Summary of Contents for CORRECT CRAFT Super Air 210 2011

  • Page 3 Nautique. By purchasing a Nautique, you have taken the first step in trading your old lifestyle for a new one. Now that you own a Nautique, life as you know it will never be the same. Enjoy the Nautique Life.

  • Page 4: Record Important Information

    Record Important Information In addition to this manual, your Nautique boat is supplied with component manufacturer information such as instructions, warranties or other important information. Read these materials carefully since improper operation and maintenance can void the warranty and jeopardize personal safety.

  • Page 5: Boater's Checklist

    Boater’s Checklist For improved safety and enjoyment, check each of these items: Check Before You Launch Your Boat: • Read both the engine and the boat operator manuals. • Drain plug (Securely in place?) • Propeller Condition (Prop nut tight and secured, no cracked or bent blades, prop turns freely?) •...

  • Page 6: Restricted Areas

    California Health & Safety Code 25249.5-.13 KC-0206-B Emission Control Warranty Information The engine in your Nautique boat meets the strict requirements set forth by the California Air Resources Board (CARB). The engine has a special environmental tag and the boat has this label affixed to it.

  • Page 7: Boating Terminology

    Boating Terminology LENGTH OVERALL (LOA) PORT SIDE STARBOARD SIDE HELM TRANSOM FORWARD GUNWALE STERN FREEBOARD DRAFT WATERLINE CORC001 * An easy way to remember PORT side from STARBOARD side is “PORT” and “LEFT” both have four letters. Product Improvement Because of our policy of continuous product improvement, the illustrations used in this manual may not look the same as on your boat and are intended only as representative reference views.

  • Page 8: Table Of Contents

    Table of Contents Welcome........i Recommended Safety Record Important Equipment ......1-21 Information.......ii Emergency Stop Switch and Boater’s Checklist ....iii Lanyard.........1-22 Restricted Areas .......iv Emergencies......1-23 Proposition 65 ......iv Fire/Explosion ....1-23 Emission Control Warranty Capsizing and Information ......iv Swamping......1-24 Boating Terminology....v Collisions......1-24 Product Improvement....v Grounding ......1-24 Water Rescue Boating Safety ......1-1...
  • Page 9 Hydro-Gate™ Control and Crossing Situation ....2-6 SportShift™......4-2 Meeting Head-On ....2-7 Shifter/Throttle.....4-4 Overtaking ......2-8 Emergency Stop Switch..4-5 The General Prudential Nautique Dash Pod - 200, 210, Rule........2-9 216, 226 ........4-6 Night Running....2-9 Gauges .........4-6 Speedometer Calibration ..4-8 200, 210, 216, 226 Control Switches....4-8 and 230 .......3-1...
  • Page 10 Ballast Tank Valves - 216 ..5-5 Watersports Tow Point..4-57 Ballast Tank Valves - 226 ..5-5 Bow Features of Your Ballast Tank Valves - 230 ..5-6 Nautique ......4-58 Belly Ballast Tank and Driver’s Seat Bilge System ......5-7 Adjustment......4-59 Port and Starboard Ballast Rearview Mirror Tanks........5-8...
  • Page 11 Boat Planing......6-5 Gelcoat Maintenance ..8-12 Pre-Operation Checks...6-6 Care of Metal .......8-13 Flooded Engine....6-11 Care of Glass ......8-13 Break In Procedure..6-13 Adhesive-Backed Propeller Selection...6-13 Non-Skid.......8-14 Shifting .........6-14 Vinyl Maintenance and Steering ........6-14 Cleaning .......8-14 Stopping .......6-15 Tunable Rudder....8-16 Docking ........6-15 Rudder Remote Lube Fitting ........8-17 Running........7-1 Transmission ......8-17...
  • Page 12 Warranty......W-1 NAUTIQUE LIMITED WARRANTY ......W-1 Lifetime Limited Warranty......W-1 Transferable Lifetime Limited Warranty ....W-1 Boat Five (5) Year Transferable Limited Warranty......W-2 Gel Coat Three (3) Year Non-transferable Limited Warranty......W-2 NAUTIQUE COASTAL EDITION LIMITED WARRANTY ......W-5 Lifetime Limited Warranty......W-5 Transferable Lifetime Limited Warranty ....W-5...

  • Page 13: Boating Safety

    Section 1 Boating Safety Safety While Boating Boating-related accidents are generally caused by the operator’s failure to follow basic safety rules or written precautions. Most accidents can be avoided if the operator is completely familiar with the boat, its operation and can recognize potentially hazardous situations.
  • Page 14 Section 1 • DO NOT operate the boat while under the influence of alcohol or other drugs. • DO NOT stand or allow passengers to stand in the boat, or sit on the transom, seat backs, engine cover or sides of the boat while the engine is running.

  • Page 15: General Precautions

    Boating Safety • Seek shelter from open water if there is threat of lightning. • Operate slowly in congested areas such as marinas and mooring areas. • The bow may be slippery. Do not go forward while the engine is running. •...
  • Page 16 NOTICE Indicates a property damage message. The precautions listed in this manual and on your Nautique boat are not all-inclusive. If a procedure, method, tool, or part is not specifically recommended, you must satisfy yourself that it is safe for you and others, and that the boat will not be damaged or made unsafe as a result of your decision.

  • Page 17: Boat Safety Labels

    Boating Safety Boat Safety Labels Your Nautique boat is affixed with various safety labels at the time of manufacture. These labels appear at specific locations on the boat where safety is of particular concern. Safety labels must be legible. If you suspect a label is missing or one becomes damaged, contact your Nautique dealer for immediate replacement.
  • Page 18 Section 1 Avoid personal injury or property damage caused by flying objects. Remove any items from WARNING! DO NOT board racks when trailering boat. ATTEMPT TO START OR OPERATE ENGINE WITH FLAME ARRESTOR REMOVED CORC094 CORC093 Flame Arrestor Board Racks CORC064 Walk Through Windshield FIRE EXTINGUISHER SYSTEM...
  • Page 19 Boating Safety Failure to follow these guidelines can result in injury or death. Do not tow more than two persons at one time from this tow tower. tower should only be used for waterskis, wakeboards, or recreational towables and not for parasailing, kite flying, towing other...
  • Page 20 Section 1 CORC0290 CORC0289 CORC0285...

  • Page 21: Boating Regulations

    Boating Safety Boating Regulations The U.S. Coast Guard (USCG) is the authority of the waterways; they are there to help the boating public. State boating regulations are enforced by local authorities. You are subject to marine traffic laws and “Rules of the Road” for both federal and state waterways; you must stop if signaled to do so by enforcement officers, and permit to be boarded if asked.

  • Page 22: Registration/Documentation

    Contact your state boating authorities (and neighboring states) for registration information on boats and trailers. Your Nautique dealer can supply you with the appropriate forms. 1-10...

  • Page 23: Insurance

    Many states have laws detailing minimum insurance needs. Your insurance agent or your Nautique dealer may be able to supply you with more information. Education Opportunities This manual is not intended to provide complete training on all aspects of boat operation.

  • Page 24: Operating By Minors

    An overloaded boat can cause death or serious injury. Do not purposely overload or add any additional water to the boat other than to the Nautique Launch Control System. DO NOT overload your boat. Your boat is equipped with a required...
  • Page 25 An overloaded Nautique will handle differently than a lightly loaded one. Drive and turn your Nautique with this in mind. As wakeboarding has developed, we have witnessed the advent of ballast systems which add weight and increase the size of the wake.

  • Page 26: Passenger Safety And Seating

    Section 1 maximum weight of people, gear and ballast that can be placed in the boat. Always be aware of the load in your boat and do not load the boat in excess of the listed capacity. The quest for the "phattest" wake has caused some to excessively overload their boats.

  • Page 27: Boating Under The Influence

    Boating Safety The operator of the boat is responsible by law to “maintain a proper lookout by sight and hearing.” The operator must ensure that he/she has an unobstructed view particularly to the front. No passengers or equipment should block the operator’s view. Look carefully before turning, especially when you are turning around to pick up a fallen skier.

  • Page 28: Reporting Accidents

    The included safety equipment on your Nautique boat meets or exceeds the standards of the USCG, ABYC and the NMMA. Some required safety equipment such as PFDs are not included with your Nautique boat.

  • Page 29: Life Saving Equipment

    Boating Safety Equipment requirements for coastal and inland waters differ. Check with local authorities or the USCG for further information about coastal water requirements. The following equipment may or may not be required by federal/local regulations. Type I Life Saving Equipment Life Preservers Federal law requires at least one Type I, II, III, or V Personal Flotation Device (PFD), of the...
  • Page 30 Designed to be thrown to a person in the water and should never be worn. Type IV Throwable Devices Your Nautique dealer can help you select appropriate PFDs and throwable lifesaving devices for your area. 1-18...

