- Page 1 Full Manual 1/2.8" Network Full HD Speed Dome, PTZ, 30x, Day&Night PXD-2030PTZ1080...
-
Page 2: Table Of Contents
Table of Contents Overview ..........................2 Features ........................2 Package Contents ....................... 3 Dimensions ........................4 Switch / Connector Definition ..................5 Camera Cabling ........................6 Connect Power ......................6 Connect Ethernet Cable....................6 Apply Alarm I/O ......................7 Apply Audio ......................... 7 System Requirements ...................... -
Page 3: Overview
Overview The Full HD Ultra WDR Speed Dome IP Camera transmits digital video and audio data using wire connection. Live video can be monitored and recorded from window-based computer via network. The video encoder supports Real-Time H.264 Full HD resolution. Simultaneous Quad Codecs, H.264 Baseline / Main / High Profile, MJPEG, are available for various network applications via speeding or limited bandwidth. -
Page 4: Package Contents
Package Contents The package should contain the items listed below. If any item is missing or has defects, contact the dealer for assistance. M3 Standard Screw (x1) M3 Security Screw (x1)* Dome Camera with M5 Standard Screw (x1) Outdoor Mount Kit M5 Security Screw (x1)* Quick Guide CD: Operation Manuals... -
Page 5: Dimensions
Dimensions... -
Page 6: Switch / Connector Definition
Switch / Connector Definition Refer to the diagrams and the tables below for the use of each switch / connector. Outdoor RJ-45 Connector Alarm I/O Power microSD Card Slot Factory Reset Button Audio I/O... -
Page 7: Camera Cabling
Camera Cabling Follow the instructions below to complete IP Camera connection. Connect Power Refer to the illustration and the pin definition table below to connect the power core through the supplied power adaptor to the camera. Definition AC 24_1 AC 24_2 Connect Ethernet Cable Use of Category 5 Ethernet Cable is recommended for network connection;... -
Page 8: Apply Alarm I/O
Apply Alarm I/O The camera supports 4 digital alarm inputs and 2 digital alarm outputs. Please refer to the illustration and the pin definition table below for alarm system wiring. Definition Definition ALARM_OUT_NO_1 ALARM_OUT_COM_2 ALARM_OUT_NC_1 ALARM_OUT_COM_1 ALARM_IN_4 ALARM_IN_3 ALARM_OUT_NO_2 ALARM_IN_2 ALARM_OUT_NC_2 ALARM_IN_1 Apply Audio... -
Page 9: System Requirements
System Requirements To perform the IP Camera via web browser, please ensure the PC is in good network connection, and meet the system requirement as described below. Items Minimum Requirement 1. Intel® Pentium® IV, 3 GHz or higher, Intel® Core2 Duo, 2 GHz or higher Personal Computer 2. -
Page 10: Access Camera
Access Camera The network Speed Dome Camera’s default IP address is: 192.168.1.10. Therefore, to access the camera for the first time, set the PC’s IP address as: 192.168.1.XXX; for example: IP Address: 192.168.1.20 Subnet Mask: 255.255.255.0 Login ID & Password •... - Page 11 The download procedure of DC Viewer software is specified as follows. Step 1: In the DC Viewer installation window, click on <Next> to start the installation. Step 2: A status bar will be displayed to show the installation progress. After the installation is completed, click on <Finish> to exit the installation process.
-
Page 12: Setup Video Resolution
Setup Video Resolution Users can setup Video Resolution on Video Format page of the user-friendly browser-based configuration interface. Video Format can be found under this path: Streaming> Video Format. The default values of the Video Resolution are as below. H.264 1920 x 1080 (30 fps) + H.264 720 x 480 (30 fps) For more Video Resolution combination detail, please refer to chapter Appendix D: Video Resolution. -
Page 13: Appendix A: Technical Specifications
Appendix A: Technical Specifications Camera PXD-2030PTZ1080 Image Sensor 1/2.8" Sony Progressive CMOS Optical Zoom Digital Zoom Focal Length 4.3 ~ 129.0 mm Wide Dynamic Range Shutter WDR (>96dB) Focus Mode Auto / Manual White Balance Auto / Indoor / Outdoor / ATW / Manual... - Page 14 General Environment Indoor / Outdoor ∅ 191.97 x 282.11 mm (∅ 7.55 × 11.10 in.) w/ Sunshield Operating Temperature -40°C ~ 50°C (-40°F ~ 122°F) Dimension Weight 2.30 kg (5.07 lbs) w/ Sunshield Power Source 802.3 at PoE+ (60 W) / AC 24V ± 10% Power Consumption 59 W (w/ Heater) Regulatory...
