the cursor in the MENU : Moves UP/DOWN/LEFT/RIGHT Joy stick ●...
  • Page 24 NETWORK AF ZOOM CAMERA Operating Instructions 2-1. MODE (default: AUTO) : Can set EXPOSURE MODE to AUTO, IRIS P, SHUT. P, and MANUAL. • AUTO: Optimizes the video level by controlling the iris and the shutter speed automatically. • IRIS P: If you set to IRIS.P mode, it can be adjusted IRIS value.(refer to 2-4.IRIS) Selects to fix IRIS in a certain apperture and the video level is controlled by an automatic shutter control.
  • Page 25 NETWORK AF ZOOM CAMERA Operating Instructions 2-8. BLC/WDR/HLC (default: OFF) : Select WDR(Wide Dynamic Range) , BLC(Back Light Compensation) or HLC(High Light Compensation) functions. 2-8-1. WDR(Wide Dynamic Range): : This function is extended the gain range of the screen that is mostly useful if camera takes a simultaneous picture of both indoor and outdoor nearby window.
  • Page 26 NETWORK AF ZOOM CAMERA Operating Instructions 2-9. DAY & NIGHT : This function is used to control the setting during day-time and night-time operation. 2-9-1. EXT-IN DAY&NIGHT : The camera switches DAY from/to NIGHT automatically DELAY using the detected brightness BURST level by photocell.
  • Page 27 NETWORK AF ZOOM CAMERA Operating Instructions • IR DETECTION : Sets ON or OFF • IR DET LEVEL : Sets IR Detection level. LOW, MID-LOW, MIDDLE, MID-HIGH, HIGH • BURST: It determines whether a color burst signal keeps output or eliminated when camera switches to B/W.
  • Page 28 NETWORK AF ZOOM CAMERA Operating Instructions 4. IMAGE IMAGE MIDDLE MIRROR SHARPNESS DEFOG FREEZE GAMMA 0.55 [ BACK ] [ SAVE ] [ DFLT ] (default: MIDDLE) 4-1. DNR : DNR(Digital Noise Reduction) function improves picture quality by filtering out signal noise which is generated under the low light conditions.
  • Page 29 NETWORK AF ZOOM CAMERA Operating Instructions (default: OFF) 4-6. DEFOG : This function is used to carry out defog function. Set to ON, it can be set MODE and LEVEL to eliminate amount of fog on screen. ※ If the DEFOG is set to ON, the ACE(D-WDR) function will be deactivated. 4-6-1.
  • Page 30 NETWORK AF ZOOM CAMERA Operating Instructions • TRANS: Defines the transparency for the masking zone from 0(100%) to 4(25%). (default: OFF) 5-2. MOTION : Sets ON/OFF for enabling/disabling MOTION. It is used to detect motion in the monitored area which can set up to 3. MOTION INTELIGENCE AREA#...
  • Page 31 NETWORK AF ZOOM CAMERA Operating Instructions 6. SPECIAL FUNC SPECIAL FUNC DEFECT IMAGE RANGE COMP SYSTEM NTSC/PAL HD FORMAT 1080P/30fps COMM [ BACK ] [ SAVE ] [ DFLT ] 6-1. DEFECT DET : Detects and compensates the defective pixels. Procedure ] 1) Close the lens and make the screen dark.
  • Page 32 NETWORK AF ZOOM CAMERA Operating Instructions 7. DISPLAY DISPLAY DISP SEL SET TITLE INIT SEL SET INIT MSG LANGUAGE ENGLISH [ BACK ] [ SAVE ] [ DFLT ] 7-1. DISP SEL : Sets ON/OFF the display items • ID: Sets ON/OFF to display the camera ID defined by ‘SPECIAL FUNC > COMM >...
  • Page 33 NETWORK AF ZOOM CAMERA Operationg Instructions SET TITLE Input line [ BACK ] [ SAVE ] [ DFLT ] 7-3. INIT SEL : Sets ON/OFF to display the camera related system. • ID: Sets ON/OFF to display the camera initial ID •...

  • Page 34: Specifications

    NETWORK AF ZOOM CAMERA Specifications PXB-2280Z10 D ITEM Imaging Sensor 1/3" Panasonic Progressive Scan CMOS Sensor Effective Pixels 1,956(H) x 1,266(V) Min.Illumination 0.5 Lux (Color), 0.1 Lux (BW) / 0.002 Lux (Color, DSS), 0.001 Lux (BW, DSS) 1920x1080(1080p/30fps, 25fps) Video Resolution...
  • Page 35 NETWORK AF ZOOM CAMERA Specifications Power Source PoE(IEEE Std. 802.3af ), AC24V~16.5VA/DC12V=980mA, 12W Circuit protection against faulty connection in power polarity. Isolated power supply against ground loop problem. NETWORK SPECIFICATION Video Encoding H.264 / MJPEG dual streaming Protocol HTTP, TCP/UDP/IP, ARP, ICMP, RTP/RTSP, multicast, Telnet, IPv6, PPPoE, SMTP(e-mail), DHCP, NTP, uPNP, ftp, IGMP, ONVIF, PSIA Transmission Control VBR, CBR ( 32K ~ 12M bps )
  • Page 36 VIDEOR E. Hartig GmbH Exclusive distribution through specialised trade channels only. VIDEOR E. Hartig GmbH Carl-Zeiss-Straße 8 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 Technical changes reserved Fax +49 (0) 6074 / 888-100 www.videor.com...
