Page 7: Emc (Electromagnetic Compatibility) And Safety Notices
4) Connections to the transmit and receive IF interfaces must be made with double screened coaxial cable - for example RG223/U. Installations which ignore these requirements will invalidate the compliancy to EMC specifications. P300H P300 Series Modem Installation and Operating Handbook Page 7...
Page 8: Safety
This means a system that has separate earth, line and neutral conductors. The equipment is not designed to operate with an IT power system which has no direct connection to earth. CAUTION: This unit has DOUBLE POLE / NEUTRAL FUSING. P300H P300 Series Modem Installation and Operating Handbook Page 8...
Page 9: Introduction
This handbook describes how to install and configure the P300 Series Satellite Modems. This includes the original P300, the P300 Turbo, P310 L-Band and P311 mixed L-Band/IF Modems. Where ever reference is made to the P300 or P300 Series modem it applies to all products unless specifically noted.
Page 10: P300 Series Features
P300-IBS, P300-IDR and the P300-TCM. The P300 Series has been designed to make field upgrades as easy as possible, and many features may be added by front panel entry of a Feature Code which can be issued by Paradise Datacom.
Page 11: Feature Summary
Options marked with an asterisk will require boards or single IC s to be added to the unit in order to add the option at a later date. features without an asterisk can be added by entering a Feature Code into the front panel of the equipment. P300H P300 Series Modem Installation and Operating Handbook Page 11...
Page 12: Feature Highlight
FEATURE HIGHLIGHT This list highlights some of the notable features about the P300 Series Modems: All P300 Series Modems (ie base modem features) Variable data rate in 1 bps steps with fast acquisition even at low data rates BPSK, QPSK, and Offset QPSK (OQPSK) Viterbi FEC (to IESS 308/309), rate 1/2, 3/4 &...
Page 13 Tx fails and bearer is looped through to the Insert mux to pick up Rx data Timeslot ID maintenance even with Closed Net Plus ESC carriers Enhanced features with the Extended D/I Feature (see later) P300H P300 Series Modem Installation and Operating Handbook Page 13...
Page 14 (normally only N=1, 2, 3, 4, 5, 6, 8, 10, 12, 15, 16, 20, 24 are maintained for IBS/SMS and there is no ID maintenance for IDR) Insertion of only partial received data (for multi-destinational working) P300H P300 Series Modem Installation and Operating Handbook Page 14...
Page 15 Monitor only option for distant end Eb/No & BER monitoring without power control. Adds optional automatic regular logging of AUPC delta power and distant end Eb/No. Uni-directional, bi-directional and broadcast (Tx only / self monitor) modes. P300H P300 Series Modem Installation and Operating Handbook Page 15...
Page 16: Description
IF frequencies, or different services if required. Like all Paradise Datacom products, the P300 Series includes a traffic log, which stores the last 500 events, suitably time-stamped. It can automatically add several measured parameters to the log at operator set intervals, including average &...
Page 17: Front Panel Features
If the STANDBY LED is Amber, the Tx carrier is off. It may be intentionally switched off, or it may be muted due to either a fault, an external mute signal, or if in a 1-FOR-1 redundant pair it may be the standby unit. P300H P300 Series Modem Installation and Operating Handbook Page 17...
Page 18: Rear Panel Description
Remote M&C port may be internally linked (ie no cables) to the Async ESC port for over the satellite distant end Remote M&C control. Pinout details are in Appendix B. P300H P300 Series Modem Installation and Operating Handbook Page 18...
Page 19 IDR modes, and (if the IBS and `Custom Features` features are available) a custom IBS mode, which allows four backward alarms for low rate IBS multidestinational carriers. P300H P300 Series Modem Installation and Operating Handbook Page 19...
Page 20 This LED mirrors the front panel standby LED, so that from the rear of the equipment the operator can tell if the carrier is off, or more importantly which unit of a 1:1 pair is the offline unit. P300H P300 Series Modem Installation and Operating Handbook Page 20...
Page 21: Block Diagram
F. BLOCK DIAGRAM P300H P300 Series Modem Installation and Operating Handbook Page 21...
Page 22 P300H P300 Series Modem Installation and Operating Handbook Page 22...
Page 23: Summary Of Specifications
<64k to >2048k (96k overhead added) Resolution of 8k (limitation of frame structure) Note: Maximum data rate is 512kbps in all modes before overheads unless the High Data Rate option is fitted. P300H P300 Series Modem Installation and Operating Handbook Page 23...
Page 24: Modulator Specifications
1.4 times symbol rate Recommended Channel Spacing Phase and Amplitude 2 degrees, 0.2dB, max Accuracy -30dBc, min. Carrier Suppression <1.0 degrees RMS double sided, 100Hz to 100kHz Output Phase Noise P300H P300 Series Modem Installation and Operating Handbook Page 24...
Page 25: Demodulator Specifications
@ 64 kbps < 2 seconds at 6dB Eb/No (rate 1/ FEC) @ 2048 kbps < 500 ms at 6dB Eb/No ±100 ppm min Clock Tracking Range order Butterworth, group delay equalised (INTELSAT IESS Receive Filtering compliant) P300H P300 Series Modem Installation and Operating Handbook Page 25...
Page 26 7.3dB BER performance with concatenated RS BER improvement depends on n and k values chosen, but a typical increase in coding gain of 3dB is possible over basic Viterbi mode. P300H P300 Series Modem Installation and Operating Handbook Page 26...
Page 27 (T1/E1). Buffer storage is 32kBytes, so above 2.6 Mbps max buffer size reduces linearly from 99 ms to 52ms at 5.0Mbps Framing & Deframing Closed Network (unframed) Formats P300H P300 Series Modem Installation and Operating Handbook Page 27...
Page 28 (7 in 126 = 5.5% and 4 in 64 = 6.25% respectively), with similar overheads (126/112=12.5%, 64/56=14.3%), but with interleaving & decoder delays reduced from 5632 to 3104 bits (156 ms to 85 ms at 32 kbps). P300H P300 Series Modem Installation and Operating Handbook Page 28...
Page 29 For T1-D4 and T1-ESF RBS the IBS or Closed Net plus ESC overheads maintain the identity of the in band signalling, and it is re-inserted into the terrestrial multiframe in the correct positions to maintain the RBS. P300H P300 Series Modem Installation and Operating Handbook Page 29...
Page 30 M&C port (software selected). No external cabling required between the ESC and M&C ports for M&C via ESC channel within overhead. Other devices externally wired in parallel with M&C port can also be P300H P300 Series Modem Installation and Operating Handbook Page 30...
Page 31 Test Patterns Display of error count & average BER Results Automatic logging of average and 1 minute worst case BER at user Autolog specified intervals (1 min - 24 hours) P300H P300 Series Modem Installation and Operating Handbook Page 31...
Page 32: Common Specifications
Common Specifications Interface Loop (local & remote) Loopbacks Drop/Insert Loop (local) Framer Loop (local) P300H P300 Series Modem Installation and Operating Handbook Page 32...
Page 33 (P314). Provides control of BUC from modem front panel or by remote M&C via normal modem M&C ports. Includes control and monitoring of all BUC parameters available over FSK, and option to provide closed loop power control to BUC flange. P300H P300 Series Modem Installation and Operating Handbook Page 33...
Page 34 Environmental Operating temperature range 0 to 50C Supporting Products The P300 Series are supported by the following products: P500 series 1:8 redundancy controller, which includes the facility to mix electrical interfaces within redundancy group Alphawave CAM Monitor & Control software allows monitor and control of many different products (including non-Paradise products).
Page 35 P300 Modem Series, Error Probability versus Eb/No - Viterbi Decoding. P300H P300 Series Modem Installation and Operating Handbook Page 35...
Page 36 P300 Modem Series, Error Probability versus Eb/No - Sequential Decoding at 64kbps P300H P300 Series Modem Installation and Operating Handbook Page 36...
