Jandy AquaLink RS Installation Manual
All button and onetouch control systems pool/spa combination systems and pool/spa only systems
Hide thumbs
Also See for AquaLink RS:
- Owner's manual (68 pages) ,
- Installation manual (36 pages) ,
- Troubleshooting manual (28 pages)
Table of Contents
Advertisement
Installation Data
Installation Manual
All Button and
OneTouch
Systems
Pool/Spa Combination Systems and
Pool/Spa Only Systems
FOR YOUR SAFETY - This product must be installed and serviced by a professional pool/
spa service technician. The procedures in this manual must be followed exactly. Failure to
follow warning notices and instructions may result in property damage, serious injury, or
death.
TM
Control
WARNING
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Jandy AquaLink RS
Summary of Contents for Jandy AquaLink RS
-
Page 1: Installation Manual
Installation Data Installation Manual All Button and OneTouch Control Systems Pool/Spa Combination Systems and Pool/Spa Only Systems WARNING FOR YOUR SAFETY - This product must be installed and serviced by a professional pool/ spa service technician. The procedures in this manual must be followed exactly. Failure to follow warning notices and instructions may result in property damage, serious injury, or death. -
Page 3: Table Of Contents
Heater Connection ......15 Section 5. Troubleshooting ........ 32 Temperature Sensors ....... 18 All Button and OneTouch Quick Jandy Valve Actuators ..... 18 Troubleshooting Guide ....32 Auxiliary Power Centers ....18 Wireless OneTouch Quick All Button Control Panel Installation .. 19 Troubleshooting Guide .... -
Page 4: Section 1. Important Safety Instructions
Page 4 Section 1. Important Safety Instructions READ AND FOllOW All INSTRUCTIONS lire la notice technique. All electrical work must be performed by a licensed electrician and conform to all national, state, and local codes. When installing and using this electrical equipment, basic safety precautions should always be followed, including the following: DANGER To reduce the risk of injury, do not remove the suction fittings of your spa or hot tub. - Page 5 Page 5 WARNING People with infectious diseases should not use a spa or hot tub. To avoid injury, exercise care when entering or exiting the spa or hot tub. Do not use drugs or alcohol before or during the use of a spa or hot tub to avoid unconsciousness and possible drowning.
-
Page 6: Section 2. System Overview
Page 6 Section 2. System Overview Package Contents Package contents will depend on which AquaLink RS System you are installing. All Jandy AquaLink RS Systems come complete with the appropriate number of 3HP relays needed. Control System Sub-Assemblies All Button... -
Page 7: System Component Specifications And Dimensions
Page 2.2 System Component Specifications and Dimensions Table 1 Specifications (USA and Canada) Power Supply 120 VAC; 60 Hz; A Contact Rating High voltage - 25 A; HP @ 240 VAC 1½ HP @120 VAC 1500 Watts Incandescent Low Voltage - Class Two, 1 A @ 24 VAC Service Switch All Circuits (located at Power Center in Service Mode) Specifications (European) -
Page 8: Basic Plumbing
NOTE When the filter system is shared (a Pool/Spa turn simultaneously so when the Spa button Combo), the spa water must be able to overflow is pressed on the AquaLink RS Control Panel, back to the pool. water circulation switches between pool and spa (consult the Jandy Valve Actuator Installation and Operation Manual to ensure that the JVA’s are... - Page 9 Page 9 2.3.2 Booster Pump Pool Cleaner Plumbing Filter heater Pump Filter Spa Make-up Booster Pump Check Valve Pool Intake Spa Intake Pool Return Spa Return 2.3.3 Non-Booster Pump Pool Cleaner Plumbing Filter heater Pump Filter Spa Make-up Cleaner Check line Valve Energy...
-
Page 10: Section 3. Installation
Power Center can create dangerous electrical hazards, possibly causing death, serious injury or property damage. Turn off power at the main circuit of the AquaLink RS Power Center to disconnect the Power Center from the system. To properly and safely wire the system, be sure... - Page 11 Page 11 3.2.2 3HP (Standard) Relays 3.2.3 Bonding the Power Center For each piece of 240 volt equipment to be Install a bonding lug to the Power Center enclosure. Connect the bond lug, using a #8 solid controlled, connect line power to the two (2) line copper core wire, to an approved earth ground (an terminals and connect equipment power to the two approved ground stake, grid, or conducting metal...
- Page 12 For in the Power Center. a Sub-Panel Power Center install a GFCI Refer to Figures 5 and 6 to connect the Jandy Pool receptacle in the Power Center (use the and Spa Lights to the Power Center.
