Installation Manual

IMPORTANT:
TO THE INSTALLER.
It is the responsibility of
the Installer to ensure that
the water supply to the
dispensing equipment is
provided with protection
against backflow by an air
gap as defined in
ANSI/ASME A112.1.2-1979;
or an approved vacuum
breaker or other such
method as proved effective
by test.
Water pipe connections
and fixtures directly
connected to a potable
water supply shall be
sized, installed, and
maintained according to
Federal, State, and Local
Codes.
Release Date: October 01, 1998
Publication Number: 620911102
Revision Date: May 07, 2014
Revision: E
THIS DOCUMENT CONTAINS IMPORTANT INFORMATION
This Manual must be read and understood before installing or operating this equipment
Ó CORNELIUS INC; 1998-2014
CORNELIUS INC
Telephone (800) 238-3600
ICE/BEVERAGE DISPENSER
MODEL: TRIAD- -150
One Cornelius Place
Anoka, MN 55303-6234
Facsimile (612) 422-3246
PRINTED IN U.S.A