Page 37 P300 Modem Series, Error Probability versus Eb/No - Sequential Decoding at 2048kbps. P300H P300 Series Modem Installation and Operating Handbook Page 37...
Page 38 P300 Modem Series, Error Probability versus Eb/No - 8PSK/TCM with/without Reed-Solomon. P300H P300 Series Modem Installation and Operating Handbook Page 38...
Page 39 P300 Modem Series, Error Probability versus Eb/No – 1 Generation Turbo Codec. P300H P300 Series Modem Installation and Operating Handbook Page 39...
Page 40 Rx 70.000 MHz 1.00E-03 Scrambling: Normal (Turbo) Input Level: -45 dBm 1.00E-04 1.00E-05 1.00E-06 1.00E-07 Rate 1/2 Rate 7/8 Spec Limit Spec Limit 1.00E-08 Rate 3/4 Spec Limit 1.00E-09 EbNo P300H P300 Series Modem Installation and Operating Handbook Page 40...
Page 41 Rate: 2048kHz 8PSK Tx: 70.000 MHz Rx 70.000 MHz Scrambling: Normal 1.00E-03 (Turbo) Input Level: -45 1.00E-04 1.00E-05 1.00E-06 1.00E-07 Rate 3/4 Rate 7/8 Spec Limit Spec Limit 1.00E-08 1.00E-09 EbNo P300H P300 Series Modem Installation and Operating Handbook Page 41...
Page 42: Installation And Configuration
Carrier immediately and submit a damage report. Carefully unpack all items, taking care not to discard packing materials, particularly the moulded foam inserts. Should the unit need to be returned to Paradise Datacom, USE THE ORIGINAL PACKING CARTON. This is the only approved shipping container that Paradise recognises.
Page 43: Menu System
Make use of the Rx=Tx option, it s great, it cuts down configuration errors, and generally makes life easy. At least read the note on Rx=Tx in section 6.7 on page 89 so you know what you are missing ! P300H P300 Series Modem Installation and Operating Handbook Page 43...
Page 44: Menu Structure Diagrams
For example the option to raise a deferred alarm if the distant Eb/No falls below a certain level (shown on the diagrams as [DISTANT Eb/No]-Option: AUPC) requires the AUPC feature to be available and switched on before the menu option is shown. P300H P300 Series Modem Installation and Operating Handbook Page 44...
Page 45: Menu Structure Sheet 1 / 7 (Main: Status, Change)
6.2.1 Menu Structure Sheet 1 / 7 (Main: Status, Change) P300H P300 Series Modem Installation and Operating Handbook Page 45...
Page 46: Full Menu Structure Sheet 2 / 7 (Main: Monitor, Info)
6.2.2 Full Menu Structure Sheet 2 / 7 (Main: Monitor, Info) P300H P300 Series Modem Installation and Operating Handbook Page 46...
Page 47: Full Menu Structure Sheet 3 / 7 (Main: Log, Test, Setup, Action, Help)
6.2.3 Full Menu Structure Sheet 3 / 7 (Main: Log, Test, Setup, Action, Help) P300H P300 Series Modem Installation and Operating Handbook Page 47...
Page 48: Full Menu Structure Sheet 4 / 7 (Main, Change, User-Opt, Operation)
6.2.4Full Menu Structure Sheet 4/7 (Main, Change, User-Opt, Operation) P300H P300 Series Modem Installation and Operating Handbook Page 48...
Page 49: Full Menu Structure Sheet 5 / 7 (Change, Tx)
6.2.5 Full Menu Structure Sheet 5 / 7 (Change, Tx) P300H P300 Series Modem Installation and Operating Handbook Page 49...
Page 50: Full Menu Structure Sheet 6 / 6 (Change, Rx)
6.2.6 Full Menu Structure Sheet 6 / 6 (Change, Rx) P300H P300 Series Modem Installation and Operating Handbook Page 50...
Page 51: Full Menu Structure Sheet 7 / 7 (Change, Buc/Lnb)
6.2.7 Full Menu Structure Sheet 7 / 7 (Change, BUC/LNB) P300H P300 Series Modem Installation and Operating Handbook Page 51...
Page 52: Status Screen Display
Traffic Status Summary Screen (shown second above) when Status is selected from the main menu. The selection between screens is made under . These screens are now each discussed in turn: P300H P300 Series Modem Installation and Operating Handbook Page 52...
Page 53 Cfg-Info Traf-Fault A Traffic Fault exists A Traffic Warning exists Traf-Warn Remote Remote M&C mode, no warnings or test modes active. Local mode, no warnings or test modes active. Local P300H P300 Series Modem Installation and Operating Handbook Page 53...
Page 54 (as opposed to the one line message on the Status Traffic Summary Screen). Pressing down again selects the Transmit Detailed Traffic tatus. P300H P300 Series Modem Installation and Operating Handbook Page 54...
Page 55 From this screen the Down Arrow ads back to the selected Status screen. (Back to the selected Status Screen, `Config Summary` or `Tx & Rx Traffic Summary`) P300H P300 Series Modem Installation and Operating Handbook Page 55...
Page 56: Setup - Initial Configuration Menu
Change Screen (Remote M&C): Change limited as Remote M&C active ! Change: 1:Rem M&C 2:Time/Date Change Menu (remote M&C) Each of these options will be described in the following sections: P300H P300 Series Modem Installation and Operating Handbook Page 56...
Page 57: Change, Tx Menu
Refer to the section "IBS/SMS Service Features" in Appendix F on page 212 for a full description of IBS/SMS features. The Tx path operates in IDR mode, where a 96kbps framing overhead is added P300H P300 Series Modem Installation and Operating Handbook Page 57...
Page 58: Change, Tx/Rx, Service, Closed Network
Main data rate. Async ESC Baud Rate, Character length and Parity. Backward Alarm option (ie both enabled or both disabled). P300H P300 Series Modem Installation and Operating Handbook Page 58...
Page 59 ESC, lowering the total overhead marginally. See "Overhead Rates" in section 8.7.1 on page 149 for details of the overhead percentage requirements for differing mixes of main data and async ESC data rates. P300H P300 Series Modem Installation and Operating Handbook Page 59...
Page 60: Change, Tx/Rx, Baseband Menu
IDR frame, so that the distant receive equipment may arbitrarily re-order the timeslots. Refer to section 7.3.1 "Change, Tx/Rx, Baseband, Continuous, 2048k Menu (IDR)" on page 141 for the P300H P300 Series Modem Installation and Operating Handbook Page 60...
Page 61: Change, Tx/Rx, Baseband, Drop/Insert Menu
NOTE: If the Extended D/I feature is available (standard on P300-TCM) timeslots can be arbitrarily re- ordered, and so group selections may be down as well as up eg 11-17 means send in order P300H P300 Series Modem Installation and Operating Handbook Page 61...
Page 62 TS16 does not contain CAS (ie a terrestrial CAS multiframe and `abcd` signalling nibbles for each timeslot). It is simply treated as a normal data timeslot and may be dropped / inserted as with any other timeslot. P300H P300 Series Modem Installation and Operating Handbook Page 62...
Page 63 RBS are replaced into the same relative positions within the terrestrial multiframe by the insert mux, in order to preserve the RBS. P300H P300 Series Modem Installation and Operating Handbook Page 63...
Page 64 Timeslot ID will not be maintained and the Modem will be compatible with other manufacturers equipment for these `Odd values of N`. This is the end of the Drop/Insert dialogue when in modes P300H P300 Series Modem Installation and Operating Handbook Page 64...
Page 65: Change, Tx/Rx, Baseband, Other Menu
Closed Net Plus ESC, IBS or Custom IBS overhead is required in order to maintain the timeslot ID and hence keep the channels separate in order for this to function. Normal clocking selections are available. P300H P300 Series Modem Installation and Operating Handbook Page 65...
Page 66: Change, Tx, Clocking Menu
6.6.7 Change, Tx, CLOCKING Menu Paradise Datacom products have always provided a `Data Marginal` warning where the incoming data phase is monitored with respect to the clock. The Modem shows a `Data Marginal` warning on the front panel if the data changes at the instant where it should be stable (and is sampled by the modem) which would otherwise cause data errors with no fault indication.
Page 67 Station Clock again if there is one or the Internal 1PPM ref if not. So this option really is only of any practical use when the Rx Clocking is set to P300H P300 Series Modem Installation and Operating Handbook Page 67...
Page 68: Change, Tx, Modulator Menu
8PSK: TCM only at rate 2/3 See the OQPSK primer below, and also refer to Appendix E Fault Mode 12" for interworking OQPSK between early and later P400 series modems. P300H P300 Series Modem Installation and Operating Handbook Page 68...
