- Page 1 Inverter Air Conditioner Installation Manual KSV25CRG, KSV35CRG, KSV70CRG, KSV25HRG, KSD25HRG, KSV35HRG, KSD35HRG, KSV50HRG, KSD50HRG, KSV70HRG, KSD70HRG, KSV80HRG, KSD80HRG...
-
Page 2: Table Of Contents
R32 refrigerant warning This product uses R32 difluoromethane refrigerant, which is a mildly flammable gas class 2.2 according according to AS 1677 and must be handled by a refrigeration mechanic with appropriate Australian refrigerant handling licence. 2 Contents Kelvinator Air Conditioning... -
Page 3: Important Safety Instructions
Contact an authorised installer for installation of this unit. disconnected. • Contact an authorised service technician for repair or maintenance of this unit. • Installation work must be performed in accordance with the national wiring standards by authorised personnel only. Kelvinator Air Conditioning Important safety instructions 3... -
Page 4: Choosing A Location To Mount Unit
Avoid a location to which the general public have access. range of room size, please ensure the selection of your air conditioner complies with the Kelvinator selection tool available from www.kelvinator.com.au This product uses mildly flammable R32 refrigerant. Certain levels of refrigerant require minimum room sizes. -
Page 5: Installation Drawing
Flare nuts Mounting plate fixing screws, ST3.9x25 Installation Manual Remote controller User manual Remote controller holder (optional) NOTE: Appearance of outdoor unit and indoor unit may differ from some models. The actual shape shall prevail. Kelvinator Air Conditioning Installation drawing 5... -
Page 6: Indoor Unit Installation
The installation plate provided with the machine differ from appliance to appliance. (Dimensions are in mm unless otherwise stated). Correct orientation of Installation Plate ✓ ✗ ✗ 6 Indoor unit installation Kelvinator Air Conditioning... -
Page 7: Drilling The Wall
2. Note most simple installation is with hole on the right side. Drill the piping hole with a hole core drill of the following size: 65mm for models: KSV25CRG, KSV25HRG, KSD25HRG, KSV35CRG, KSV35HRG, KSD35HRG 75mm for models: KSV50HRG, KSD50HRG, KSV70CRG, KSV70HRG, KSD70HRG, KSV80HRG, KSD80HRG. -
Page 8: Drain Piping
The power and signal cable that connects from outdoor unit to indoor unit do not carry the full compressor current, therefore 1.0mm (or larger) is suitable for this application. 8 Indoor unit installation Kelvinator Air Conditioning... - Page 9 30-50mm 30-50mm Fasten the connection cable with a cable clamp. Re-fit the wire box cover and secure with the screw, then close the indoor unit cover. Kelvinator Air Conditioning Indoor unit installation 9...
-
Page 10: Outdoor Unit Installation
Drain pipe KSV25HRG KSD25HRG 885 x 554 x 365 KSV35CRG KSV35HRG KSD35HRG KSV50HRG 924 x 702 x 382 KSD50HRG KSV70CRG KSV70HRG 924 x 702 x 382 KSD70HRG KSV80HRG 1024 x 810 x 455 KSD80HRG 10 Outdoor unit installation Kelvinator Air Conditioning... -
Page 11: Refrigerant Pipe Connection
KSD25HRG ø 6.35 (1/4") ø 9.52 (3/8") KSD35HRG ø 6.35 (1/4") ø 12.7 (1/2") KSD50HRG ø 6.35 (1/4") ø 12.7 (1/2") KSD70HRG ø 9.52 (3/8") ø 15.9 (5/8") KSD80HRG ø 9.52 (3/8") ø 15.9 (5/8") Kelvinator Air Conditioning Outdoor unit installation 11... -
Page 12: Flaring Work
Cone Dimension A (mm) as per fig. 15 Outer diameter (mm) Copper Max. Min. pipe Clamp ø 6.35 (1/4") Red arrow mark handle ø 9.52 (3/8") ø 12.7 (1/2") ø 15.9 (5/8") 12 Outdoor unit installation Kelvinator Air Conditioning... - Page 13 Fit the cable clamp over the incoming wires to protect from tape (wide) strain, then fit the cover and fix in place with the screw. indoor pipe unit connection pipe vinyl tape (wide) wrap with vinyl tape Kelvinator Air Conditioning Outdoor unit installation 13...
-
Page 14: Electrical Connection
DR, ensure that a click is heard to confirm it has locked into place. Secure the demand response cable in the cable clamp, then fit the terminal block cover and secure with screws. 14 Outdoor unit installation Kelvinator Air Conditioning... -
Page 15: Test Running
M = (L - 5) x A Where: M = Mass of additional refrigerant (g) L = Actual installed connecting pipe length (m) A = Additional refrigerant required per meter of connecting pipe (g/m) (refer to the above table) Kelvinator Air Conditioning Test running 15... - Page 16 Remove the charge hose from the Low pressure charge hose. -76cmHg Fully open the packed valve stems B and A. Securely tighten the cap of the packed valve. Handle Lo Handle Hi Charge hose Charge hose Vacuum pump Low pressure valve 16 Outdoor unit installation Kelvinator Air Conditioning...
- Page 17 Pressing the button while the unit is operating will switch off check point the unit. The test operation should last about 30 minutes. Cover Outdoor unit check point Auto/Cool Manual control button Kelvinator Air Conditioning Electrical and gas leak check 17...
-
Page 18: Information Servicing
A degree of ventilation shall continue during the period that the work is carried out. The ventilation should safely disperse any released refrigerant and preferably expel it externally into the atmosphere. 18 Information servicing Kelvinator Air Conditioning... - Page 19 (by means of shut off valves) in a part of the system remote from the leak. Oxygen free nitrogen (OFN) shall then be purged through the system both before and during the brazing process. Kelvinator Air Conditioning Information servicing 19...
- Page 20 The maximum number of pieces of equipment permitted to be stored together will be determined by local regulations. 20 Information servicing Kelvinator Air Conditioning...
- Page 21 Notes Kelvinator Air Conditioning Notes 21...
- Page 22 Notes 22 Notes Kelvinator Air Conditioning...
-
Page 23: Warranty
Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: KELVINATOR SPLIT SYSTEM AIR CONDITIONER This document sets out the terms and conditions of the product In all instances, unless the Appliance is transported by Electrolux or an Electrolux warranties for Electrolux Appliances. It is an important document. - Page 24 1800 350 067 email: customercare@electrolux.com.au web: kelvinator.com.au Kelvinator. We are part of the Electrolux Family. To add a touch of professional inspiration to your home, visit electrolux.com.au ©2018 Electrolux Home Products Pty Ltd ABN 51 004 762 341 KMAN_AIR_IM_Jan18...
