S E R V I C E & P A R T S M A N U A L
This manual covers UK/EC models manufactured from:
ISSUE 5
Version 2.0 Serial No. 000745 –001199
23.09.2008
Version 3.0 Serial No. 001200 onwards
CAUTION MICROWAVE EMISSIONS
DO NOT BECOME EXPOSED TO EMISSIONS FROM THE MICROWAVE
GENERATOR OR PARTS CONDUCTING MICROWAVE ENERGY
o.
402s Ovens Part. N
32Z3539 Issue 5
1