Page 69: Offset Qpsk (Oqpsk) Primer
1/2 rate or 3/4 rate FEC (increasing the data rate by factors of 2 and 4/3 respectively). The operator is warned of unusual combinations of Modulation and FEC type/code rate when is requested. P300H P300 Series Modem Installation and Operating Handbook Page 69...
Page 70 (which offer a better 7/8 rate performance at the cost of significant latency). If you`re stuck with a channel that can only accommodate 7/8 Rate FEC, then this will give you an extra dB over using Viterbi. P300H P300 Series Modem Installation and Operating Handbook Page 70...
Page 71: Change, Tx/Rx, Mod/Demod, Reed-Solomon Menu
Interleaving is usually of depth 4 or depth 8. The configuration menus are described in the following paragraphs. See also the applications section, para 8.4 "Choosing Optimum Custom RS N&k Values" on page 146 P300H P300 Series Modem Installation and Operating Handbook Page 71...
Page 72: Change, Tx/Rx, Mod/Demod, Scrambler Menu
See the applications section, para 8.4 "Choosing Optimum Custom RS N&k Values" on page 146 6.6.13 Change, Tx/Rx, Mod/Demod, SCRAMBLER Menu Scrambler: [?] 1=Off 2=Normal 3:Other Change, Tx/Rx, Mod/Demod, Scrambler Menu P300H P300 Series Modem Installation and Operating Handbook Page 72...
Page 73 INTELSAT mode as this is the most common. Refer also to section 8.9 on page 154 which describes in more detail the different scramblers, and interworking between manufacturers. P300H P300 Series Modem Installation and Operating Handbook Page 73...
Page 74: Change, Tx, Modulator, Carrier Menu
BUC, varying the Tx Carrier level and BUC attenuator to provide the desired power. Power from BUC (13-33), now [31]dBm 1:Set new power 2:Nudge up/down Change, Tx, Modulator, Power Menu (Terminal with BUC) P300H P300 Series Modem Installation and Operating Handbook Page 74...
Page 75: Change, Tx/Rx, Modulator, Spectrum Invert Menu
Change, Tx, Modulator, AUPC Menu Note that options 2 through 7 only display when the AUPC mode It is set to other than , so initially only AUPC: 1:Mode may be displayed. P300H P300 Series Modem Installation and Operating Handbook Page 75...
Page 76: Change, Tx, Modulator, Aupc Mode Menu
Note also that the distant modem must be set for remote reporting of Eb/No with 6.6.19 Change, Tx, Modulator, AUPC, MAX Menu Set AUPC max positive delta power [3.5dB] (0-25.0dB) ??.?dB (Yes) Change, Tx, Modulator, AUPC, Max Menu P300H P300 Series Modem Installation and Operating Handbook Page 76...
Page 77: Change, Tx, Modulator, Aupc, Min Menu
AUPC system responding to rapid fades (eg 10dB fade in 10 seconds). 6.6.22 Change, Tx, Modulator, AUPC, TARGET EB/NO Menu Set target Eb/No to maintain: [8.5]dB (0 to 25.0dB) ??.?dB (Yes) Change, Tx, Modulator, AUPC, Target Eb/No Menu P300H P300 Series Modem Installation and Operating Handbook Page 77...
Page 78: Change, Tx, Modulator, Aupc, Tolerance Menu
The AUPC delta power It is reset to zero so the carrier returns to its nominal power. The AUPC delta power increases to the maximum power limit as set on the AUPC Max positive delta power screen. P300H P300 Series Modem Installation and Operating Handbook Page 78...
Page 79: Change, Tx/Rx, Esc/Aux/Ba Menu
When operating in IDR or Custom IDR modes, the Define selection is as follows: IDR 8k ESC: [?] 1=Off 2=Sync 3=Async Change, Tx/Rx, ESC/Aux/BA, Define (IDR), ESC Menu The ESC port is disabled (and all ones is sent in the 8k ESC channel) P300H P300 Series Modem Installation and Operating Handbook Page 79...
Page 80 Audio ESC V2 operates as normal, and the Aux port provides a 32kbps channel in V1. Audio ESC V1 operates as normal, and the Aux port provides a 32kbps channel in V2. P300H P300 Series Modem Installation and Operating Handbook Page 80...
Page 81: Change, Tx/Rx, Esc/Aux/Ba, Define (Ibs) Menu
ESC channel is to link it to the M&C port of the Modem (software controlled internal link), and provide remote M&C of the distant equipment from the local end of the link. P300H P300 Series Modem Installation and Operating Handbook Page 81...
Page 82 ESC Baud rate defined, then setting the ESC to maximises the proportion of the overhead available to the ESC, and lowers the overhead addition to the minimum possible. P300H P300 Series Modem Installation and Operating Handbook Page 82...
Page 83: Custom Ibs Overhead Allocation
This bit can only be allocated to the ESC. TS32 bit 4 is 1/32nd of the overhead and is normally used for the Satellite TS32 Multiframe but is spare P300H P300 Series Modem Installation and Operating Handbook Page 83...
Page 84: Change, Tx/Rx, Esc/Aux/Ba, Async Esc Menu
ESC port for remote M&C. This is a one time copy, and the ESC port configuration will not track changes to the remote M&C configuration. When the ESC port is configured as the remote M&C port, [=] P300H P300 Series Modem Installation and Operating Handbook Page 84...
Page 85: Change, Tx/Rx, Esc/Aux/Ba, Config Async, Baud Rate Menu
NOTE: ESC channel not guaranteed above 2962 Baud (YES) Change, Tx/Rx, ESC/Aux/BA, Set as Remote Warning Menu P300H P300 Series Modem Installation and Operating Handbook Page 85...
Page 86: Change, Tx/Rx, Esc/Aux/Ba, Interfaces Menu
Tx ESC channel and back via the satellite link. Aux Interface Following the ESC interface selection the Aux port may be configured (self explanatory): Aux Interface: [RS232] 1=RS232 2=RS422 Change, Tx/Rx, ESC/Aux/BA, Cfg Interfaces, Aux Menu P300H P300 Series Modem Installation and Operating Handbook Page 86...
Page 87: Change, Tx/Rx, Esc/Aux/Ba, Audio Levels Menu
Pressing the up/down keys slowly/rapidly causes the level to change in 0.1dB steps, rapidly in 0.5dB steps. must be pressed to exit the screen otherwise the previous values will be restored. P300H P300 Series Modem Installation and Operating Handbook Page 87...
Page 88: Change, Tx/Rx, Esc/Aux/Ba, Backward Alarms Menu
All four alarms represent the internal Rx Fail signal. Used in non multidestinational working, external backward alarm inputs are ignored. In non multidestinational operation, the choice between the third and fourth options is down to operator preference or station policy. P300H P300 Series Modem Installation and Operating Handbook Page 88...
Page 89: Change, Rx Menu
Insert Mux will be active and the operator needs access to the baseband menu in order to independently set the insert TS selection. The Buffer/Clocking menu is always shown. The Demod menu provides access to the independent selection of IF Frequency, and demod Sweep Width control P300H P300 Series Modem Installation and Operating Handbook Page 89...
Page 90: Change, Rx, Service Menu
Rx=Tx is , when Rx=Tx is (ie a symmetrical link, which is by definition unlikely to be multi-destinational) Partial Insert makes no sense, and the option is not displayed. P300H P300 Series Modem Installation and Operating Handbook Page 90...
Page 91 Change, Tx, Baseband menu. The total number of timeslots inserted must match the number of 64kbps channels selected for this destination on the `Sat TS` screen above. P300H P300 Series Modem Installation and Operating Handbook Page 91...
Page 92: Change, Rx, Buffer/Clocking Menu
180Hz when the IF is tuned to 180MHz. However if this option is used please be aware that the transmit IF spectrum purity is entirely dependent upon the quality (phase noise performance) of the supplied reference. P300H P300 Series Modem Installation and Operating Handbook Page 92...
Page 93: Change, Rx, Buffer / Clocking, Rx Clock Menu
This is normal `Plesiochronous Mode`, and the buffer should be set large enough to accommodate both the difference in the clocks at each end of the link PLUS the Doppler shift, whilst providing the required interval between slips. P300H P300 Series Modem Installation and Operating Handbook Page 93...
Page 94: Change, Rx, Buffer/Clocking, Buffer Size Menu
8.1 "Doppler & Plesiochronous Buffering" on page 142 8.2 "Determining Clocking Schemes & Buffer Size" on page 143 Buffer size (end-end): [16]ms (0-99ms) ??ms (YES) Change, Rx, Buffer/Clocking, Buffer Size Menu P300H P300 Series Modem Installation and Operating Handbook Page 94...
