On-hook line voltage
Off-hook line current
Off-hook loop resistance
threshold
Dial tone frequency
Ringing voltage
Supported dialing type
Antenna
Antenna cable length
Power supply
Temperature range
Maximum relative humidity
Dimensions (HxWxD)
Weight
CGW-T/TS/D Installation and Programming Manual
48VDC
Maximum 25mA
800Ω
400Hz
48Vrms, 25Hz
DTMF
50Ω Impedance, connected via SMA connector
frequency 800 - 2000MHz
3m
9.8ft
Input:
110VAC, 60Hz
220VAC, 50Hz
Output: 9VDC, 800mA
0˚C-45˚C
32˚F-113˚F
95%
212x44x121 mm/8.3x1.7x4.8 inch
550g (1.21 lbs)
33