  • Page 31: Navigation Lights

    The anchor light must be visible 360 degrees. Horn or Whistle All boats over 16 feet (4.8 meters) in length must be equipped with an operable horn or whistle, audible from one mile. Your Nautique boat is equipped with a USCG approved horn. Fire Extinguisher At least one approved B-1 portable fire extinguisher is required.
  • Page 32 Section 1 If you are required to carry distress signals, you must have three USCG approved pyrotechnic devices. Be sure they are in serviceable condition, not exceeding the expiration date and stored in a cool, dry location in a waterproof container. Have enough signals on board to last three days.

  • Page 33: Recommended Safety Equipment

    Normally, this equipment is dependent on the body of water and the length of the trip; your Nautique dealer can assist you: • First aid kit and manual • Anchor with at least 75 feet (23 meters) of line •...

  • Page 34: Emergency Stop Switch And Lanyard

    Section 1 Emergency Stop Switch and Lanyard Your Nautique boat is equipped with an emergency stop switch and lanyard. Nautique strongly recommends that the lanyard be secured to the operator and the lock plate attached to the emergency stop switch prior to starting the engine and anytime the engine is operating.

  • Page 35: Emergencies

    Boating Safety Replacement lanyards should be of sufficient length to avoid inadvertent activation. Accidental loss of power can be hazardous particularly when docking or in heavy seas, strong current or high winds. Emergencies Be prepared to deal with emergencies before they happen. Try to formulate a plan for each type in advance so that decisions can be made quickly and without hesitation.

  • Page 36: Capsizing And Swamping

    Section 1 Capsizing and Swamping A boat may capsize or swamp when least expected. Like fires, try to formulate a plan in advance on what to do if it should happen. Keep in mind the following guidelines: • Try to turn the engine OFF to prevent damage. •...

  • Page 37: Medical Emergency

    Boating Safety Medical Emergency Be prepared in the event of an emergency. Know how to use your first aid kit. Be aware of any special medical conditions of your passengers. Operation Failure If you experience a propulsion, steering or control failure, immediately turn OFF the engine.

  • Page 38: Dam Spillways

    Section 1 NOTICE Weeds can sometimes be removed by shifting to NEUTRAL, pausing for a moment, then shifting to REVERSE to unwind the weeds from the propeller. Dam Spillways The water level around a dam spillway is a hazardous area. It is subject to rapid changes caused by currents and turbulence.

  • Page 39: Warning Markers

    Boating Safety Warning Markers DIVERS FLAG ALPHA FLAG DISTRESS FLAG BLUE ORANGE USED BY WORLDWIDE VESSELS INDICATES RECREATIONAL ENGAGED IN DIVING FELLOW DIVERS - OPERATIONS - DOES BOATER IS IN INDICATES NOT INDICATE NEED OF DIVER'S DIVER'S POSITION ASSISTANCE POSITION KC-0352C-a Warning Markers It is a good idea to ask local authorities if there are hazardous areas...

  • Page 40: Carbon Monoxide

    Section 1 KC-0260C Swim Area Warning Buoy Navigation markers serve as a means of identifying navigable routes, and indicate water hazards. Boaters should become familiar with navigation markers and stay within marked boundaries and clear of hazards. Carbon Monoxide Carbon Monoxide (CO) is a colorless and odorless gas produced by all engines and fuel burning appliances.

  • Page 41: Our Environment

    Boating Safety Our Environment As a boater, you already appreciate nature’s beauty and the peace of the great outdoors. It is a boater’s responsibility to protect the natural environment by keeping waterways clean. Foreign Species If you trailer your boat from lake to lake, you may unknowingly introduce a foreign aquatic species from one lake to the next.

  • Page 42: Discharge/Disposal Of Waste

    Increased exhaust (hydrocarbon) emissions pollute our water and air. Keep your engine tuned and boat hull clean for peak performance. Consult your Nautique dealer for information. Paints If your boat is kept in water where marine growth is a problem, the use of anti-fouling paint may reduce the growth rate.

  • Page 43: Cleaning Agents

    Boating Safety Cleaning Agents Household cleaners should be used sparingly and not discharged into waterways. DO NOT mix cleaners and be sure to use plenty of ventilation in enclosed areas. DO NOT use products which contain phosphates, chlorine, solvents, non-biodegradable or petroleum based products.
  • Page 44 Taking the risk of swimming under a boarding platform when the engine is running, "teak surfing" or "dragging" behind a moving boat can be fatal. Nautique DOES NOT consider any dangerous activities which can result in a serious injury or death a watersport.

  • Page 45: General Watersport Precautions

    Boating Safety SAFETY ALERT From August 28, 2001: The United States Coast Guard advised boaters not to "Teak/Drag Surf." Recent boating fatalities revealed that carbon monoxide (CO) emitted from a vessel’s exhaust resulted in CO poisoning and the death of at least six teak surfers. "Teak/Drag Surfing" places the individual in position directly exposed to the CO in the engine’s exhaust.
  • Page 46 Section 1 • DO NOT Kitefly. • Make sure that everyone knows and uses approved skiing hand signals and common skiing courtesy. • Be sure to turn off the engine before allowing anyone to approach the boat. • The engine MUST be shut down (OFF) before a skier enters or exits the boat, boarding platform or ladder.
  • Page 47 • Be sure to inspect the tow eye or pylon before use. If there is any evidence of corrosion or other damage, do not use until it has been inspected by your Nautique dealer. • Be sure to wear wet suits or protective shorts when skiing to prevent abrasions, hypothermia and injuries to orifices (rectal and vaginal) from impact with a water surface.

  • Page 48: Watersports Responsibility Code

    Section 1 When participating in watersports, be safe and courteous and follow these guidelines: • Be considerate to fishermen and others you share the water with. • DO NOT perform watersports in congested areas. • Stay away from navigation markers. •...
  • Page 49 Boating Safety • Read your owner’s manual and inspect your equipment prior to use. • Ski or ride within your limits. • Always ski or ride in control and at speeds appropriate for your ability. • Always turn ignition off when anyone is near watercraft power drive unit.
  • Page 50 Section 1 NOTES 1-38...

  • Page 51: Basic Rules Of The Road

    Section 2 Basic Rules of the Road Hazard from collisions between boats can cause death or serious injury. Follow the nautical “Rules of the Road.” The operator is legally required to follow the rules. The following information outlines only the most basic of the nautical “Rules of the Road.”...

  • Page 52: Uswms System

    Section 2 BLUE KC-0412C Mooring Buoy – White with Blue Band May Show White Reflector or Light USWMS System In the USWMS Lateral System, well-defined channels are marked with red and black buoys. Lateral means the sides of the channel are marked and the boat should pass between them.

  • Page 53: Uniform State Regulatory Markers

    Basic Rules of the Road Uniform State Regulatory Markers USWMS regulatory markers are white with international orange geometric shapes; you must obey regulatory markers. UNIFORM STATE WATERWAY MARKING SYSTEM (USWMS) CONTROLLED DANGER BOATS INFORMATION AREA KEEP OUT DO NOT PASS SPECIAL NAVIGATE TO NAVIGATE TO...
  • Page 54 Section 2 SPAR BUOY CAN BUOY LIGHTED BUOY UNLIGHTED NUN BUOY BELL BUOY KC-0420 FWMS Marking System The middle of the channel is marked with RED and WHITE vertically striped buoys; pass close to these buoys. SPHERICAL SAFE WATER MARKER KC-0430 Spherical Safe Water Marker Obstructions, channel junctions, etc.

  • Page 55: Right Of Way

    Basic Rules of the Road STARBOARD MARKER PORT GREEN MARKER KC-0440C Lights, bells and horns are used on buoys for night or poor visibility conditions. Buoys with unique light flashing characteristics are identified on nautical charts with the specific flashing pattern. Right of Way NOTICE In general, boats with less maneuverability have right of way over...

  • Page 56: Crossing Situation

    Section 2 Crossing Situation In crossing situations, the boat to the right from the 12 o’clock to the 4 o’clock position has the right of way. It must hold course and speed. The burdened boat keeps clear and passes behind the privileged boat.

  • Page 57: Meeting Head-On

    Basic Rules of the Road Meeting Head-On Neither boat has the right of way in this situation. Both boats should decrease speed, turn to the right and pass port-to-port. However, if both boats are on the left side of the channel, each vessel should sound two short blasts and pass starboard-to-starboard.