Page 95 With typical earth station clock accuracies, buffers never need be larger than approximately 16ms. The buffer can be manually centred by selecting P300H P300 Series Modem Installation and Operating Handbook Page 95...
Page 96: Change, Rx, Demod Menu
6.7.12 Change, Rx, Demod SCRAMBLER Menu See Change, Tx/Rx, Modulator, Scrambler Menu on page 72 6.7.13 Change, Rx, Demod SPECTRUM INVERT Menu See Change, Tx/Rx, Modulator, Spectrum Invert Menu on page 75 P300H P300 Series Modem Installation and Operating Handbook Page 96...
Page 97: Change, Rx, Demod Sweep Menu
BPSK, QPSK, and 8PSK respectively. In such a case, the `Normal` sweep width is automatically narrowed to within these limits, to make the sweeping Demod avoid any false locks (assuming the Rx carrier is exactly on frequency). P300H P300 Series Modem Installation and Operating Handbook Page 97...
Page 98: Change, Rx, Demod Aupc Menu
Note: Temporarily setting Rx=Tx is a convenient way of copying the Tx configuration to the Rx as when disabled again the Rx path keeps the Tx values, and does not return to the old Rx values. P300H P300 Series Modem Installation and Operating Handbook Page 98...
Page 99: Change, Terr-Intfc Menu
For the first three options the dialogue terminates here, for G.703 it proceeds to the line code selection: Set G.703 line code: [?] 1=AMI 2=HDB3 (Normal) Change, Terr-Intfc, Electrical Menu, Line Code (if G.703) P300H P300 Series Modem Installation and Operating Handbook Page 99...
Page 100: Change, Terr-Intfc, Control Lines
The three following screens are presented in turn allowing each line to be individually controlled. The line names change to match the interface type selected (examples here are for V.35). P300H P300 Series Modem Installation and Operating Handbook Page 100...
Page 101: Change, Terr-Intfc, Card Specific
These screens are used for interfaces, which have interface specific requirements such as the 64kbps G.703 interface. With the standard P1440 interface this option is not shown on the Change, Terr-Intfc menu. P300H P300 Series Modem Installation and Operating Handbook Page 101...
Page 102: Change, Rem-M&C Menu
The subsequent timeout menu is as follows, its function is described above: Rem M&C timeout before user can take local control: [120s] (1-255secs) ???s (YES) Service, Factory Parameters, Remote M&C Timeout Menu P300H P300 Series Modem Installation and Operating Handbook Page 102...
Page 103: Change, Rem-M&C, Configure Menu
The bus address must be specified. The valid range for the Paradise / FDC protocol is 1-255, for the SA-bus protocol the valid range of address is 49 to 111 (31H to 6FH). P300H P300 Series Modem Installation and Operating Handbook Page 103...
Page 104: Change, User-Opt Menu
The operator has control over many parameters, which are the subject of either personal or company preference. A single menu choice resets these to the Paradise Defaults, which are listed in the following paragraphs along with each parameter. P300H P300 Series Modem Installation and Operating Handbook Page 104...
Page 105: Change, User-Opt, Operation, Actions Menu
6.10.4 Change, User-Opt, Operation, TERRESTRIAL Menu Terrestrial: 1:PCM Bearer CRC BER monitors: 2:Tx/Drop mux 3:Insert mux Change, User-Opt, Operation, Terrestrial Menu This option is only applicable when the unit is configured for Drop/Insert P300H P300 Series Modem Installation and Operating Handbook Page 105...
Page 106: Change, User-Opt, Operation, Terrestrial, Pcm Bearer Crc Menu
Drop/Insert frame sync if CRC sync cannot be achieved within 8ms. Options available are Default: 6.10.6 Change, User-Opt, Operation, SATELLITE Menu Satellite: 1:BER est 2:IBS MF period 3:Carrier ID s 4:Back alm map 5:IF-50/75 Change, User-Opt, Operation, Satellite Menu P300H P300 Series Modem Installation and Operating Handbook Page 106...
Page 107 This option allows the four alarms to be mapped in different ways onto the IBS TS32 multiframe, in the hope that should INTELSAT adopt such a standard, the P300 Modems could be set to be P300H P300 Series Modem Installation and Operating Handbook Page 107...
Page 108: Change, User-Opt, Operation, Terr/Sat Menu
Refer to section 7.2 "Change, Tx/Rx, Baseband, Continuous, 2048k Menu (IBS)" on page 139 for further information on operation in this mode. Options are Default: P300H P300 Series Modem Installation and Operating Handbook Page 108...
Page 109: Change, User-Opt, Operation, Alarms Menu
0-15 at this menu. The full list of options available are described in Appendix E on page 207. Default: 0 (standard AGC voltage). P300H P300 Series Modem Installation and Operating Handbook Page 109...
Page 110: Change Time/Date Menu
This screen is only available on P310 L-Band modems. BUC Attached:[?] 1=None 2=Other 3=Std Ku 4=Ext Ku 5=Std C 6=INSAT C 7=PALAPA C Change, BUC/LNB, Tx/BUC, BUC Type Menu 1 P300H P300 Series Modem Installation and Operating Handbook Page 110...
Page 111 , these options are not available. If a Paradise BUC is fitted then the following screen is displayed: Modem/BUC control mode: [?]1=Independent 2=Terminal (Closed Loop) Change, BUC/LNB, Tx/BUC, BUC Type Menu 2 P300H P300 Series Modem Installation and Operating Handbook Page 111...
Page 112 Terminal mode, where the Tx power is varied to maintain a steady level at the BUC flange, is NOT compatible with AUPC which requires the Tx power to vary to meet receive criteria. P300H P300 Series Modem Installation and Operating Handbook Page 112...
Page 113: Change, Buc/Lnb, Tx/Buc, Dc & References Menu
Freq shift of upconverter:[13050 MHz] (0-65535MHz) ??.??? (YES) Change, BUC/LNB, Tx/BUC, SHF Frequency Menu 2 Once set all Tx IF frequencies displayed or edited include the frequency shift of the BUC or upconverter chain. P300H P300 Series Modem Installation and Operating Handbook Page 113...
Page 114: Change, Buc/Lnb, Tx/Buc, Shf Power/Units Menu
IF IN DOUBT, always start with the MINIMUM modem Tx Carrier level and the MAXIMUM BUC attenuator setting. The second line of this screen reports the actual power measured by the BUC. P300H P300 Series Modem Installation and Operating Handbook Page 114...
Page 115: Change, Buc/Lnb, Rx/Lnb Menu
SHF frequency. Note however that with the LNB Type set to , there is no way to manually enter a SHF offset which uses a High Side LO. P300H P300 Series Modem Installation and Operating Handbook Page 115...
Page 116: Change, Buc/Lnb, Rx/Lnb, Dc & References Menu
SHF frequency received would be LO - IF Frequency (unlike the situation where the modem is told it has a Std C band LNB, and knows that a high side LO is used). P300H P300 Series Modem Installation and Operating Handbook Page 116...
Page 117: Change, Buc/Lnb, Tune Ref Menu
This is the measured error rate into the Reed-Solomon decoder (from the FEC, unless operating uncoded). The difference between this and the To FEC figure shows the improvement due to the Inner FEC. P300H P300 Series Modem Installation and Operating Handbook Page 117...
Page 118: Monitor, Terrestrial Ber Menu
AUPC in section 8.11 on page 156). In these modes the Eb/No and BER from the distant modem are brought across the satellite link by the AUPC, and are available for display on the local modem (and automatic timed entries to the traffic log if required). P300H P300 Series Modem Installation and Operating Handbook Page 118...
Page 119: Monitor, Aupc Menu
This may be either: None, Other, Std Ku, Ext Ku, Std C, INSAT C, or PALAPA C If the BUC is from Paradise Datacom and the modem is fitted with the FSK communication option, then significantly more information is available on this and subsequent screens. On this screen:...
Page 120: Info Menu
`Feature Code`. Refer to Appendix C for further details. This menu is only available on the P310 L-Band modem. It provides information on the current BUC & LNB connected P300H P300 Series Modem Installation and Operating Handbook Page 120...
Page 121: Log Menu
This may be either: None, Other, Std Ku, Ext Ku, Std C, INSAT C, or PALAPA C BUC Type If the BUC is from Paradise Datacom and the modem is fitted with the FSK communication option, then more information is available on this and subsequent screens. On this screen: Software Ver: The version of software in the BUC.
