5.2
CGW-TS LED Status Indicators and Diagnostics
When you power-up the CGW-TS, the LEDs indicate the first diagnostics. In most cases
further diagnostics are not needed. Figure 5 displays the LED layout on the CGW-TS.
To perform further diagnostics, connect an analog telephone with an RJ-11 connector to the
trunk connector in the unit. For details on how to perform further diagnostics, see Paragraph
5.2.3.
CGW-T/TS/D Installation and Programming Manual
Figure 5. LED Layout on the CGW-TS
Power
Status
LED #4
LED #3
LED #2
LED #1
17