  • Page 58: Overtaking

    Section 2 Overtaking The boat that is overtaking one ahead of it is the give-way boat and must make any adjustments necessary to keep out of the way of the stand-on boat. The stand-on boat should hold its course and speed. HONK (LONG) STAND-ON...

  • Page 59: The General Prudential Rule

    Basic Rules of the Road The General Prudential Rule The General Prudential Rule regarding right of way, is that if a collision appears unavoidable, neither boat has right of way. As prescribed in the "Rules of the Road," both boats must act to avoid collision.
  • Page 60 Section 2 NOTES 2-10...

  • Page 61: And 230

    Gear Reduction Ratio.............1.48:1 Maximum Factory Ballast Capacity......736 lbs (334 kg) * Weights are estimates and can vary from options and equipment added. NOTICE The dash configurations used in this section may show more features than what is included in your Nautique.
  • Page 62 Section 3 Length Overall............21' 0" (6.40 m) Length with Platform...........23' 3.5" (7.10 m) Lifting Ring Spacing ..........19' 7" (5.97 m) Beam................98" (2.49 m) Draft................28" (0.71 m) Approximate Dry Weight*......3,800 lbs (1,725 kg) Fuel Capacity..........40 Gallons (151.4 L) Maximum Capacity ......12 People (1,850 lbs/839 kg) Horsepower Range ......343 to 390 (256 to 291 kw) Gear Reduction Ratio.............1.48:1 Maximum Factory Ballast Capacity......906 lbs (411 kg)
  • Page 63 200, 210, 216, 226 and 230 Length Overall............22' 7" (6.88 m) Length with Platform..........24' 10" (7.57 m) Beam................98" (2.49 m) Draft................31" (0.79 m) Approximate Dry Weight*.......4,100 lbs (1860 kg) Fuel Capacity..........56 Gallons (212.0 L) Maximum Capacity ......15 People (2,150 lbs/975 kg) Horsepower Range ......343 to 409 (256 to 305 kw) Gear Reduction Ratio.............1.48:1 Maximum Factory Ballast Capacity....1,020 lbs (463 kg)

  • Page 64: Nautique Dash Pod And Console (Without Nautique Linc)

    Section 3 200 Nautique Dash Pod and Console (without Nautique LINC) 1. Stereo Remote 10. SportShift™ Hydro-Gate™ 2. Ignition Key Control Handle 3. RPM 3 in 1 Gauge w/Oil & 11. Shifter/Throttle Control Temp Handle 4. Service Soon Light (catanium 12.

  • Page 65: Team Dash Pod And Console (With Nautique Linc)

    200, 210, 216, 226 and 230 200 Team Dash Pod and Console (with Nautique LINC) 1. Pocket Panel 8. SportShift™ Hydro-Gate™ 2. RCA Video Input Control Handle 3. USB and Auxiliary Input* 9. Shifter/Throttle Control 4. Nautique LINC System Handle 5.

  • Page 66: Nautique Dash Pod And Console

    Section 3 10 11 NAV/ BLOWER BILGE HORN ANCHOR 210, 216, 226 Nautique Dash Pod and Console 1. Stereo 11. Ignition Key (210) 2. RPM 3 in 1 Gauge w/Oil and 12. Fire Extinguisher System Temp (optional) 3. Service Soon Light 13.

  • Page 67: Dash Pod And Console With Nautique Linc System

    200, 210, 216, 226 and 230 210, 216, 226, 230 Dash Pod and Console with Nautique LINC System 1. Pocket Panel 10. SportShift™ Hydro-Gate 2. Warning and Danger Decal Control Handle 3. RCA Video Input 11. Shifter/Throttle Control 4. USB and Auxiliary Input* Handle 5.

  • Page 68: Ignition And Switch Panel

    Section 3 CORC083 Ignition and Switch Panel 1. Keyless Ignition Key Pad 2. Belly Ballast (if equipped) 3. Port Ballast (if equipped) 4. Starboard Ballast (if equipped) 5. Underwater Lights 6. Heater Fan 7. Courtesy Lights/Docking lights 8. Navigation Lights/Anchor Light 9.

  • Page 69: Keys

    200, 210, 216, 226 and 230 Keys CORC027B 1. Fuel Tank Fill Cap Key 2. Hatch Latch Key...

  • Page 70: 200 Deck Layout

    Section 3 200 Deck Layout CORC0310 3-10...
  • Page 71 200, 210, 216, 226 and 230 Description 1. Bow Navigation Light 2. Bow Lifting Ring 3. Belly Ballast Tank Vent 4. Dash Pod and Console 5. Hydro-Gate™ Control and SportShift™ 6. Removable Pylon 7. T-Handle Drain Plug 8. Engine Cooling Water Intake Shutoff Valve 9.
  • Page 72 Section 3 210 Deck Layout CORC280 3-12...
  • Page 73 200, 210, 216, 226 and 230 Description 1. Bow Navigation Light 2. 12V Port 3. Bilge Pump Outlet 4. Belly Tank Vent 5. Dash Pod & Console 6. Sport Shift 7. Automatic Bilge Panel 8. Storage 9. Anchor Light Receptacle 10.

  • Page 74: 216 Deck Layout

    Section 3 216 Deck Layout CORC0311 3-14...
  • Page 75 200, 210, 216, 226 and 230 Description 1. Bow Navigation Light 2. Bow Lifting Ring 3. Anchor Storage 4. Storage 5. Cruise Control GPS Module 6. Belly Tank Vent 7. Dash Pod and Console 8. Hydro-Gate ™ Control and SportShift ™...

  • Page 76: 226 Deck Layout

    Section 3 226 Deck Layout CORC0312 3-16...
  • Page 77 200, 210, 216, 226 and 230 Description 1. Bow Navigation Light 2. Bow Lifting Ring 3. Storage 4. Cruise Control GPS Module 5. Belly Tank Vent 6. Battery Selector Switch/PMA Panel/Breaker Panels 7. Dash Pod and Console 8. Hydro-Gate™ Control and SportShift™ 9.

  • Page 78: 230 Deck Layout

    Section 3 230 Deck Layout CORC0309 3-18...
  • Page 79 200, 210, 216, 226 and 230 Description 1. Bow Navigation Light 2. Bow Lifting Ring 3. 12V Port 4. Bilge Pump Outlet 5. Belly Ballast Tank Vent 6. Dash Pod and Console 7. Hydro-Gate™ Control and SportShift™ 8. Removable Cooler 9.

  • Page 80: Standard And Optional Equipment

    Section 3 Standard and Optional Equipment Nautique boats are equipped with only the finest standard and optional equipment available. Your boat’s equipment will vary, based on how your boat was built. Many options can only be installed during the manufacturing of the boat and cannot be retro- fitted to boats in the field.

  • Page 81: Controls And Indicators

    Improper maintenance may result in a loss of control, possibly causing serious injury or death. Steering The steering system in your Nautique boat provides excellent maneuvering performance for pleasure boating or during watersports. Boat steering is not self-centering. Always keep a secure grip on the steering wheel to maintain full boat control.

  • Page 82: Hydro-Gate™ Control And Sportshift

    Section 4 The helm transfers rotary motion of the steering wheel to linear motion in the cable which pushes or pulls the rudder. Nautique rudders are equipped with an adjustable trim tab under license from Z-Marine (U.S. patent 5,746,147) to compensate for the torque generated by the propeller.
  • Page 83 Controls and Indicators CORC142B CORC143...

  • Page 84: Shifter/Throttle

    DO NOT replace the control with a control that does not have this feature. Your Nautique boat is equipped with a Shifter/Throttle Control Handle which features a start-in-gear protection to prevent the boat from moving when started.

  • Page 85: Emergency Stop Switch

    Controls and Indicators Emergency Stop Switch The emergency stop switch will stop the engine when the lanyard is pulled far enough to disengage it from the switch. Attach the lanyard to the boat operator whenever the engine is running but be aware there will be a loss of engine power if the switch is activated.

  • Page 86: Nautique Dash Pod

    Once a month: Check the emergency stop switch for proper operation. With the engine running, pull lanyard. If the engine does not stop, see your Nautique dealer for service of the switch. Nautique Dash Pod - 200, 210, 216, 226 Gauges RPM 3 in 1 Gauge w/Oil &...
  • Page 87 Speedometer 3 in 1 Gauge w/ Fuel & Volt • Speedometer - Your Nautique is equipped with a precision speedometer by Faria. This gauge registers forward speed in miles per hour (optional kilometers per hour). The speedometer is equipped with an adjustment knob to calibrate speedometer accuracy.

