Summary of Contents for d&b audiotechnik V-GSUB
- Page 1 V-GSUB Manual 1.2 en...
- Page 2 General information V-GSUB Manual Version: 1.2 en, 10/2016, D2723.EN .01 Copyright © 2016 by d&b audiotechnik GmbH; all rights reserved. Keep this document with the product or in a safe place so that it is available for future reference. We recommend you to regularly check the d&b website for the latest version of this document.
-
Page 3: Table Of Contents
V-GSUB loudspeaker............5 2.1 Product description..............5 2.2 Connections................6 2.3 Operation..................7 2.3.1 Controller settings..............7 2.4 Technical specifications.............. 8 Manufacturer's declarations........... 9 3.1 EU conformity of loudspeakers (CE symbol)......9 3.1.1 WEEE Declaration (Disposal)..........9 d&b V-GSUB Manual 1.2 en... -
Page 4: Safety Precautions
Generally speaking, a distance of 0.5 m (1.5 ft) from magnetic data carriers (floppy disks, audio and video tapes, bank cards, etc.) is sufficient; a distance of more than 1 m (3 ft) may be necessary with computer and video monitors. d&b V-GSUB Manual 1.2 en... -
Page 5: Gsub Loudspeaker
The V-GSUB is a compact high performance cardioid subwoofer for use with d&b V-Point cabinets. The V-GSUB houses two long excursion neodymium drivers in an integrated cardioid setup: an 18“ driver in a bass-reflex design facing to the front and a 12” driver in a two chamber bandpass design radiating to the rear. -
Page 6: Connections
2.2 Connections The cabinet is fitted NLT4 F/M connectors. All four pins of both connectors are wired in parallel. The V-GSUB uses the pin assignments 2+/2–. Pins 1+/1– are designated to TOP cabinets. Using one as the input, the second connector allows for direct connection to a second cabinet. -
Page 7: Operation
It can be used when actively driven V-GSUBs are used to supplement V-Point cabinets operated in full range mode. The 100 Hz mode can also be used to compensate for the effect of close coupling between the V-GSUB and V-Point cabinets operated in CUT mode. d&b V-GSUB Manual 1.2 en... -
Page 8: Technical Specifications
2 x NLT4 F/M optional 2 x NL4 M or 2 x EP5 Pin assignment NLT4 F/M and NL4 M: 2+ / 2– V-GSUB frequency response, standard and 100 Hz mode EP5: 3: + / 4: – Weight 61 kg (135 lb) V-GSUB cabinet dimensions in mm [inch] d&b V-GSUB Manual 1.2 en... -
Page 9: Manufacturer's Declarations
Please dispose of this product according to the respective national regulations or contractual agreements. If there are any further questions concerning the disposal of this product, please contact d&b audiotechnik. d&b V-GSUB Manual 1.2 en... - Page 11 www.dbaudio.com...