- Page 13 120 VAC Power Supply 120V Jandy Light Junction Black GFCI Neutral White Ground Green Ground Figure 5. 120-Volt Jandy Pool and Spa light Wiring Diagram 120 VAC Power Supply Jandy Light Junction Black Black 120V/12V GFCI Neutral Transformer White White...
-
Page 14: Low Voltage Wiring
Page 14 3.3 Low Voltage Wiring Minimum wire size should be 22 AWG. If wire run low Voltage is more than 300 feet, larger wire should be used. Raceway 3.3.1 Bezel Connection Plug the 24 VAC power plug from the transformer into its 3-pin terminal on the back of the Power Center PCB (see Figure 7). -
Page 15: Heater Connection
Remove the LX GUI from the heater. heaters or heat pumps with thermostatic circuitry of 24 VAC or less (see pages 15 thru 17 for brand Confirm the LX and AquaLink RS software specific installation). revisions are compatible (see table). - Page 16 ANY line voltage Wire nut two (2) heater wires from wires. AquaLink RS P.C. Board to the two (2) red wires of the heater (see Figure 12). Set the thermostat selector switch to ON, HIGH, or SPA, and set the heater thermostat(s) to maximum.
- Page 17 T5 and T6 on the control panel NOTE To program the Heat Pump control panel, refer printed circuit board (PCB), located on the back to the Jandy AE Series Heat Pump Manual. of the control panel. Run the wires from the Heat Pump control panel through the wiring conduit located on the outer right hand side of the Heat Pump.
-
Page 18: Temperature Sensors
Operation Manual, Cam Setting Chart strip each wire ¼". Connect sensor wires to for proper settings. the green, 10-pin terminal bar (see Figure 17). Auxiliary Power Centers AquaLink RS All Button models support one (1) Solar Auxiliary Power Center. Temperature Water Sensor... -
Page 19: All Button Control Panel Installation
• Never put more than two (2) wires into each of the pins of the red, 4-pin terminal bar (use 4-Conductor Cable a Jandy Multiplex Board). Access hole • If more than one Auxiliary Power Center is installed, set the jumpers as shown in Figure Figure 20. -
Page 20: Onetouch Control Panel Installation
Page 20 3.8.2 Multiple AquaLink RS All Button First Controller Control Panel Installation The AquaLink RS allows each system to support Second Controller a maximum of 4 indoor control panels (see Figure 22). The control panels may be wired "in series" Multiple Control Panels... - Page 21 Page 21 Wire the 4-conductor cable to the red, 4-pin Slide cleat into the slot opening, terminal bar (see Figure 25). Push the 4-pin thread screw through the boss terminal bar onto the back of the OneTouch and into cleat. PCB.
-
Page 22: Wireless Onetouch Control Panel Installation
Control Panel Installation location First Controller The AquaLink RS allows each system to support a maximum of 4 indoor control panels (see Figure 28). The control panels may be wired "in series" starting from the first control panel (solid lines), or Second Controller wired "in parallel"... - Page 23 Voltage Raceway 3.10.3 Changing the Transmission Code Ground level If your AquaLink RS system is turning items on or off at undesignated times, another AquaLink RS Wireless Control Panel may be in close proximity using the same or similar code. To prevent unwanted operation, the code for your Red 4-Pin AquaLink RS Wireless system can be personalized.
-
Page 24: Section 4. System Startup
ENTER. Scroll to the correct hour and minute and press ENTER. NOTE Depending on the version of the AquaLink RS, the following items can be found either in the Main Menu or in a Sub Menu under SETUP. - Page 25 TEMP2). Use the arrow keys to select the desired temperature, and press The AquaLink RS Freeze Protection senses when the ENTER to complete. Press the MENU button, air temperature falls below 38° F (3°C) and will auto- matically turn on the filter pump to circulate the water.