  • Page 88: Speedometer Calibration

    Section 4 Service Soon Light - For quality control check. When ignition is turned on without cranking the engine, the red “check engine” light will turn on for a few seconds and then turn off. The amber “service soon” light will turn on and stay on until either the engine is started or the ignition is switched off.
  • Page 89 Controls and Indicators The intakes which supply fresh air into the bilge area are located aft, at the windshield frame base. The intakes must remain clear to allow air to enter the bilge area. DO NOT drape towels or any items which may not allow air to be drawn in while the bilge blowers are operating.
  • Page 90 This pumping system should not be relied on over an extended period of time. Frequently inspect your boat for evidence of excessive water in the bilge area. Consult your Nautique dealer if you have any questions. NOTICE Trash in bilge area can damage the bilge pumps.

  • Page 91: 12-Volt Port

    Smart Pod – Team Gauges Gauge information is displayed in the Nautique LINC System. Refer to Section 4 - Nautique LINC System to access the gauge display. • Volts - Indicates the condition of the engine’s cranking battery in volts DC. With the ignition switch on and the engine not running, a reading above 12.5 volts indicates a fully charged...
  • Page 92 If the pressure is lower than the manufacturer’s specification, immediately turn off the engine. Contact your Nautique dealer to correct the problem before operating the engine. • Tachometer/Hour Meter - Registers engine speed in revolutions per minute (RPM).

  • Page 93: Control Switches

    Belly, Port, Starboard Ballast These buttons fill and drain the ballast tank designated to the switch. Ballast tanks are an option on most Nautique boats. A full description of how these buttons function is discussed in Section 4, Ballast Tank Control Switches.
  • Page 94 Section 4 Courtesy/Docking Lights Press and release for courtesy lights, press and hold from this position to turn docking lights on with courtesy lights. To turn the courtesy lights and the docking lights off, press and release. Docking lights only: from the OFF position, press and hold until the docking lights are on and release, to turn off, press and release.
  • Page 95 This pumping system should not be relied on over an extended period of time. Frequently inspect your boat for evidence of excessive water in the bilge area. Consult your Nautique dealer if you have any questions. NOTICE Trash in bilge area can damage the bilge pumps.

  • Page 96: 12-Volt Port

    This receptacle can be used to power and charge cellular phones, MP3 players, video cameras or other electronics. These receptacles are powered through a 10 amp breaker. Dash Pod – 216, 226 Nautique Packages and All Team Packages Ignition and Switch Panel CORC137...
  • Page 97 Controls and Indicators CAUTION The keypad and switch control box will be damaged beyond repair if the boat’s battery cables, the main switch control box power leads or battery charger leads are reversed. DO NOT reverse these connections. Locked Mode When the boat’s battery is first connected, the unit is in locked mode.
  • Page 98 The “Primary User Code” is programmed into the system by the owner with the Nautique dealer’s help at the time of boat delivery. This code is used to unlock the system, to lock the system and to add or change the “Secondary User Code.”...
  • Page 99 Controls and Indicators NOTICE The “System Indicator Light” is on the right side of the ignition keypad. The “Ignition Indicator Light” is on the left side of the ignition keypad. Programming the Primary User Code NOTICE Until a Primary User Code is set, the keyless ignition does not require the entry of a code to unlock the system or start the engine.
  • Page 100 Section 4 Changing the Primary User Code NOTICE The current primary code must be used to change to another primary code. Make sure the system indicator light is OFF. 1. Enter the Primary User Code, then press and release the 1/2 key and the 7/8 key at the same time to put the system in the code programming mode.

  • Page 101: Nautique Digital Cruise

    “Programming The Primary User Code” in this section. Nautique Digital Cruise Home Screen When the ignition is turned to the ON position, the Nautique Digital Cruise gauge will flash the Nautique corporate logo until the internal software is booted up, then the display screen will show the following: •...
  • Page 102 Nautique Cruise, press and release the ON/OFF/MENU button. Nautique Digital Cruise will still control the speed until the throttle is reduced below the set speed. Set speed can be adjusted with the Nautique Digital Cruise on or off by pressing the UP/DOWN arrow buttons until the desired speed is displayed on the screen.
  • Page 103 Controls and Indicators Depth The Depth function includes an audible and visual alarm that can be set to sound when a minimal water depth is present. If audible alarm sounds, pressing the SELECT button will silence the alarm. The alarm resets itself when the boat enters water that is deeper than the shallow setting.
  • Page 104 Section 4 Dash Pod Circuit Breaker Box All dash pod switches interface with a sealed circuit breaker box located in the driver’s kickboard. The circuit breaker box consists of 16 soft, opaque, flexible vinyl tubular shields which cover 16 circuit breakers. When the circuits are functioning, the tubular shield is somewhat flexible.

  • Page 105: Power Management Access (Pma) Panel (216 And 226 Only)

    BALLAST PUMP AFT BILGE STEREO PUMP BILGE SWITCH BELLY COCKPIT BALLAST PUMP PORT BALLAST PUMP CORC0306 Your Nautique is equipped with a PMA panel to manage other components of the electrical system. It includes breakers, switches and a 12-volt port. 4-25...

  • Page 106: Automatic Bilge Panel

    Section 4 Automatic Bilge Panel Bilge Pump Only Mode - This feature is activated by a switch located on the side console. The switch has three positions, ON, OFF and BILGE. If the boat is going to sit for more than a few days with the bilge pumps on, it is important the switch is set in the BILGE position to minimize battery drain.

  • Page 107: Nautique Linc System

    Controls and Indicators Nautique LINC System Product Information The Nautique LINC System display is designed for instrumentation and control on electronically controlled engines communicating via SAE J1939 and NMEA 2000. The display is a multi-functional tool that provides GPS tracking, Clarion Audio, Cruise control, and enables equipment operators to view many different engine, ballast, transmission parameters and service codes.

  • Page 108: Basic Navigation Features

    Section 4 Basic Navigation Features All product features are easily accessed through Quick Access Keys, Menus, and Popup Controls. Quick Access Keys These keys provide one-button access to Gauge and GPS displays, Clarion Audio and Cruise Gauge screens. These features are also accessible from the MENU.

  • Page 109: Quick Access Key Features

    Controls and Indicators Quick Access Key Features This section describes the features accessed through the Quick Access Keys located to the left of the display. These features are also accessible from the MENU. Gauge Display The Gauge Display screen for viewing engine statistics can be accessed by pressing the Quick Access Key or by selecting “Gauge Display”...
  • Page 110 Section 4 Gauge Display - Soft Key Commands VIDEO ON / OFF – displays full-screen input from video in. Pressing the key a second time overlays a reduced video window onto the Gauge Display screen. A third key press turns off the video feature.
  • Page 111 Controls and Indicators CRUISE SETUP – accesses user profiles and cruise controls The Cruise feature is explained in more detail in the “Cruise Setup Screen” section. 4-31...

  • Page 112: Gps Display

    Section 4 GPS Display The GPS Display screen can be accessed by pressing the Quick Access Key or by selecting “GPS Display” from the Menu options. The GPS feature displays map data and up to 3 configurable gauges, Latitude and Longitude coordinates, time and speed. Additional Soft Key Commands are accessed by pressing 4-32...
  • Page 113 Controls and Indicators GPS Display - Soft Key Commands UP – LEFT – RIGHT - DOWN – facilitates navigation of the GPS map by moving the cross-hairs accordingly. SPLIT MODE – toggles between a split screen with up to 3 gauges, or a full map screen without gauges.
  • Page 114 Section 4 TRACK INFO – Tracking shows the current route and any waypoints you have set. A green arrow indicates your current position, while the red square indicates the initial point of tracking. Additional Soft Key Commands for Track Info include: SAVE TRACK –...

  • Page 115: Clarion Audio

    Controls and Indicators Clarion Audio Clarion Audio can be accessed by pressing the Quick Access Key by selecting “Clarion Audio” from the Menu options. This feature provides universal audio controls for FM band radio and CD music discs. Clarion Audio - Soft Key Commands VOLUME UP –...
  • Page 116 Section 4 PLAY/PAUSE – toggles between Play and Pause modes when a CD is playing. MUTE – mutes the sound for both FM Band and CD Disc. SOURCE POWER – toggle power on and off. BAND DISC – select between Band for listening to FM radio or Disc for playing music CDs.

