CGW-T/TS/D Installation
To install the CGW-T/TS/D unit, perform the steps as follows:
Mount the CGW-T/TS/D unit on the wall as a stand-alone unit or on the 6-fold wall
mount bracket, which is a separate accessory.
Connect the antenna into the Ant. connector on the front panel of the CGW-T/TS/D unit.
Connect the analog trunk interface of the PBX to the Phone/PBX connector on the front
panel of the CGW-T/TS/D unit.
Connect the analog PSTN interface to the PSTN connector on the front panel of the
CGW-D unit (applicable to CGW-D only).
Connect the power supply to the CGW-T/TS/D unit. The unit will start the initialization
and registration. At the end of the process, the LCD will display the signal status
(CGW-T/D only).
NOTE
Adjust the antenna location until an optimal signal level is received.
Figure 3 displays the schematic setup of the CGW-T/TS unit. Figure 4 displays the schematic
setup of the CGW-D unit.
CGW-T/TS/D Installation and Programming Manual
9