Page 122 Finally, if AUPC is active (see AUPC in section 8.11 on page 156), another subsequent screen is offered: Autolog (Y/N): 1:AUPC Delta Power (Y) 2:Distant end Eb/No (N) Back Log Autolog, Measurements Menu (3:AUPC) P300H P300 Series Modem Installation and Operating Handbook Page 122...
Page 123 Please note that each data type logged uses up one log entry every Autolog period (ie the log capacity can be consumed quickly with multiple events logged at very regular intervals). P300H P300 Series Modem Installation and Operating Handbook Page 123...
Page 124: Test Menu
The Tx IF Level needs to be set to above -10dBm for the loopback to function reliably. Do NOT change the Tx IF Level for a loopback if the modem is still on satellite! Cont d..P300H P300 Series Modem Installation and Operating Handbook Page 124...
Page 125 This provides a loop of the Rx data after the deframer back into the framer. Tx input data is ignored, Rx traffic continues as normal. Incoming ESC & Aux channel data is not looped back to the remote site. P300H P300 Series Modem Installation and Operating Handbook Page 125...
Page 126: Test, Rf & Fec Menu
0C and 60C. Should the internal temperature exceed the limits of 0C and 60C, then a Unit Fault / Prompt Alarm is activated. The Tx carrier is muted outside the operating temperature range. P300H P300 Series Modem Installation and Operating Handbook Page 126...
Page 127: Test, Int' Bert Menu
This disables the internal BER Tester, removing it from the channel in use, ie the Main, ESC, or Aux channel, restoring normal operation. P300H P300 Series Modem Installation and Operating Handbook Page 127...
Page 128: Test, Int' Bert, Off/Channel Menu
IBS/SMS mode for the BER test to run through if the Async ESC feature is available (standard on P300-IBS and above). The ESC channel may be configured to provide rates up to 4.6% of the main data rate for BER testing. P300H P300 Series Modem Installation and Operating Handbook Page 128...
Page 129 IDR overhead of 96kbps together with 16kbps ADPCM for the audio ESC's, it may provide all the normal IDR features, but with the second 32kbps audio slot free to configure as a 32kbps Aux channel for continuous BER testing. P300H P300 Series Modem Installation and Operating Handbook Page 129...
Page 130: Test, Int' Bert, Pattern Menu
(when sync is recovered). Manual mode allows the operator to manually start, stop & restart tests which may run for up to 27 hours (99,999 seconds), at which point the results are frozen. P300H P300 Series Modem Installation and Operating Handbook Page 130...
Page 131: Test, Int' Bert, Results Menu
PRBS with an external Firebird, there will be a <0.1% discrepancy in the error count, but NOT the BER. For the purists amongst you, and so you do not question the accuracy of the Internal BERT, the briefest useful explanation possible is as follows: P300H P300 Series Modem Installation and Operating Handbook Page 131...
Page 132: Setup Menu
This resets the counts of underflows and overflows on the status screens When two Modem's are configured as a 1:1 pair, this can be selected on the on-line unit, to handover control to the off-line unit. P300H P300 Series Modem Installation and Operating Handbook Page 132...
Page 133: Help Menu
SERVICE MENU The service menu is available by selecting 0 from the main menu. It provides options not normally required when configuring the Modem. Service: 1:User Parameters 2:Factory parameters Service Menu P300H P300 Series Modem Installation and Operating Handbook Page 133...
Page 134: Service, User Parameters Menu
Testing the Watchdog timer therefore will cause the unit to reset, and corrupt both Tx and Rx traffic for a few seconds. P300H P300 Series Modem Installation and Operating Handbook Page 134...
Page 135: Menu Screens For Specialist Options
TS32 MF acquisition may take 1 second on top of demod lock time. This selection also frees up one additional bit of the overhead (TS32 bit 4) to carry ESC information. P300H P300 Series Modem Installation and Operating Handbook Page 135...
Page 136 This final option is the most powerful of the features in Custom IBS. The standard 16/15 (6.7%) IBS/SMS overhead is used. The ESC rate available is a fixed proportion of the main data rate (but may be manipulated within limits P300H P300 Series Modem Installation and Operating Handbook Page 136...
Page 137: Change, Tx/Rx, Service, Custom, Idr Menu
The 12 bit overhead defined for T1/E1 operation in IESS 308 is used. The 4 bit overhead on each of three subframes defined for T2/E2 operation is used. Whichever format is selected, the following prompt appears: P300H P300 Series Modem Installation and Operating Handbook Page 137...
Page 138 64kbps comprising 32kbps for [FAS + Back Alarms + 8K sync ESC channel] plus 32kbps containing the two 16kbps ADPCM audio channels. The final 32kbps defined for Audio ESC channel 2 is not transmitted. P300H P300 Series Modem Installation and Operating Handbook Page 138...
Page 139: Ibs/Sms Operation With 2048Kbps Continuous Data
1984kbps in the service definitions. This feature is only available if the Extended D/I feature is available (standard on P300-TCM). TS16 contains CAS and by implication a terrestrial multiframe P300H P300 Series Modem Installation and Operating Handbook Page 139...
Page 140 The Modem hardware is capable of duplication and omission of timeslots, although for simplicity the operator interface (described above) does not allow such selections. If this is a requirement, please contact the factory to discuss your needs. P300H P300 Series Modem Installation and Operating Handbook Page 140...
Page 141: Custom Idr Operation With 2048Kbps Continuous Data
This selection leads onto a screen identical to that for IBS G.732 re- ordering (as described in the previous section for IBS G.732 operation on page 140) which allows the timeslots to be arbitrarily re-ordered prior feeding to the terrestrial output. P300H P300 Series Modem Installation and Operating Handbook Page 141...
Page 142: Application Notes
With typical earth station clock accuracies, buffers never need be larger than approximately 16ms. P300H P300 Series Modem Installation and Operating Handbook Page 142...
Page 143: Determining Clocking Schemes And Buffer Size
If there is no clock loop, then both ends need the Buffer active to cope with the normal Doppler effect, plus the plesiochronous effect (ie the difference between the clocks at each end). Apply the following rules to both ends: P300H P300 Series Modem Installation and Operating Handbook Page 143...
Page 144: Determining Buffer Size
So using the example figures above gives 0.00898 seconds, so 9ms is required to absorb the plesiochronous effects. To this you must add any Doppler requirement (ie 2ms for each satellite hop). P300H P300 Series Modem Installation and Operating Handbook Page 144...
Page 145: Partial Insert And Multidestinational Working
Partial Insert becomes mandatory for multidestinational working when the total receive data at any one destination exceeds the capacity of the PCM bearers. One final note: The P300 Series can provide multidestinational operation at aggregate carrier rates below 1544 kbps using the IBS overhead, but with four backward alarms. So multidestinational working down to 64kbps between nodes become practical (ie you don't have to use the 96kbps IDR overhead on the links to get multidestinational backward alarm facilities).
Page 146: Choosing Optimum Custom Values Of Rs N&K
(254,250,2) (202,182,10) (115,95,10) (204,200,2) (187,167,10) (111,91,10) (206,200,3) (174,154,10) (107,87,10) (208,200,4) (163,143,10) (103,83,10) (210,200,5) (153,133,10) (100,80,10) (247,233,7) (145,125,10) (97,77,10) (245,229,8) (138,118,10) (94,74,10) (243,225,9) (131,111,10) (91,71,10) (242,222,10) (125,105,10) (89,69,10) (220,200,10) (120,100,10) (87,67,10) P300H P300 Series Modem Installation and Operating Handbook Page 146...
Page 147: Notes On Data Rates & Symbol Rates
