Installing the KWS2500
Installing Interface Cards and CPU Cards
Polycom, Inc.
• The interface cables must be removed before any interface card is removed
or replaced.
• When unplugging power, unplug AC mains power first before unplugging
the power connector from the KWS2500.
• The AC adapters must never be hanging by their own weight in the AC
mains connector or the output connector.
To Connect Power Cable
The KWS2500 has one power plug on the back panel.
Plug a suitable power cord into the AC power adapter.
1
Insert the AC power adapter output connector firmly into the socket on
2
the KWS2500 so that the retention clip snaps to the plug.
Plug the AC power adapter into mains.
3
When powering down the unit, the power connector must be unplugged
4
to ensure the unit is completely powered off.
Before you install an interface or a CPU card ensure to take the following
precautions.
Safety Precautions
Cards contain static sensitive circuitry and may be destroyed or damaged by
electrostatic discharge (ESD).
• Make sure you re using proper ESD equipment to prevent damage to the
system.
• Fill all empty slots with blanking front plates to close the front.
To Install Interface Cards
With two hands, gently slide the interface card into the unit. Give it a
1
gentle push on the last centimeter so that it enters the backplane connector
properly.
Avoid pushing on the front connectors - push only on the plastic parts at
the top and bottom.
KWS2500 Installation
9
