Rear Panel Descriptions
Battery Mounts
1)
Accepts Sony® InfoLithium L-Series bat-
teries. Also accepts third party ba eries
compatible with the Sony mount.
PIX 220/PIX 240 User Guide and Technical Information
3
2
1
Fan
2)
Whisper-quiet, low-speed, single, large
diameter fan. Runs continuously.
Mounting Point - ¼ - 20
3)
Stainless-steel threaded a achment point.
5
