Mircom RAM-216 Wiring & Installation Manual

Mircom RAM-216 Wiring & Installation Manual

Remote multiplex annunciator panel

Advertisement

Quick Links

RAM-216
Remote Multiplex Annunciator Panel
A.C.
ON
BUZZER
SILENCE
LAMP
TEST
Wiring & Installation Manual
COMMON
SIGNAL
TROUBLE
SILENCED
SIGNAL
SILENCE
SYSTEM
RESET
Advanced Life Safety Solutions
LT-658 Rev.6
April 2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RAM-216 and is the answer not in the manual?

Questions and answers

Summary of Contents for Mircom RAM-216

  • Page 1 Advanced Life Safety Solutions RAM-216 Remote Multiplex Annunciator Panel A.C. COMMON SIGNAL TROUBLE SILENCED BUZZER SIGNAL SILENCE SILENCE LAMP SYSTEM TEST RESET LT-658 Rev.6 Wiring & Installation Manual April 2007...
  • Page 2: Table Of Contents

    Contents Contents Introduction..........................1 Technical Support......................... 1 Installation Instructions ......................2 Controls and Displays......................2 Wiring Instructions ........................3 DIP Switch Settings ......................... 4 Jumper Selection ........................4 Specifications and Features ....................5 Enclosure..........................5 Electrical Specifications ......................5 Current Drain for Battery Calculations .................. 5 Warranty and Warning Information..................
  • Page 3: Introduction

    RAM-216 Remote Annunciator Wiring and Instruction Manual Introduction Mircom’s RAM-216 Annunciator is a 16-circuit annunciator for use with Mircom’s FA-200, FA-300, FR- 320, FX-350, FA-1000 and FX-2000 Series Fire Alarm Control Panels. Annunciators mount into standard four-gang electrical boxes, and may not be expanded. Control access is by a keyswitch. Each circuit indicator is a bi-colour LED that is automatically configured to match the fire alarm control panel configuration.
  • Page 4: Installation Instructions

    Indicating and relay circuits are not remotely displayed. For more details, refer to the manual of the fire alarm control panel that the annunciator will be connected to. • The RAM-216 has a keyswitch to enable the four slide-switch controls. The key should be appropriately secured.
  • Page 5: Wiring Instructions

    RAM-216 Remote Annunciator Wiring and Instruction Manual Wiring Instructions The RS-485 Wiring to the RAM-216 Module is recommended to be twisted shielded pair as shown in the diagram. The wire gauge may 24 VDC POWER TO 24 VDC NEXT ANNUNCIATOR OUTPUT •...
  • Page 6: Dip Switch Settings

    DIP Switch Settings DIP Switch Settings Each annunciator needs to be assigned a unique, sequential address via DIP switches SW1-1, SW1-2, and SW1-3. DIP switch SW1-4 is used to allow disabling of some front panel slide switches. SW1-1 Address A0\ Three digit address of the annunciator (address SW1-2 Address A1...
  • Page 7: Specifications And Features

    RAM-216 Remote Annunciator Wiring and Instruction Manual Specifications and Features Enclosure • A standard 4-gang electrical box is used. Electrical Specifications • 24 VDC nominal voltage • Slide-switch controls, LED indicators, and keyswitch to enable controls. • Local buzzer, indicators (ac-on, common trouble, signal silence), and controls (system reset, lamp test, buzzer silence, signal silence).
  • Page 8: Warranty And Warning Information

    Warranty and Warning Information Warranty and Warning Information Warning Please Read Carefully Note to End Users: This equipment is subject to terms and conditions of sale as follows: Note to Installers This warning contains vital information. As the only individual in contact with system users, it is your responsibility to bring each item in this warning to the attention of the users of this system.
  • Page 9 RAM-216 Remote Annunciator Wiring and Instruction Manual •Software Most Summit products contain software. With respect to those products, Summit does not warranty that the operation of the software will be uninterrupted or error-free or that the software will meet any other standard of performance, or that the functions or performance of the software will meet the user’s requirements.
  • Page 10: Limited Warranty

    Warranty and Warning Information Limited Warranty Summit Systems Technologies warrants the original purchaser that for a period of two years from the date of manufacture, the product shall be free of defects in materials and workmanship under normal use. During the warranty period, Summit Systems Technologies shall, at its option, repair or replace any defective product upon return of the product to its factory, at no charge for labor and materials.
  • Page 11: Out Of Warranty Repairs

    NOTE: Under no circumstances shall Mircom Technologies Ltd. be liable for any special, incidental, or consequential damages based upon breach of warranty, breach of contract, negligence, strict liability, or any other legal theory.
  • Page 12 Advanced Life Safety Solutions Canada U.S.A. © Mircom 2006 Printed in Canada 25 Interchange Way 60 Industrial Parkway PMB 278 Subject to change without prior notice Vaughan, ON L4K 5W3 Cheektowaga, NY 14227 Tel: 1-888-660-4655 Fax: 1-888-660-4113 www.mircom.com Tel: 905-660-4655 Fax: 905-660-4113...
