• If the power cord is to be replaced, replacement work shall be performed by authorised personnel only. • Installation work must be performed in accordance with the national wiring Standards by authorised personnel only. 2 Contents Kelvinator Air Conditioning...
It may cause explosion, fire and burns. Do not disassemble or modify unit. It may cause failure and electric shock. This symbol indicates never to do this Kelvinator Air Conditioning Important safety instructions 3...
If water enters the unit, turn the unit off and disconnect the power, contact a qualified service technician. Hold the plug by the head of the power plug when taking it out. Failure to do so may cause electric shock and damage. 4 Important safety instructions Kelvinator Air Conditioning...
Vertical louvres NOTE: All the pictures in this manual are for explanation Manual control button purpose only. Your air conditioner may be slightly different. The actual shape shall prevail. Remote control Remote control holder Kelvinator Air Conditioning Product description 5...
The battery life during normal use is about six months. • If the remote control does not operate normally, please remove and refit the batteries. If abnormal operation continues, replace with new batteries. up to 8 metres 6 Indoor display unit Kelvinator Air Conditioning...
Press it again to cancel. This function is ideal for into the high speed Turbo mode and the air conditioner maintaining a comfortable sleeping temperature. will work at maximum power. Press again to cancel this function. Kelvinator Air Conditioning Using the remote control 7...
Page 8
It can be switched on/off by pressing the TEMP button. Programmed TEMPERATURE Display lights up when the remote control displays the set temperature. It can be switched on/off by pressing the TEMP button. 8 Using the remote control Kelvinator Air Conditioning...
The temperature indicator on the indoor unit display lights up. MODE Button Press to select AUTO. CONTROl Buttons Set the desired temperature (normally, set between 21ºC to 28ºC). The air conditioner will begin functioning after approximately 3 minutes. Kelvinator Air Conditioning Using the remote control 9...
Press this button again to turn the air conditioner off. The horizontal louvre returns to the closed position upon shut down. tips and information In DEHUMIDIFY mode the fan speed is fixed at low, and Turbo function can be used. 10 Operating the air conditioner Kelvinator Air Conditioning...
The horizontal louvre returns to the closed position upon to flash. shut down. Follow step 1 and 2 to set the new time. tips and information • The clock timer uses a 24 hour clock mode. • The default time for remote control is 12:00PM and it will revert to this when the batteries are changed. Kelvinator Air Conditioning Operating the air conditioner 11...
CONTROl buttons until 09:30 shows in the The Timer indicator on the display panel of indoor unit display of the remote control. will be illuminated. 12 Operating the air conditioner Kelvinator Air Conditioning...
(10) minutes. The air conditioner will quit I FEEl operation if no temperature information is received from the remote control for eleven (11) successive minutes. Kelvinator Air Conditioning Operating the air conditioner 13...
• When the air conditioner is connected to power (initial operation), the horizontal louvre may generate a sound for 10 seconds, this is a normal part of the operation. 14 Operating the air conditioner Kelvinator Air Conditioning...
The operation mode is seen in the following table. heating performance may be reduced. Mode Model Temperature setting Airflow AUTO COOLING 25°C (COOl, FAN) AUTO AUTO HEAT PUMP 25°C (COOl, FAN) AUTO AUTO HEAT PUMP 20°C (HEAT) AUTO Kelvinator Air Conditioning Operating the air conditioner 15...
These may cause the plastic surface to crack or deform. • Never use water over 40ºC to clean the front panel, it may cause deformation or discolouration. NOTE: Supply power must be disconnected before cleaning the indoor unit. 16 Maintenance Kelvinator Air Conditioning...
Page 17
Install the upper portion of the dust filters back into the unit, taking care that the left and right edges line up correctly and place dust filters into position. Kelvinator Air Conditioning Cleaning the air filters 17...
• A white mist may generate due to moisture generated from defrosting process when the air conditioner restarts in HEAT mode operation after defrosting. 18 Operating tips Kelvinator Air Conditioning...
Fan mode from cool or heat mode The compressor will start again when the room temperature rises on COOl mode or falls on HEAT mode (for cooling & heating models only) to the set point. automatically Kelvinator Air Conditioning Troubleshooting 19...
Page 20
If the unit operates at high humidity for a long time, moisture may be generated on the air outlet Moisture on the air outlet grill and then drip off. This is normal. The unit is in defrosting operation and heating will recommence soon. H1 code: defrosting 20 Troubleshooting Kelvinator Air Conditioning...
Page 21
Notes Kelvinator Air Conditioning Notes 21...
Page 22
Notes 22 Notes Kelvinator Air Conditioning...
Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: kELvINATOR SPLIT SYSTEM AIR CONDITIONER This document sets out the terms and conditions of the product In all instances, unless the Appliance is transported by Electrolux or an Electrolux warranties for Electrolux Appliances. It is an important document.