Drop/Insert is active the Data Rate is 64kbps times the number of timeslots dropped/Inserted. As the P300 Series Modem use PSK (Phase Shift Keying) the Symbol Rate is the rate of phase changes on the I.F. signal. Each phase change represents a new symbol to the demodulator, and depending on the modulation scheme that symbol may convey one (BPSK), two (QPSK), or three (8PSK) bits of information.
Page 148: Determining Exact Maximum Esc Baud Rates
So when set for [8 bits No Parity] or [7 bits with Parity] the maximum standard Baud rate is 4800 Baud. When set for [8 bits with Parity] the maximum standard Baud rate is 9600 Baud. P300H P300 Series Modem Installation and Operating Handbook Page 148...
Page 149: Closed Network Plus Esc
1/Nth increments (eg 1/1=100%, 1/2=50%, 1/3=33%, 1/4=25% etc up to 1/256=0.39%) and so the modem must pick the appropriate value of N, which provides at least the required async ESC Baud rate. P300H P300 Series Modem Installation and Operating Handbook Page 149...
Page 150: Closed Network Plus Esc Via The Custom Service Menu
ESC channel to cause a delay in transmission of up to 3 characters (as if they were `stuck in the pipe`), which only appear out of the ESC channel when `pushed through` by subsequent P300H P300 Series Modem Installation and Operating Handbook Page 150...
Page 151 As the modems at each end of the link are simply operating as set, and don t know that the configurations are mis matched, it is not possible to automatically prevent or recover from such a configuration. P300H P300 Series Modem Installation and Operating Handbook Page 151...
Page 152: Cross Reference To Sdm300 D/I & Framing Modes
8.8 CROSS REFERENCE TO SDM300 D/I & FRAMING MODES. The P300 Series Modems are equipped with the Drop/Insert and possibly the Extended Drop/Insert features can provide all the Drop/Insert functions of competing equipment such as the SDM300. If you are familiar with the modes the SDM300 offers then here is a cross reference, along with the menu...
Page 153 Simply configure as for T1_ESF & T1_ESF_S as above, but select T1-D4 not T1-ESF in step 2 T1_IBS: 1544kbps in the same bandwidth as Normal 1536kbps IBS This is the standard INTELSAT definition for non Drop/Insert 1544kbps over IBS. 1. Select 2. Select P300H P300 Series Modem Installation and Operating Handbook Page 153...
Page 154: Scramblers
INTELSAT V.35 implementations, but in order to maintain backwards compatibility they support their original V.35 attempts as well. To maximise compatibility with other manufactures equipment, in addition to both INTELSAT and CCITT, Paradise modems implement two of these other P300H P300 Series Modem Installation and Operating Handbook Page 154...
Page 155: Interworking Different Manufacturers Equipment
(true data but poss invert, QPSK is OK invert) error rate) Sequential requires P300 Rx spectrum invert in BPSK and both Tx & Rx spectrum invert in QPSK. See Appendix E: FaultMode=11 P300H P300 Series Modem Installation and Operating Handbook Page 155...
Page 156: Introduction To Aupc (Automatic Uplink Power Control)
ESC channel (which is carried over the satellite multiplexed with the main data channel). For AUPC to operate an async ESC channel must be defined, and on the P300 Series this is available in Closed Network (Closed Net Plus ESC), IBS/SMS and IDR modes.
Page 157 + Limit only: Best performance: The power will increase when required by a fade bit it will not reduce. Any especially good atmospheric conditions will improve the Eb/No P300H P300 Series Modem Installation and Operating Handbook Page 157...
Page 158 Eb/No is read by the local odem in order to determine if any adjustment is necessary). AUPC will use a different proportion of the available ESC bandwidth depending on the E interface selected. P300H P300 Series Modem Installation and Operating Handbook Page 158...
Page 159: Configuring Aupc For Operation
For example the station M&C could be running at 9600 Baud, and the ESC channel set for 2400 Baud. The AU PC software will buffer and rate convert the M&C P300H P300 Series Modem Installation and Operating Handbook Page 159...
Page 160 Use the Autolog feature to optionally record the distant Eb/No and/or the AUPC delta power. This may prove useful in determining how often the AUPC is required, and if it manages to P300H P300 Series Modem Installation and Operating Handbook Page 160...
Page 161: Tutorial On Carrier/Noise & Eb/No Measurements
Because the data rate reduces through the FEC Decoder E is higher than E as the same power is referenced to a lower bit rate. Allowing for the change bit rate in the FEC decoder gives: (FEC Code Rate) P300H P300 Series Modem Installation and Operating Handbook Page 161...
Page 162: Practical Implications Of Displayed Eb/No
BER. Framing therefore does not degrade the BER for a stated E , but it does require more power (and bandwidth) to achieve the same P300H P300 Series Modem Installation and Operating Handbook Page 162...
Page 164: Tables To Convert (C+N)/N To Eb/No
16.5 16.40 17.0 16.91 17.5 17.42 18.0 17.93 18.5 18.44 19.0 18.94 19.5 19.45 >20 =(C+N) / N (error <0 .04dB) Example: 8SPK with 2/3 Rate TCM FEC, & RS=(219,201,9) P300H P300 Series Modem Installation and Operating Handbook Page 164...
Page 165 (C+N)/N= C/N= 8PSK so 2/3 Rate FEC, so add RS Code (219,201,9) so 8.4dB 7.72dB subtract 4.77dB 1.76dB add 0.37dB Measure Look up Calculate Eb/No = C/N - 2.64dB P300H P300 Series Modem Installation and Operating Handbook Page 165...
Page 166: 1 For 1 Operation
OK, (but only if the on-line unit has now failed, otherwise it would be an unnecessary changeover). Detected failures P300H P300 Series Modem Installation and Operating Handbook Page 166...
Page 167: Practical 1 For 1 Implementation
Rx fault as there is no carrier. When split/combined and looped testing will work, but it can still be difficult to `get your head round it`. It is much easier with no loopback and the 1:1 pair talking to a third modem. P300H P300 Series Modem Installation and Operating Handbook Page 167...
Page 168: Boot Code Operation
Waiting for flash memory to Erase / Boot, Erase Wait screen When the Flash has erased (which takes approximately 30 seconds) the screen changes to: P300H P300 Series Modem Installation and Operating Handbook Page 168...
Page 169: Other Boot Code Options
Reduce the functionality to P300-VSAT level (from a higher level only) Reduce the functionality to P300-IBS level (from a higher level only) Reduce the functionality to P300-IDR level (from a higher level only) P300H P300 Series Modem Installation and Operating Handbook Page 169...
Page 170: Appendix A: Data Interface Information
IT IS POSSIBLE TO FIT OTHER INTERFACES, and in fact the whole Paradise P14xx range can be utilised in the P300 series modem. However, prior to fitting another interface the case must be opened, the standard interface `snapped off` from the main PCB, and a 48 pin connector fitted to the main PCB to accept the plug in cards.
Page 171: P1440 In Rs422 Mode
P1440 IN RS422 MODE The P1440 is the standard interface supplied with the P300 Series Modem. If RS422 is selected under then the following interface description applies. Signal Description RS422 Circuit 25 pin 37 pin Electrical Name Number Levels DATA CIRCUIT TOWARDS MODEM (TX)
Page 172: P1440 In V.35 Mode
P1440 IN V.35 MODE The P1440 is the standard interface supplied with the P300 Series Modem. If V.35 is selected under then the following interface description applies. Signal Description V.35 Circuit 25 pin 37 pin Electrical Old Style Name Number...
Page 173: P1440 In Rs232 Mode
P1440 IN RS232 MODE The P1440 is the standard interface supplied with the P300 Series Modem. If RS232 is selected under then the following interface description applies. Signal Description RS232 Circuit 25 pin 37 pin Electrical Name Number Levels DATA CIRCUIT TOWARDS MODEM (TX)
Page 174: P1440 In G.703 Mode
P1440 IN G.703 MODE If the G.703 option is fitted to the P300 Series modem, then G.703 becomes a front panel / software selectable interface in addition to the standard RS422, V.35 and RS232 interfaces. If G.703 is selected under then the following interface description applies.
