PIX 220/PIX 240 User Guide and Technical Information
Power LED
11)
Hold the Menu bu on down, then press
the Control Knob to power on the unit.

Top and Bottom Panel Descriptions

2
1
CompactFlash Slot
1)
Insert CompactFlash media with the
label-side up. Visit
approved
and approved cards.
External DC Input (Hirose 4-pin)
2)
Accepts 10––18 volts DC. Hirose 4-pin con-
nector is wired pin-1 negative (-), pin-4
positive (+). Pin-2 (-) and pin-3 (+) must
be connected in parallel to pins 1 and 4
respectively to charge a ached Li-ion
ba eries. The included XL-WPH3 power
2
v. 1.07 Features and specifications are subject to change. Visit www.sounddevices.com for the latest documentation.
3
www.sounddevices.com/
for an up-to-date list of tested
Time Code / Charge LED
12)
Flashing green: Accurate timecode is main-
tained by internal Li-Ion ba ery.
Flashing amber: ba ery charging. (Time-
code display has precedence)
Alternating Amber / Green: Fault with
internal timecode ba ery.
Solid Red (when PIX is powered up): Time-
code has been reset back to zero and
needs to be re-jammed due to PIX power
being o for more than 4 hours.
5
4 7
supply provides positive DC on pins 3
and 4 and negative DC on pins 1 and 2.
Audio Output - 5-pin XLR
3)
Two channels of active, balanced, line-
level output. Source selected in the Audio
Menu.
Audio Inputs - 3-pin XLR
4)
Active, balanced, analog microphone
or line level inputs.
be switched to accept AES digital input,
channels.
6
8
PIX 240 only: can