  • Page 117: Cruise Gauge Screen

    Controls and Indicators Cruise Gauge Screen The Cruise Gauge Screen can be accessed by pressing the Quick Access or by selecting “Cruise Gauge Screen” from the Menu options. This feature displays rider/skier profiles for cruise controls based on user preference for speed. The screen also displays the ballasts located on each side and center of the boat.
  • Page 118 Section 4 Cruise Gauge Screen - Soft Key Commands CHANGE USER – select a predefined user. Additional Soft Key Commands for Change User include: SELECT – selects the currently displayed user. UP – DOWN – use Up and Down to scroll through the list of users. INC –...
  • Page 119 Controls and Indicators VIDEO ON/OFF – toggles the video on or off. Pressing Video On/Off from the Cruise Gauge screen launches a small video window overlay, allowing user, cruise and gauge information to be viewed simultaneously. NOTE: Full-screen video is not available on the Cruise Gage screens.
  • Page 120 Section 4 Additional Soft Key Commands for Cruise Setup include: NEW USER – provides an interface to add new user information. Use PREV / NEXT arrows to navigate alpha/numeric keys. Press SELECT when a desired character is highlighted. Press Save when user information is complete.
  • Page 121 Controls and Indicators Additional Soft Key Commands for Load USB include: COPY ALL – copies every entry in the currently selected list to the opposite list. DELETE – deletes the currently selected user entry from the list. DELETE ALL – deletes all entries from the currently selected list. SWAP ALL –...

  • Page 122: Menu Options

    Section 4 MENU Options The MENU is displayed by pressing . The following features are available: • Gauge Display – provides a series of screens that display engine and auxiliary information in a variety of formats. This feature is covered in the Quick Key Access section. •...
  • Page 123 Controls and Indicators • Cruise Settings – facilitates creation and maintenance of rider/skier profiles for cruise controls based on user preference for speed. This feature is covered in the Quick Key Access section. • Engine Diagnostics – displays a list of engine fault codes and descriptions;...

  • Page 124: Engine Diagnostics

    Section 4 Engine Diagnostics When choosing this selection, the display will query the engine(s) ECU and provide feedback on any diagnostic codes that have been activated and stored in the ECU for service needs. The Engine Diagnostics option displays faults based on engine or transmission source.

  • Page 125: Fault Code Pop-Ups

    Controls and Indicators • FMI – “Failure Mode Indicator” - fault code The FMI is defined by SAE J1939. If not translated into text, see the SAE standard, or the engine manufacturer's literature. • Count – The number of times the event has been flagged. •...
  • Page 126 Section 4 How to Hide/Show Faults To hide the fault code pop-up being displayed on the screen, press the soft key next to the “Hide” icon. The pop-up will disappear, however the “Warning” or “Stop” icon will remain on the screen to indicate there is still a fault.

  • Page 127: User Settings

    Controls and Indicators User Settings User Settings provide options to specify viewing preferences. Pressing PREV and NEXT navigates through the options, and UP and DOWN scrolls through the selections for each option. Ambient Light Night and Day options are provided for ambient lighting. The screens below illustrate these options.
  • Page 128 Section 4 NavLight Enabling NavLight allows the unit to automatically display in Night View when the NavLight switch on the console is flipped to ‘On’. You can still toggle between Day and Night View through the soft key commands. Brightness You can set the brightness control by using the UP and DOWN soft keys to change the settings in 5% increments until the desired brightness is achieved.
  • Page 129 Controls and Indicators Depth Buzzer Enable this feature to activate an audible alarm any time the minimum depth level is breached. Audio Intensity The Audio Intensity feature allows you to set values to automatically increase or decrease the audio volume according to current speed and intensity level.
  • Page 130 Section 4 River Mode River Mode can be enabled to counteract the effect of water current on speed and wake size by speeding up or slowing down the vessel. Once enabled, softkeys are available on the cruise display to select upstream or downstream. This option is enabled as a global setting for the LINC system in the User Settings menu, but can then be controlled in the Cruise Screen in LINC.

  • Page 131: Utilities

    Controls and Indicators Utilities The Utilities menu option allows you to reset external gauges, configure wiring and communication settings, and change rudder angle. It is typically only accessed when the unit is first installed in order to configure the unit. System Settings The System Settings screen displays the current software version loaded on the unit.

  • Page 132: Gps Utilities

    Section 4 Trip Reset This option resets the trip computer and fuel economy calculations. A DST or GPS device must be installed to receive speed data in order for the fuel economy calculations to work. GPS Utilities When using a GPS device, GPS Utilities will allow you to configure and monitor satellite tracking data.
  • Page 133 Controls and Indicators Depth and Position Setup This feature allows you to define the amount of detail to display for longitude and latitude information on the GPS map and depth display. You can set individual settings for the available options, or choose to select RESTORED DEFAULTS for the factory settings.
  • Page 134 Section 4 Time Setup Parameters – is used to select correct time zone and clock mode for either 12-hour or 24-hour time formats. You can also enable DST (Daylight Savings Time) by using the Check/Uncheck key to select the box. Waypoint Manager Waypoints allow you to mark specific locations by latitude and longitude.
  • Page 135 Controls and Indicators Track Manager You can set up multiple tracks for displaying on the GPS map. The Track Manager allows you to select tracks to ‘show’ on the map or ‘hide’ a map you are not currently using. You may DELETE one track or ‘Delete All Tracks’...

  • Page 136: Troubleshooting

    1. Check display supply wires are connected properly to battery. 2. Verify battery is charged properly. 3. Check battery for efficient starter current. Display has no backlight. Contact your Nautique dealer. Display has no keypad backlight. Contact your Nautique dealer. 4-56...

  • Page 137: Standard Equipment

    The watersports tow point (pylon) is manufactured from high- strength stainless steel. If the pylon becomes loose, stop using the pylon and take the boat to your Nautique dealer for service. Misuse of the tow point can cause death or serious injury. The pylon was designed for water skiing only.

  • Page 138: Bow Features Of Your Nautique

    Dealer, customer, promotional representative or any other person, known or unknown to Correct Craft, Inc. Bow Features of Your Nautique The open bow section of your boat has removable cushions. The center section may be equipped with an optional cushion which can be removed and stored in the trunk or under the observer’s...

  • Page 139: Driver's Seat Adjustment

    Controls and Indicators Driver’s Seat Adjustment The driver’s seat can be adjusted fore and aft and rotates side-to- side. To slide seat, pull the lever (A) forward, slide into position, and release the lever to secure in locked position. To rotate seat, push down on the lever (B) and rotate seat to the desired position.

  • Page 140: Rearview Mirror Adjustment

    Section 4 Rearview Mirror Adjustment The rearview mirror can be positioned on the windshield to observe a skier and traffic behind you. The mirror should be lowered when trailering or when using a mooring cover. To reposition the mirror bracket on the windshield frame, loosen the three socket head screws and reposition and tighten the screws in the new location.

  • Page 141: Observer's Seat

    Controls and Indicators Observer’s Seat Lift up on the bottom of the observer’s seat cushion to access storage under the bow area. You can leave the seat in the “UP” position to help dry the carpet. Storage Hatch To open the storage hatch, lift the latch and turn counterclockwise. The gas shock will help raise the hatch.

  • Page 142: Engine Cover Hatch

    Section 4 Engine Cover Hatch To open the engine cover hatch, lift the latch and turn counterclockwise. The gas shock will help raise the hatch. To close and latch the hatch, pull down on the hatch and allow the hatch to close firmly.

  • Page 143: Walk-Thru Windshield Opening/Latching

    Controls and Indicators Walk-Thru Windshield Opening/Latching There are two latches on the inside starboard side of the walk-thru windshield. Rotate both of the window locks (A) to secure or unlock the window. Always have window closed and secured when trailering the boat. CORC039B An open window can cause death or serious injury.

  • Page 144: Boarding Platform

    Section 4 Boarding Platform The boarding platform of your boat is a convenient feature to enhance the watersports experience. There are serious safety concerns regarding the use of the platform. Correct Craft, Inc. has placed warning labels at the driver’s position, on the deck at the rear of the occupant area and on the transom.

  • Page 145: Engine Cooling Water Intake Valve

    Controls and Indicators Engine Cooling Water Intake Valve Your Nautique is equipped with a valve (seacock) on the engine cooling water intake. The handle has a slide mechanism to prevent the valve from being shut off inadvertently. The valve is used to shut off the water supply in the event a hose failure or water leakage occurs.
  • Page 146 Section 4 T-HANDLE CORC0259 T-HANDLE CORC0227 4-66...
  • Page 147 Controls and Indicators T-HANDLE CORC0246 T-HANDLE CORC0258 4-67...

