ICE/BEVERAGE DISPENSER
MODELS: ENDURO-150 (SIX VALVE)

INSTALLATION MANUAL

Release Date: February 24, 2004
Publication Number: 91971RINS
Revision Date: August 3, 2010
Revision: E
Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ENDURO-150 and is the answer not in the manual?

Questions and answers

Related Manuals for Cornelius ENDURO-150

Summary of Contents for Cornelius ENDURO-150

  • Page 1: Installation Manual

    ICE/BEVERAGE DISPENSER MODELS: ENDURO-150 (SIX VALVE) INSTALLATION MANUAL Release Date: February 24, 2004 Publication Number: 91971RINS Revision Date: August 3, 2010 Revision: E Visit the IMI Cornelius web site at www.cornelius.com for all your Literature needs.

  • Page 2: Contact Information

    Commercial Warranty. Cornelius will not be responsible for any repair, replacement or other service required by or loss or damage resulting from any of the following occurrences, including but not limited to, (1) other than normal and proper use and normal...

  • Page 3: Table Of Contents

    Safety Instructions 1 Read And Follow All Safety Instructions ......... 1 Safety Overview .

  • Page 4: Recognize Safety Alerts

    Only trained and certified electrical, plumbing and refrigeration technicians should service this unit. ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE. © 2004-2010, IMI Cornelius Inc. Ice/beverage Dispenser Installation Manual AFETY...

  • Page 5: Safety Precautions

    Publication Number: 91971RINS ARNING OUNTER - 2 - gas leaks in the entire CO © 2004-2010, IMI Cornelius Inc.

  • Page 6: Installation Instructions

    22’’ Wide X 30’’ Deep X 35-5/8’’ High (With Llid Removed Dimensions ED 150: 34’’ High) Z model = 22’’ Wide X 23-1/16’’ Deep X 35-5/8’’ High. © 2004-2010, IMI Cornelius Inc. Ice/beverage Dispenser Installation Manual BC (Beverage Faucets and Coldplate) Z (No Drip)

  • Page 7: Installation Instructions

    3--wire power cord is provided. An adapter plug for the particular country will need to be provided by the Installer. Publication Number: 91971RINS (NSF) silastic sealant (Dow 732 or equal) approximately - 4 - © 2004-2010, IMI Cornelius Inc.

  • Page 8: Adjust Water -To-Syrup Ratio

    5. Set a syrup flow adjuster to get the desired ratio. 6. Test the valve and adjust until a consistent ratio is delivered three consecutive times. 7. Repeat procedure for other valves. © 2004-2010, IMI Cornelius Inc. Ice/beverage Dispenser Installation Manual Figure 1...

  • Page 9: Gate Restrictor Plate

    Adjustment can be made by sliding up or down with nuts loosened, to obtain the desired amount of restriction. Publication Number: 91971RINS Figure 2. GATE RESTRICTOR PLATE - 6 - © 2004-2010, IMI Cornelius Inc.
  • Page 10 Ice/beverage Dispenser Installation Manual Figure 3. Drip Tray Drain Assembly © 2004-2010, IMI Cornelius Inc. - 7 - Publication Number: 91971RINS...

  • Page 11: Plumbing Diagram (Bc Models)

    Ice/beverage Dispenser Installation Manual Figure 4. Plumbing Diagram (BC Model) Publication Number: 91971RINS - 8 - © 2004-2010, IMI Cornelius Inc.

  • Page 12: Plumbing Diagram (B Models)

    Ice/beverage Dispenser Installation Manual Figure 5. Plumbing Diagram (B Model) © 2004-2010, IMI Cornelius Inc. - 9 - Publication Number: 91971RINS...

  • Page 13: Troubleshooting

    B. No CO2 pressure in carbonator. C. Faucet brix requires adjusting. A. Empty syrup tank B. Faucet brix requires adjusting. A. Unit standing with no ice in hopper -- no ice in cold plate cabinet. - 10 - switch). © 2004-2010, IMI Cornelius Inc.

  • Page 14: Flavor Syrups Do Not Dispense

    FLAVOR DISPENSES MORE THAN .5 OZ Contact your local syrup or beverage equipment distributor for additional information and troubleshooting of beverage system. © 2004-2010, IMI Cornelius Inc. Ice/beverage Dispenser Installation Manual Probable Cause A. No 24 volt power to PC board.
  • Page 15 Ice/beverage Dispenser Installation Manual Figure 6. Wiring Diagram (120 V Unit) Publication Number: 91971RINS - 12 - © 2004-2010, IMI Cornelius Inc.
  • Page 16 Ice/beverage Dispenser Installation Manual Figure 7. Wiring Schematic (120V Unit) © 2004-2010, IMI Cornelius Inc. - 13 - Publication Number: 91971RINS...
  • Page 17 Ice/beverage Dispenser Installation Manual Figure 8. Wiring Diagram (220--240 V Unit) Publication Number: 91971RINS - 14 - © 2004-2010, IMI Cornelius Inc.
  • Page 18 Ice/beverage Dispenser Installation Manual Figure 9. Wiring Schematic (220--240 V Unit) © 2004-2010, IMI Cornelius Inc. - 15 - Publication Number: 91971RINS...
  • Page 20 IMI Cornelius Inc. www.cornelius.com...
