PIX 220/PIX 240 User Guide and Technical Information

Audio

Press the AUDIO bu on (keyboard: F3) to enter the Audio Metering and Gain control screen. From
this screen, the level for both analog (XLR mic/line) and digital (XLR AES, HDMI, or SDI) audio in-
puts can be adjusted. Turn the Control Knob to select between audio tracks, press the Control Knob
to select a track, then turn the Control Knob to adjust the input gain for that track. see Audio Inputs
Press and hold the AUDIO bu on, and then turn the Control Knob to adjust the headphone level.
Press and hold the AUDIO bu on, and then push the Control Knob to cycle through signal source
for the headphones. see Audio Outputs