-
Page 15: Appendix B: Delete The Existing Dc Viewer
Appendix B: Delete the Existing DC Viewer For users who have installed DC Viewer in the PC previously, please remove the existing DC Viewer before accessing the IP Camera. Deleting the DC Viewer Activate the <Control Panel>, and then double click on <Add or Remove Programs>. In the <Currently installed programs>... -
Page 16: Appendix C: Setup Internet Security
Appendix C: Setup Internet Security If ActiveX control installation is blocked, please either set Internet security level to default or change ActiveX controls and plug-ins settings. Internet Security Level: Default Step 1: Start the Internet Explorer (IE). Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>. Step 3: Click on the <Security>... -
Page 17: Appendix D: Video Resolution
Appendix D: Video Resolution Quad Stream H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (15 fps) 1280 x 720 (15 fps) 640 x 480 (15 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 800 x 600 (15 fps) 640 x 480 (30 fps) - Page 18 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 720 x 480 (30 fps) 1280 x 720 (15 fps) 640 x 480 (30 fps) 1280 x 720 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 1280 x 1024 (15 fps) 800 x 600 (30 fps)
- Page 19 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 (30 fps) 352 x 240 (30 fps) 720 x 480 (30 fps) 352 x 240 (60 fps) 1280 x 720 (30 fps) 640 x 480 (30 fps) 352 x 240 (60 fps) 352 x 240 (60 fps)
- Page 20 H.264 + H.264 + H.264 + H.264 / MJPEG H.264-1 H.264-2 H.264-3 H.264-4 / MJPEG 800 x 600 (60 fps) 352 x 240 (60 fps) 720 x 480 (60 fps) 800 x 600 (30 fps) 720 x 480 (60 fps) 640 x 480 (60 fps) 640 x 480 (60 fps) 640 x 480 (60 fps)
-
Page 21: Triple Stream
Triple Stream H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 1280 x 720 (15 fps) 800 x 600 (30 fps) 1280 x 1024 (15 fps) 720 x 480 (30 fps) 640 x 480 (30 fps) 352 x 240 (30 fps) 1280 x 720 (30 fps) 1280 x 720 (15 fps) 800 x 600 (30 fps) - Page 22 H.264-1 + H.264-2 + H.264-3 / MJPEG H.264-1 H.264-2 H.264-3 / MJPEG 800 x 600 (30 fps) 1280 x 720 (30 fps) 720 x 480 (30 fps) 640 x 480 (30 fps) 1280 x 720 (60 fps) 352 x 240 (60 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 1024 x 768 (30 fps)
-
Page 23: Dual Stream
Dual Stream H.264-1 + H.264-2 / MJPEG H.264-1 H.264-2 / MJPEG BNC SUPPORT 1920 x 1080 (15 fps) 1280 x 1024 (30 fps) 1920 x 1080 (15 fps) 1280 x 720 (30 fps) 1024 x 768 (30 fps) 800 x 600 (30 fps) 720 x 480 (30 fps) 1920 x 1080 (30 fps) 640 x 480 (30 fps) - Page 24 Videor E. Hartig GmbH Exclusive distribution through specialised trade chan- nels only. Videor E. Hartig GmbH Carl-Zeiss-Straße 8 · 63322 Rödermark/Germany Tel. +49 (0) 6074 / 888-0 · Fax +49 (0) 6074 / 888- Technical changes reserved www.videor.com...