  • Page 148: Fuel Tank

    Section 4 Fuel Tank There is a fuel tank fill cap on the port and starboard side for added convenience. Use the fuel tank fill cap key to remove the fuel fill cap to fuel your boat. Use caution when fueling your boat. Avoid overfilling of the tank by monitoring the fuel level gauge while fueling.

  • Page 149: Battery Charger - Optional

    United States will require your Nautique dealer to install the proper electrical plug on the battery charger AC supply cord. Your Skippers Kit will contain a manual...

  • Page 150: Folding Instructions For Flight Control Tower Optional

    Section 4 Folding Instructions for Flight Control Tower ® – Optional Crush hazard. The Flight Control Tower is heavy. Use care to fold or unfold the tower. 210, 216, 226 and 230 - Flight Control Tower ® Series 5 (FCT 5) The Flight Control Tower Series 5 has two folding positions.
  • Page 151 Make sure the hardware is securely tightened after it is loosened. Nautique towers are pre-wired so audio speakers can be added to the tower. The plugs have a “fish line” to retrieve speaker wires through the towers.
  • Page 152 Section 4 200 - Flight Control Tower ® Series 3 (FCT 3) Remove all boards from the board racks prior to folding the tower. Make sure to support the tower before unlocking the tower lock handles. To Lower: Support the tower. Push the lock handles (A) down and rotate fully, until they stop.

  • Page 153: Anchor Storage Locker (216, 226 Only)

    Make sure the hardware is securely tightened after it is loosened. Nautique towers are pre-wired so audio speakers can be added to the tower. The plugs have a “fish line” to retrieve speaker wires through the towers.

  • Page 154: Bimini Top

    Section 4 Bimini Top Your Nautique may be equipped with a bimini top which can be used for securing lighter watersports equipment. The top can be tilted by removing the aft pins (A) and allowing the top to tilt, to load the equipment.
  • Page 155 Controls and Indicators COR0238 4-75...

  • Page 156: Ballast Tanks

    Section 4 Ballast Tanks The tanks increase the wake for wake boarding, making your Nautique the most versatile watersports tow package in the world. Ballast Tank Control Switches Press the button for the ballast tank you choose to fill or drain.

  • Page 157: Optional Accessories

    Optional accessories are available from your Nautique dealer. Your dealer may have a wide range of other accessories available to enhance your watersports or pleasure boating experience. Contact your Nautique dealer for more information. Here are just a few of the fine accessories Nautique offers: • Pull-out Cleats...
  • Page 158 Section 4 • Sun Pad Cargo Net - 210 Only CORC179 4-78...

  • Page 159: Boat Systems

    Section 5 Boat Systems Knowing the systems, controls and indicators on your boat is essential for safe and proper operation. Systems which inspected regularly or maintained can cause death, serious injury or damage to product. Inspect and maintain all systems to prevent unexpected hazards associated with worn or faulty components.
  • Page 160 Section 5 FUEL RETURN FUEL FEED FUEL TANK FUEL TANK VENT VENT (200 ONLY) (ALL EXCEPT 200) FUEL FILL FUEL FILL FUEL FILTER CORC0291...

  • Page 161: Ballast Tanks And Bilge System

    Boat Systems Ballast Tanks and Bilge System NOTICE The Federal Water Pollution Control Act prohibits the discharge of oil or oily waste into the water. Violators can be fined $5,000.00. Do not allow water to accumulate in the bilge area of your boat.

  • Page 162: Ballast Tank Valves - 200

    Section 5 Ballast Tank Valves - 200 PORT BALLAST BELLY BALLAST STARBOARD RAW WATER T-HANDLE BALLAST CORC0305 Ballast Tank Valves - 210 T-HANDLE PORT TANK STARBOARD INTAKE/DRAIN TANK ENGINE VALVE BELLY TANK INTAKE/DRAIN COOLING INTAKE/DRAIN VALVE VALVE VALVE CORC0255...

  • Page 163: Ballast Tank Valves - 216

    Boat Systems Ballast Tank Valves - 216 T-HANDLE PORT TANK INTAKE/DRAIN ENGINE STARBOARD TANK BELLY TANK VALVE COOLING INTAKE/DRAIN VALVE INTAKE/DRAIN VALVE VALVE CORC0227A Ballast Tank Valves - 226 T-HANDLE PORT TANK STARBOARD TANK ENGINE BELLY TANK INTAKE/DRAIN INTAKE/DRAIN VALVE COOLING INTAKE/DRAIN VALVE...

  • Page 164: Ballast Tank Valves - 230

    Section 5 Ballast Tank Valves - 230 T-HANDLE BELLY TANK ENGINE INTAKE/DRAIN COOLING STARBOARD VALVE PORT TANK VALVE TANK INTAKE/DRAIN INTAKE/DRAIN VALVE VALVE CORC0256...

  • Page 165: Belly Ballast Tank And Bilge System

    Boat Systems Belly Ballast Tank and Bilge System HULL VENT BELLY BALLAST TANK FORWARD BILGE PUMP BELLY TANK INTAKE/DRAIN VALVE BILGE DRAIN BELLY TANK PUMP BILGE PUMP CORC0229...

  • Page 166: Port And Starboard Ballast Tanks

    Section 5 Port and Starboard Ballast Tanks PORT STARBOARD INTAKE/DRAIN INTAKE/DRAIN VALVE VALVE VENT VENT REAR REAR BALLAST TANK BALLAST TANK PORT STARBOARD TANK PUMP TANK PUMP CORC0230...

  • Page 167: 12-Volt System

    Boat Systems 12-Volt System – 200, 210 Only PORT STARBOARD BATTERY BATTERY (210 only) NEGATIVE STUD ON MOTOR BATTERY SWITCH PANEL CORC029...

  • Page 168: 12-Volt System

    Section 5 12-Volt System – 216, 226 Only POWER MANAGEMENT ACCESS/ CIRCUIT BREAKERS/ BATTERY SWITCH/ BREAKER PANEL BATTERY NEGATIVE STUD ON MOTOR CORC0233 5-10...

  • Page 169: 12-Volt System - 230 Only

    Boat Systems 12-Volt System – 230 Only BATTERY NEGATIVE STUD ON MOTOR BATTERY SWITCH PANEL CORC0292 5-11...

  • Page 170: Heater System - Optional

    Section 5 Heater System - Optional HEATER INTAKE GRILLE HEATER HEATER DUCTS ENGINE CORC0231 5-12...
  • Page 171 Boat Systems The heater system has a heating core, ducts, diffusers and a three- speed fan to deliver heat to the cockpit and windshield. The duct diffuser at the windshield can be closed and rotated to direct air flow. The floor ducts can also be closed to control air flow. The aft duct and diffuser can be pulled out of its socket to direct flow in other locations of the cockpit.
  • Page 172 Section 5 NOTES 5-14...

  • Page 173: Getting Underway

    DO NOT operate the boat if any problem is found during this inspection. Problems found during this inspection should be handled by your Nautique dealer. The following checks are essential to safe boating and must be performed before starting the engine.

  • Page 174: Safety Equipment

    Section 6 Safety Equipment Federal and local laws require certain safety equipment to be on- board at all times. In addition, responsible boaters carry other equipment in case of emergency. Check with local boating authorities for any additional requirements over and above the federal requirements.

  • Page 175: Gasoline Containing Alcohol

    The implementation of ethanol-based fuel is spreading rapidly throughout the United States. As such, PCM Engines and Nautique provide the following information regarding the use of this fuel. This information addresses the use of ethanol fuels in PCM Engines and Nautique boats.
  • Page 176 Section 6 Without proper fuel filtration or fuel stabilization, ethanol blended fuel may cause the following: • Excessive moisture (water) can cause lean operation, hard starting, and operating difficulties such as vapor lock and low speed stalling, and can reduce fuel shelf life. •...

  • Page 177: Boarding

    OFF when swimmers, divers and skiers are boarding or even near the platform. Boat Planing The performance of your Nautique boat depends on load weight and distribution. DISTRIBUTE WEIGHT EVENLY, from bow to stern, and also from port to starboard.