Page 175 When transparent TS16 options are selected and the P300 is in drop and inset mode, the P300 modem must be set to maintain timeslot identities if TS16 is part of the drop and insert group. P300H P300 Series Modem Installation and Operating Handbook Page 175...
Page 176: P1440 In X.21 Mode
P1440 IN X.21 MODE The P300 Series along with its standard P1440 RS422/V.35/RS232 interface can provide both X.21 DCE and X.21 DTE operation. For X.21 operation the card must be set to RS422 mode, and the Tx & Rx Clocking modes must be set correctly. With the use of the appropriate adaptor lead (to convert to the X.21 standard 15 pin D connector), a full X.21 DCE or DTE interface is available.
Page 177 RS422 `Device (DTE) Ready In` line (TR), set this to . It is also possible to configure the Tx carrier to be switched on and off by the `Sig` Valid In` line (I) by selecting P300H P300 Series Modem Installation and Operating Handbook Page 177...
Page 178: Mil-Std-188-114A Interface
Type 1 generator is not supported, but as specified for use with older equipment in 1985, should not be an issue today. The Type 3 is for data rates beyond the P300 Series operating range, and also is not supported.
Page 179: P1451 Eurocom D/1 `D` & `G` Plus Multi-Standard Interface
J4 (exactly as per the P1440) in order for RS422, V.35 and RS232 modes to work. Equipment is supplied with the header fitted, but be aware of this if ever removing a G.703 option card. P300H P300 Series Modem Installation and Operating Handbook Page 179...
Page 180 If repeated `Data Marginal` alarms occur then it is likely the Tx clock and data are not from the same clock course and are `slipping past` each other. P300H P300 Series Modem Installation and Operating Handbook Page 180...
Page 181 This provides protection by ensuring the signal levels remain close to ground potential (as might happen if both inputs and outputs were floating), but avoid any ground currents between distant locations (as might happen if both inputs and outputs were grounded). P300H P300 Series Modem Installation and Operating Handbook Page 181...
Page 182: Appendix B: Modem Connector Pinouts
- to modem RX-A Rx. data * Pins 1 & 5 are both grounded on the modem (ie Shield and Ground are interchangeable). See also the `M&C Appnote` available from www.paradisedata.com. P300H P300 Series Modem Installation and Operating Handbook Page 182...
Page 185: For 1 Interface
Refer to the earlier section on 1 FOR 1 switching for details of 1 FOR 1 operation. A standard 1 FOR 1 lead is available from Paradise Datacom, part number P1391. The lead is 10cm long, and is designed for use when two Modems are mounted vertically adjacent to each other in the rack.
Page 186: Alarms & Agc Connector
(ie non-energised) alarm state. Note: The function of these relays can be changed. See Relay Mode in Appendix E: Customer Specific Features on page 207 for a description. P300H P300 Series Modem Installation and Operating Handbook Page 186...
Page 187: Async Esc Connector
This provides a RS422 compatible station clock in addition to the unbalanced 75 station clock BNC connector. See the menu dialogue in section 6.7.4 on page 92 for a full description of this port. P300H P300 Series Modem Installation and Operating Handbook Page 187...
Page 188 STANDARD LEAD A constellation monitor / serial lead is available from Paradise Datacom, part number M1479. This lead provides the required connections to a 25 pin D type for a PC connection (for printing/capturing a log or updating the modems embedded software), and three BNC s for connecting to a scope for the constellation monitor.
Page 189: Esc/Aux & Backward Alarms Connector
In IDR modes this port provides access to the 8kbps IDR ESC channel. This can either by synchronous at 8kbps, or (if the Async ESC feature is available) asynchronous at up to 4800 or 9600 Baud. P300H P300 Series Modem Installation and Operating Handbook Page 189...
Page 190 32kbps ADPCM audio channels. Typically this would be used synchronously, but if required it could be used asynchronously & oversampled giving maximum baud rates of approx 9600 Baud (in place of one audio channel) or 19200 Baud (in place of both Audio channels). P300H P300 Series Modem Installation and Operating Handbook Page 190...
Page 191 In IDR modes these are used to access the IDR Audio ESC channels. One or both Audio ESC's may be dropped in favour of 32 or 64kbps access to the channel by the Aux port. P300H P300 Series Modem Installation and Operating Handbook Page 191...
Page 192: Backward Alarms
For multidestinational IBS carriers it is possible to operate the P300 in IBS mode, but use 4 separate backward alarms as per IDR. From the front panel select Service as `Other`, based on `IBS`, and follow the screen prompts. P300H P300 Series Modem Installation and Operating Handbook Page 192...
Page 193: Appendix C: Upgrade Information
Upgrading a P300 Series modem may then involve the entering of a `Feature Code` into the front panel, or the addition of one of more of the optional hardware items listed above in addition to entering of a `Feature Code` into the front panel.
Page 194: Appendix C1: Modem Capabilities & Upgrades
To determine the hardware capability of any P300 Series Modem see Features: Hardware in Appendix C2 which follows immediately. Any feature for which the modem Hardware is already present can be added by a simple `Feature Code` upgrade from the front panel.
Page 195 (Temporary features). The modem will cease to be able to provide these features when the period expires unless a Feature Code issued by Paradise Datacom is entered. If you have no means to get a feature code from Paradise Datacom (eg lack of comms, public holiday etc), use one of the 5-day user activated Feature Test periods to provide cover until you can contact us.
Page 196 Other features are available but may require a hardware upgrade (ie a chip to be plugged in or a PCB to be added) If you contact Paradise Datacom directly we will supply within a few minutes by fax a Feature Code to provide the extra features you require (eg addition of Reed-Solomon etc). This will be a temporary code valid for probably 30 days to enable you to raise and place a purchase order on your supplier.
Page 197 Dual rate: If data rate is fixed by feature `P`, then fixed at Low_Rate unless this feature enabled when choice of Low_Rate or High_Rate is available (see below). No effect if feature Dual Rate `P` enables Variable rate P300H P300 Series Modem Installation and Operating Handbook Page 197...
Page 198 A * in the `Letter` column indicates these features require additional hardware to be fitted (eg small PCB or `Chip`). All Other features may be added simply by entering a `Feature Code`. P300H P300 Series Modem Installation and Operating Handbook Page 198...
Page 199: Appendix C3: Features On Demo Expire Soon
All P300 Series modems have this asymmetric loop timing facility. APPENDIX C5: UPGRADE AVAILABLE Again this section is not applicable to the P300 series modems. APPENDIX C6: FEATURES NOT AVAILABLE You have been directed to this appendix by a message on the equipment display, as the unit has detected it has been configured to use features, which it cannot provide.
Page 200: Appendix D: Remote M&C
ASCII characters. Whilst this is not specified for the Paradise / FDC protocol, Paradise Datacom have attempted to achieve this wherever possible. For this reason, only 6 bits of each character of the `Body` are utilised (bits 0 to 5). Bit 6 is fixed at a one for both protocols, and for the Paradise / FDC protocol (where the character has 8 bits, 0-7), bit 7 is fixed at a zero.
Page 201: Message Structure
ACK'd individually (which is useful in very distributed systems with long message transit times). Slave devices will respond with the original format ACK when requested originally defined, allowing common code in the slave devices to support both variants. P300H P300 Series Modem Installation and Operating Handbook Page 201...
Page 202: Message Categories
Messages to read the traffic log Administrative messages The following table summarises all messages, including the message categories listed above. A detailed list of the content of each message is available on request from Paradise Datacom. P300H P300 Series Modem Installation and Operating Handbook...
