Anton/Bauer Universal BP Installation Instructions

1. Remove the four (4) Screws from the face of the Gold Mount
rear of the camera/recorder.
2. Disconnect the power and any data connector between camera and Gold Mount.
3. Position the Universal BP in-between the rear of the camera/recorder and the Gold Mount.
3a: It may be necessary to use the four (4) 3mm silver screws provided to attach the back plate to the
camera first.
4. Reconnect power and any data connectors.
5. Replace Gold Mount and secure with four (4) screws from step #1 or with longer screws provided if
necessary (DO NOT OVER-TIGHTEN).
5a: The four (4) black flat head screws provided are 6/32 x 3/4 and are for use with the JVC 200/250
Cameras.
Anton/Bauer Inc., 14 Progress Drive, Shelton, Connecticut 06484 USA • (203) 929-1100 • Fax (203) 925-4988 • support@antonbauer.com
Europe, B.V. Eurode Business Center, Eurode-Park 1-2, 6461 KB Kerkrade, The Netherlands • (+31) 45 5639220 • Fax (+31) 45 5639222 • eurosupport@antonbauer.com
Singapore Office - Anton/Bauer, 6 New Industrial Road, # 02-02 Hoe Huat Ind. Bld., Singapore 536199 • (+65) 62975784 • Fax (+65) 62825235
®
. This will loosen the Gold Mount from the
Universal BP
www.antonbauer.com
Universal BP

Installation Instructions

The supplied (4) 3mm screws
may be necessary to attach
the Universal – BP to the
camera.
Gold Mount
7595-0331 Rev D