  • Page 178: Pre-Operation Checks

    Checking these items periodically will soon become a habit. If leaks or other abnormal conditions are found, stop using the boat and contact your Nautique dealer to have the problem corrected. Get into the habit of performing these checks in the same order each time so that it becomes routine.
  • Page 179 • Check all gasoline line connections. Connections are located at the fuel tank, the fuel control cell and the fuel injection system. All Nautique boats are equipped with anti-siphon valves on the outlet fittings of the fuel tanks to reduce the chance of fuel siphoning from the fuel tank if a fuel hose leaks or is severed.
  • Page 180 • Once the boat is in the water, visually check for water leaking at the stuffing box. There should be no leakage from the “dripless stuffing box.” If the “dripless stuffing box” is leaking, pull the boat out of the water and have your Nautique dealer service the stuffing box.
  • Page 181 Getting Underway • Make sure there are no ropes, gear bags, arms/legs near the belts and pulleys of the engine. Severe injury can result by becoming entangled in the belts of the engine while it is running. Make sure the boat is deep enough in the water to supply the water intake with water to cool the engine.
  • Page 182 Section 6 In order to prevent personal injury to you or others, the engine cover must be closed whenever the engine is running. • DO NOT operate the engine with the engine cover open or while someone is in the area of an open engine cover. •...

  • Page 183: Flooded Engine

    Section 4 “Run Mode.” DO NOT operate the start switch for more than 30 seconds. Allow the starter to cool. We suggest you bring your boat back to your Nautique dealer after 25 hours of operation for an inspection of the shaft alignment, stuffing boxes adjustment, and the fuel system checked for leaks.
  • Page 184 Read the “Notice to Dealer” located in your Skipper’s Kit. It contains pre-delivery checks and adjustments which must be performed by your Nautique dealer. It is still the boat owner’s responsibility to make sure they were performed. This will also help you become more familiar with your boat and its systems.

  • Page 185: Break In Procedure

    Getting Underway Break In Procedure Make sure all your passengers are properly seated before starting the break in procedure. After the engine is thoroughly warmed up and you have driven the boat into a large open area, advance the throttle to wide open until the maximum rpms are reached. DO NOT exceed 5,000 rpm.

  • Page 186: Shifting

    Practice steering your boat. Make sure the steering system is working correctly and is properly maintained. The steering system must be in good operating condition for safe boating. Frequent inspection, lubrication and adjustment by your Nautique dealer is recommended. 6-14...

  • Page 187: Stopping

    Getting Underway Stopping Stopping the engine immediately after operating at high speed is not recommended. Allow the engine a two to three minute cool- down period at idle or low speed. Refer to your engine operator and maintenance manual for stopping information.
  • Page 188 Section 6 NOTES 6-16...

  • Page 189: Running

    Section 7 Running Nautique urges you and all others operating your boat to seek certified instruction from the local boating authorities. This section is designed to present the most basic operational principles. It is NOT intended to cover all conditions encountered during operation.

  • Page 190: Maneuvering Techniques

    Steering response depends on three factors: rudder position, motion and throttle. Maneuvering in congested areas and advanced courses requires mastering and good “Rules of the Road” ethics. Your Nautique boat is designed to be responsive and agile enough to meet the challenge of these conditions.

  • Page 191: Tow Pattern

    Unequal thrust is an aspect shared by all single-engine propeller- driven watercrafts. All Nautique V-Drives have a counterclockwise (left-hand) rotation propeller. Propeller rotation has a direct effect on steering, especially when operating your boat in reverse. The operator...

  • Page 192: Freezing Temperatures

    A Danforth anchor is recommended for general boating. For more information on anchors, contact your Nautique dealer. Improper use of an anchor can pull a boat underwater causing death or serious injury.

  • Page 193: Dropping Anchor

    Running KC-1571C Danforth Anchor Dropping Anchor • Make sure the line is tied to the anchor and tie the other end to the forward cleat or bow eye. • Head the boat into the wind or current over the spot where you want to lower the anchor.

  • Page 194: Weighing (Pulling In) Anchor

    Section 7 LINE SIX TO SEVEN TIMES DEPTH OF WATER CORC136 Anchoring • Pull on the line to make sure the anchor is holding. • Occasionally check your position against the shoreline. If the anchor is dragging and you are drifting, reset the anchor. Weighing (Pulling In) Anchor Start the engine and move forward until the anchor line is straight up and down.

  • Page 195: Performance Boating

    Nautique boats are the ones of choice of the better professional and amateur ski shows and tournaments. You may have seen drivers put their Nautique through extreme maneuvers.
  • Page 196 Section 7 NOTES...

  • Page 197: Care And Maintenance

    Section 8 Care and Maintenance This section describes how to care and maintain your Nautique boat. Periodic inspection and maintenance of items listed in this section is absolutely necessary. Winterization and some engine maintenance functions are best performed by your Nautique dealer. Some maintenance items that can be done by you or your dealer are listed below.

  • Page 198: Engine Intake Water Strainer

    Section 8 4. When servicing the ignition switch or any wiring, always disconnect the battery cables from the battery. 5. Check for water circulation when the engine is running. Exhaust should contain steady flow of water. In closed cooling systems, make sure the coolant in the cooling system is at the proper level.

  • Page 199: Bilge Pumps

    Wash the bilge with a good biodegradable household detergent or a bilge cleaner available at your Nautique dealer or a marine supply store. Rinse with water with your bilge pumps running. If your pumps seem to lag, remove the top of the pump from the base and check the impeller to make sure there is no debris inside.

  • Page 200: Cartridge Replacement

    Section 8 Cartridge Replacement 1. Turn off power to the bilge pump. 2. Unscrew the filter bowl (A) by turning counterclockwise and pour any excess bilge water remaining in the bowl back into the bilge. 3. Remove the used cartridge (B) and dispose of in a suitable container.

  • Page 201: Propeller

    Care and Maintenance Propeller CAUTION • A propeller can be very sharp. Be careful when you handle it. Wear a pair of protective gloves when handling any propeller. • Remove your key from the ignition and remove the Emergency Stop Switch clip from the switch to prevent accidental starting of the engine.

  • Page 202: Installation

    Section 8 Use a propeller puller to remove the propeller, then remove the key from the keyway. Inspect the keyways and key for any damage. CORC269 Installation Before placing the propeller on the shaft, look at the keyway on the shaft and in the propeller.

  • Page 203: Through-Hull Fittings

    Care and Maintenance Through-Hull Fittings All fittings that actually pass through the hull on the wetted surface are caulked in. These are not serviceable and must not be tampered with. Quick Oil Drain System Change the engine oil after the first 25 hours of operation, then after every 50 hours.

  • Page 204: Salt Water Boating

    Nautique offers an optional freshwater flush kit. This is the only system we recommend if you use your boat in salt water or unusual water conditions. Flushing the system by running the boat in fresh water is another good way to flush the engine, but it must be done immediately.

  • Page 205: Coastal Edition

    9. Remove the water supply hose and reinstall the deck fitting cap securely. Coastal Edition Nautique boats with the Coastal Edition are equipped to effectively resist saltwater corrosion while maintaining premium performance capabilities. Follow these procedures to help keep your Nautique boat operating efficiently.

  • Page 206: Battery Maintenance

    4. Flush the engine with fresh water after each use. See Freshwater Flushing Kit - Optional on page 8-9 for more information. 5. Correct Craft, the manufacturer of Nautique boats, applies dielectric grease to the battery connections at the factory.
  • Page 207 Care and Maintenance Take care when connecting or disconnecting a battery charger. Be sure the charger is turned OFF and unplugged from power source when you clip ON/OFF the connecting clamps. Make sure you have a solid connection with the charging clamps. Poor connections are common causes of electrical arcs and engine problems.

  • Page 208: Gelcoat Maintenance

    Some of these can be caustic. Pay special attention to the cautions on the label of these coatings. Ask your Nautique dealer for advice on which work best in your area.

  • Page 209: Care Of Metal

    If your boat’s gelcoat develops a chalky look over a period of time due to exposure to sun, there are gelcoat buffing and polishing compounds available at your Nautique dealer and marine supply stores. DO NOT use common household scouring pads or powders.

  • Page 210: Adhesive-Backed Non-Skid

    Cleaning Nautique has selected the finest marine grade vinyl for your Nautique. It is important to keep it clean at all times. There are some substances that will stain the vinyl if you leave them on for even a short period of time. Remove any contaminant and clean the area immediately.
  • Page 211 Care and Maintenance Common stains and steps to treat: Step #1 Step #2 Step #3 Chewing gum D then A Eye shadow E then B Engine oil Spray paint Mildew or wet leaves * Shoe polish * Yellow mustard Oil based paint (fresh) Oil based paint (dried) Suntan lotion * Tar/Asphalt...

  • Page 212: Tunable Rudder

    Section 8 Tunable Rudder The Tunable Rudder* is designed to offer easy steering adjustment. This system uses a composite tuning foil which is located at the upper aft corner of the rudder blade. Use a Phillips head screwdriver to adjust the foil.