-
Page 26: All Button Reset And Display Messages
CANCEL button; use the arrow keys to advance program is already entered, highlight CHANGE to DIMMERS and press ENTER. The AquaLink RS PROGRAM and step through to the entry that display will prompt you to select an Aux. Press the should be corrected. -
Page 27: Onetouch Reset And Display Messages
Page 2 Highlight TEMP2 and press SELECT (TEMP1 NOTE The Auxiliary labels AIR BLOWER and FILL LINE have an automatic 0 minute runtime. must be higher than TEMP2). Use the UP or To change this setting, refer to the DEVICE DOWN button to increase or decrease the RUNTIME feature. -
Page 28: Changing Chlorine Production Percentage Rate
4.5.2 Changing the Chlorine Production 4.5.1 Power Center Service Switch Settings at the Equipment AUTO Mode (automatic) The AquaPure and AquaLink RS now have two- 1. The control panel has complete control of all way communication. The AquaLink RS Power functions. Center will read settings or modifications made 2. -
Page 29: Power Interruption
Boost - 24 Hour 100% Chlorine Production Cycle - Refer to Manual - - - - To Enter Boost Mode Press and Hold "Temperature" Button for 10 Seconds AquaLink RS system is in Service or Time Out Pool Temperature - Temperature of Pool Water at Flow Sensor... -
Page 30: All Button Menu Flow Chart
Page 0 4.6 All Button Menu Flow Chart ON ALL DAYS SELECT PROGRAM EQUIPMENT ON WEEKENDS PROGRAMS ON WEEKDAYS TEMP SET ON SPECIFIC DAY ALL OFF TIME REVIEW SPA SWITCH POOL TEMP SPA LINK SET TEMP SPA TEMP FRZ PROTECT MAINTAIN TEMP SET YEAR, DAY AUX LABELS SET TIME HOUR &... -
Page 31: Onetouch Menu Flow Chart
† DISABLED DISABLED RETURN SYSTEM ENABLED PUMP LOCKOUT SETUP CLEANER DISABLED ASSIGN TO AUX SOLAR ASSIGN JVAs JANDY LIGHT COLOR LIGHTS SAM/SAL LIGHT GO BACK DIMMERS** SELECT LOCATION DUSK CTRL SPA SWITCH** DURATION PACIFIC SPA LINK** SET TIME TIME ADJUST... -
Page 32: Section 5. Troubleshooting
Page 2 Section 5. Troubleshooting 5.1 All Button and OneTouch Quick Troubleshooting Guide Symptom Problem Possible Solution Power Center override switches Power supply problem. Check connection of the outside two wires (red operate when in Service or & green) of the four conductor cable. If wired Time Out Mode, but the control correctly, check the voltage between these two panel is completely dead (no... -
Page 33: Wireless Onetouch Quick Troubleshooting Guide
"Service Mode". installed or defective. 5.2 Wireless OneTouch Quick Troubleshooting Guide The Wireless AquaLink RS will stop communicating anytime interference (such as from a microwave oven or other 2.4 GHz devices) prevents a valid signal transmission. When communication is lost the control panel will lock on "Model Number"... - Page 34 Page 4 Symptom (continued) Problem Possible Solution LCD screen display stays on No communication between . Repeat Step 2 for the Indoor Desktop Control "Firmware B11" (or later). indoor Control Panel and Panel. Power Center J-box. 4. Recheck the Indoor Desktop Control Panel for proper performance.
-
Page 35: Section 6. Power Center Wiring Diagram
Page 5 Section 6. Power Center Wiring Diagram Elect. Heater Return Solar Intake Cleaner Solar Pump 4 3 2 1 6 5 4 3 2 1 JVA Sockets Relay Sockets To Controller To Remote To Sensors, etc. (24 VAC output) (24 VDC output) Dip Switch Settings (red terminal bar) (brown terminal bar) (green terminal bar) -
Page 36: Section 7. Power Center Pcb Dip Switch
With this switch Turn this switch ON if you have installed a heat on, the filter pump button on the AquaLink RS pump instead of a gas heater. After thermostat Control Panel will control high speed and the AUX 2 button will control low speed. -
Page 37: Dip Switch Settings For Pool And Spa Combination
Page OFF ON Factory setting is with all DIP switches off. 7.2 DIP Switch Settings for Pool and Spa Combination DIP Switch # AUX1= any equipment AUX1= Pool Cleaner AUX2= any equipment AUX2= Low Speed for a two-speed filter pump. Filter pump circuit becomes High Speed. AUX= any equipment AUX= Spa Spillover effect- Combination controls only. -
Page 38: Dip Switch Settings For Pool Or Spa Only
Page 8 7.3 DIP Switch Settings for Pool or Spa Only DIP Switch # AUX1= any equipment AUX1= Pool Cleaner AUX2= any equipment AUX2= Low Speed for a two-speed filter pump. Filter pump circuit becomes High Speed. AUX= any equipment No change Heater cool down operates. Heater cool down disabled. -
Page 39: Section 8. General, Water Feature And Light Aux Labels
Fence light hi-E2 Flood light high Speed Fountain light home A/C Front light home heat Garage light Jet Pump Garden light Jandy lite Jandy lX Gazebo light hall light lamp lights* house light Kitchen light low Speed Mist laminar Plsr... -
Page 40: Warranty
DE grids, or cartridge elements; or damage caused by running the pump with insufficient quantities of water. LIMITATION OF LIABILITY: This is the only warranty given by Jandy Pool Products, Inc. No one is authorized to make any other warranties on behalf of Jandy Pool Products, Inc. THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO ANY IMPLIED WARRANTIES OF FITNESS FOR A PARTICULAR PURPOSE AND MERCHANTABILITY.