Page 207: Appendix E: Customer Specific Features
APPENDIX E: CUSTOMER SPECIFIC FEATURES This appendix lists the customer specific options available on the P300 Series Modems: Refer to the Change, User-Opt, Operation menu, section 6.10.7 on page 109 for explanations of how to use these parameters: RELAY MODE SETTING Default (normal) relay operation.
Page 208: Fault Mode Setting
Eb/No (eg to track short duration interruptions such as a helicopter crossing the beam), and this option disables the Eb/No averaging providing a faster responding, but rather jittery Eb/No display. P300H P300 Series Modem Installation and Operating Handbook Page 208...
Page 209 (as far as the 1 for 1 is concerned) providing receive data. Full traffic will switch back to the first modem, which has no faults, ie where the modem has a good receive P300H P300 Series Modem Installation and Operating Handbook Page 209...
Page 210 In order to be in accordance with general industry practises Paradise Datacom has changed which of the two components is delayed with respect to the other between the earliest of the P400 series modems and ongoing P400/P300 production.
Page 211: Uncommitted Dac Output Control
(ie although scaled to ±25dB, it may practically vary only to +3 -1dB if those are the upper and lower AUPC delta limits set). 6-15 Undefined at present P300H P300 Series Modem Installation and Operating Handbook Page 211...
Page 212: Appendix F: Framing And Drop/Insert Overview
& odd frames. Thankfully the IBS specification parted from the G.732 definition at this point and instead of having even & odd frames of 32 timeslots, it defined one longer P300H P300 Series Modem Installation and Operating Handbook Page 212...
Page 213 128kbps carrier). Typically such individual data streams comprise of 64kbps data channels from `N` timeslots of terrestrial PCM bearers, interfaced to the IBS/SMS framing via the Drop/Insert multiplexer. P300H P300 Series Modem Installation and Operating Handbook Page 213...
Page 214: Implementation Of Timeslot Id Maintenance
P300 when equipped with the Extended D/I feature uses a derivative of the IBS CAS Multiframe (see later section "CAS Multiframe") to provide timeslot ID maintenance for even these remaining values of N. P300H P300 Series Modem Installation and Operating Handbook Page 214...
Page 215: Signalling Systems Introduction: Ccs, Cas & Rbs
This option is fully implemented within the P300 equipped with the Extended D/I feature (standard on P300 TCM), and is further explained in the following section on "CAS Multiframe". P300H P300 Series Modem Installation and Operating Handbook Page 215...
Page 216: Cas Multiframe
15 out of every 16 TS16/TS48 locations are still available for high rate ESC, even when the CAS multiframe is required to support `Odd values of N` or Robbed Bit Signalling. P300H P300 Series Modem Installation and Operating Handbook Page 216...
Page 217 Drop/Insert CAS = 104 CAS = 104 CAS = 72 CAS = 72 CAS = 56 CAS = 112 CAS = 232 CAS = 232 TS 328 CAS = 8 P300H P300 Series Modem Installation and Operating Handbook Page 217...
Page 218 * These are the `Odd values of N` for which the Timeslot ID cannot be maintained by the TS 32 Multiframe. + N=32 is a special case normally handled as unframed 2048kbps (ie no Drop/Insert) or 1920/1984kbps (D/I with N=30/31) P300H P300 Series Modem Installation and Operating Handbook Page 218...
Page 219: Idr Framing
All normal IDR facilities plus a 32kbps Aux channel in the normal 96kbps overhead (which allows an internal or external PRBS test to run in parallel with the traffic to monitor the service quality) Reduced IDR facilities with 64kbps or 32kbps overhead. P300H P300 Series Modem Installation and Operating Handbook Page 219...
Page 220: Appendix G: Fault Messages And Action Table
WRITE DOWN the EXACT TEXT and call us for support. Finally, many messages, also show " READ" or " Note" and display further information if the down arrow is pressed, this is usually worth reading! P300H P300 Series Modem Installation and Operating Handbook Page 220...
Page 221 The Modem is configured to operate with a Paradise BUCand the PLL generating the SHFcarrier in (10M ref' to BUC: On) the BUC has failed. The state of the reference feed to the BUC is also reported. P300H P300 Series Modem Installation and Operating Handbook Page 221...
Page 222 This is an internal failure; consult the factory with the error code. Typically though it is caused by poor code>) seating of the Turbo option board on the mating connectors. P300H P300 Series Modem Installation and Operating Handbook Page 222...
Page 223 BER is bad is not set to Ignore (Change, User-Opt, Operation, Actions, BER Action). The fault is always displayed, although the actions can be cancelled by selecting Ignore. Check the line code setting (AMI/B8ZS/HDB3) matches the input P300H P300 Series Modem Installation and Operating Handbook Page 223...
Page 224 See above text, but this time with regard to CAS signalling data not the main data path. Tx Warn: Framer Sig' FIFO slip The FIFO, which carries the CAS signalling from the Drop Mux to the Framer, has slipped (full or P300H P300 Series Modem Installation and Operating Handbook Page 224...
Page 225 Frame sync (otherwise the message above would display). This is only likely in Custom IBS modes where the operator has the option of sending a TS32 Multiframe or not. Note that for low data rates P300H P300 Series Modem Installation and Operating Handbook Page 225...
Page 226 The <line> switching off may be user set to cause this fault or be ignored (Change, Terr-Int, Control Lines). See note 5 P300H P300 Series Modem Installation and Operating Handbook Page 226...
Page 227 Tx modulator onwards, it is unlikely to be other than the Tx mod, the Rx demod, or further down the Rx path as other failures would result in a more P300H P300 Series Modem Installation and Operating Handbook Page 227...
Page 228 Rx Warn: RF Sig too high, now <-19dBm> The Receive RF signal level is above the range specified for this equipment. Decrease the level to P300H P300 Series Modem Installation and Operating Handbook Page 228...
Page 229 Eb/No. Rx Warn: Turbo Decoder status This is a warning used in the engineeering debuging process it should not occur in the field. If it does, please consult the factory. P300H P300 Series Modem Installation and Operating Handbook Page 229...
Page 230 All ones (the Alarm Indication Signal, AIS) is a means of signalling to downstream equipment that the data being sent is not valid. It is advised to leave AIS detection enabled so the modem can inform you when there is a fault with the traffic. If P300H P300 Series Modem Installation and Operating Handbook Page 230...
Page 231 Clock as Satellite (Change, Rx, Buff/Clock, Gen Bearer Clock). If the downstream equipment requires a terrestrial TS16 Multiframe, you must configure the modem to use CAS, so the generated bearer has a TS16 multiframe. P300H P300 Series Modem Installation and Operating Handbook Page 231...

This manual is also suitable for:

P300 turbo P310 l-band P311 l-band/if P310-vsat P310-ibs P310-idr ... Show all

Paradise Datacom P300 Series Installation & Operating Handbook

1 Emc (Electromagnetic Compatibility) and Safety Notices

2 Introduction

3 Description

4 Summary of Specifications

5 Installation and Configuration

6 Menu System

7 Menu Screens for Specialist Options

8 Application Notes

1 For 1 Operation

Boot Code Operation

Appendix A: Data Interface Information

Appendix B: Modem Connector Pinouts

Appendix C: Upgrade Information

Appendix C1: Modem Capabilities & Upgrades

Appendix C2: Feature Screens

Appendix C3: Features on Demo Expire Soon

Appendix C4: Asymmetric Loop Timing

Appendix C5: Upgrade Available

Appendix C6: Features Not Available

Appendix D: Remote M&C

Appendix E: Customer Specific Features

Appendix F: Framing and Drop/Insert Overview

Appendix G: Fault Messages and Action Table

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Paradise Datacom P300 Series

Summary of Contents for Paradise Datacom P300 Series