  • Page 213: Rudder Remote Lube Fitting

    Care and Maintenance Rudder Remote Lube Fitting The remote lube fitting allows for easy access to lubricating the rudder. The remote lube fitting is located at the stern of the engine compartment. Use a quality marine grease and gun. Connect the grease gun to the fitting and apply a light pressure to the gun until you feel a slight resistance.

  • Page 214: Shift Cable

    Section 8 Oil Fill/Drain Oil Fill/Drain Plug Plug Raw Water Drain Plug CORC210 Shift Cable Lubricate pivot points and exposed cable with SAE 30W-30 engine oil. LUBRICATION POINTS CORC211 8-18...

  • Page 215: Troubleshooting

    Troubleshooting The following chart will assist you in finding and correcting minor problems with your Nautique boat. Refer to your engine operation and maintenance manual for more detailed information for any problem concerning the starting, shifting or operation of the engine.

  • Page 216: Trouble Check Chart

    Section 9 Trouble Check Chart Performance Symptom Possible Cause Starter motor will not operate • Shift handle not in NEUTRAL • Battery Selector switch OFF • Battery and electrical connection loose or corroded Engine will not start • Emergency stop switch not in place •...

  • Page 217: Electrical

    Troubleshooting Electrical Symptom Possible Cause Electrical problem • Open circuit breaker or blown fuse • Loose wiring connection • Defective switch or gauge Dim or no lights • Open circuit breaker tripped or in OFF position • Battery discharged • See Page 4-24...
  • Page 218 Section 9 NOTES...

  • Page 219: Storage

    Section 10 Storage Lifting Rings Your Nautique is equipped with bow and stern lifting rings. These are designed to lift your boat in a steady and secure manner. The winch, hooks and other components of the lifting mechanism have sufficient capacity sufficient for your boat. Refer to Section 3, Specifications.
  • Page 220 Section 10 NOTICE Only use a hook that will pass easily through the lifting rings without binding. A hook that is too large or off-center could break the lifting rings. DO NOT use a sling to lift the boat. Damage to your boat can occur.

  • Page 221: Winterizing Your Boat

    When storing your boat up on a rack system, it is important that the racks adequately support the hull bottom. If you do not have a trailer, support the boat like a Nautique dealer recommended trailer. It is important to have an even weight distribution.

  • Page 222: Winterizing The Heater System (In Closed-Cooled Engine Only)

    Section 10 CORC078 The raw water strainer bowl (A) remains full of water even after the rest of the engine cooling water system is drained. To properly winterize your boat, the strainer bowl must be removed and emptied. DO NOT lose the rubber O-ring (B) that seals the bowl to the cap.

  • Page 223: Check For Water In Your Fuel System

    Check your Fuel Control Cell once each year for signs of water in the canister. If it appears there is water buildup in the canister, see your Nautique dealer for service. An empty fuel tank can accumulate water inside by changing temperature and repeated cycles of condensation on the inner surfaces of the tank.

  • Page 224: Winterizing Ballast Tanks (If Equipped)

    Section 10 Add a good quality fuel stabilizer to the fuel prior to winterizing to slow down the rate of fuel decomposition. You can purchase a fuel stabilizer at your servicing dealer, most marinas or an auto supply store. Add the stabilizer to the tank. If you did not add the stabilizer previously, run the engine to circulate fuel throughout the system.

  • Page 225: Trailer/Trailering

    Storage Trailer/Trailering Hitch If you do not already have a trailer hitch installed on your vehicle, go to a reputable hitch company to have the proper size hitch installed. Always use a hitch rated with the appropriate capacity to match the trailer and boat’s gross weight. Loss of control can cause death or serious injury.

  • Page 226: Towing Your Boat

    Section 10 Towing Your Boat Read this checklist prior to trailering your boat. • Check wheel lug nuts for tightness. • Be sure the trailer tongue is securely on the hitch and the safety chains from the trailer are secured to the vehicle. •...
  • Page 227 Storage • Examine the hitch connection to be sure it is firmly attached and the safety pin and chains are securely fastened. • Make sure all trailer lights are still functioning properly. • Re-examine the contents of your boat to ensure that no items such as life jackets or other gear have shifted and will not fly out while you are on the road.
  • Page 228 Section 10 NOTES 10-10...

  • Page 229: Glossary

    Glossary ABYC – American Boat and Yacht Council, Inc. AFLOAT – On the water. AFT – Toward the rear or stern of the boat. AGROUND – Touching bottom. AMIDSHIP – Center or middle of the boat. ANCHOR – (1) An iron casting shaped to grip the lake bottom to hold the boat.
  • Page 230 CAST-OFF – To unfasten mooring lines in preparation for departure. CATHODE – An electrode carrying a negative charge. CAVITATION – A phenomenon in which low pressure within a liquid allows vapor bubbles to form. CENTER LINE – A lengthwise imaginary line which runs fore and aft with the boat’s keel.
  • Page 231 Glossary HYPOTHERMIA – A physical condition where the body loses heat faster than it can produce it. IN-LINE FUSE – A type of protective fuse located in the power wire of a direct current (DC) circuit usually near the battery. KEEL –...
  • Page 232 RUDDER – A vertical metal device used to steer the boat RULES OF THE ROAD – Regulations for preventing collisions on the water. SACRIFICIAL ANODE – Metal parts fitted to the hull of boat to provide a transfer of ions to the cathodic part of an electrolytic coupling and so protect other parts of the boat that would otherwise waste away through electrolysis SLIP –...

  • Page 233: Warranty

    Warranty NAUTIQUE LIMITED WARRANTY (Nautique Boats as Originally Manufactured by Correct Craft) The Nautique warranty is backed by a tradition of boat building experience since 1925. Lifetime Limited Warranty: Correct Craft, Inc, exclusive manufacturer of Nautique, and also referred to as Nautique herein, warrants to the original user or...

  • Page 234: Boat Five (5) Year Transferable Limited Warranty

    Warranty: Nautique warrants to the original user or purchaser, whichever comes first, of each new Nautique boat that the gel coat, under normal authorized use, shall remain free from defect in material and workmanship (including cracks not caused by negligence, impact or collision) for a period of three (3) years from date of delivery.
  • Page 235 Any defect or damage covered by this warranty shall, at the discretion of Nautique be repaired free of charge at an authorized dealership or service facility. Repairs will be warranted only for the remainder of the original warranty period.
  • Page 236 Procedure: In the event your Nautique boat has a claim covered by this warranty, the following procedure shall be allowed to secure performance of warranty obligations: 1.

  • Page 237: Nautique Coastal Edition Limited Warranty

    Warranty NAUTIQUE COASTAL EDITION LIMITED WARRANTY (Nautique Boats as Originally Manufactured by Correct Craft) The Nautique warranty is backed by a tradition of boat building experience since 1925. Lifetime Limited Warranty: Correct Craft, Inc, exclusive manufacturer of Nautique, and also...

  • Page 238: Boat Three (3) Year Transferable Limited Warranty

    Gel Coat One (1) Year Non-Transferable Limited Warranty: Nautique warrants to the original user or purchaser, whichever comes first, of each new Nautique boat that the gel coat, under normal authorized use, shall remain free from defect in material and workmanship, cracks not caused by negligence, impact or collision) for a period of one (1) year from date of delivery.
  • Page 239 Any defect or damage covered by this warranty shall, at the discretion of Nautique, be repaired free of charge at an authorized dealership or service facility. Repairs will be warranted only for the remainder of the original warranty period.
  • Page 240 Procedure: In the event your Nautique boat has a claim covered by this warranty, the following procedure shall be allowed to secure performance of warranty obligations: 1.
  • Page 241 Warranty REQUEST FOR TRANSFER OF WARRANTY ON PARTS ** A COPY OF THE PURCHASE RECEIPT MUST BE INCLUDED ** At Correct Craft, Inc.’s discretion, the remaining portion of Correct Craft, Inc. “Boat Five (5) Year Transferable Limited Warranty” of 2006-2011 model boats that covers parts (no labor), can be transferred for $300.00 to the second purchaser within five (5) years from the date of sale to the first purchaser.
  • Page 242 REQUEST FOR WARRANTY TRANSFER OF HULL, DECK, AND STRINGER ** A COPY OF THE PURCHASE RECEIPT MUST BE INCLUDED ** At Correct Craft, Inc.’s discretion, Correct Craft’s Lifetime Limited Warranty against structural defects in material and workmanship of the hull, deck and stringer for 2006-2011 model boats can be transferred, for a nominal fee, to the second purchaser within five (5) years from the date of sale to the first purchaser.

This manual is also suitable for:

Sport 226 2011Sport 216 2011Super air 230 2011

Table of Contents
