Connecting to the switch module

To use the Telnet program (in VT100 compatible terminal mode) to access and
control the switch module, you must know the IP address of the switch
module and have an existing network connection. If you need to obtain the IP
address for the switch module or establish a network connection, contact your
system or network administrator. Be sure to use the correct IP address in the
required commands.
Establishing a Telnet session through the management
module
To establish a Telnet session through the BladeCenter unit management
module, complete the following steps.
Note: The sample screens that appear in this document might differ slightly
from the screens that are displayed by your system. Screen content
varies according to the type of BladeCenter unit that you are using and
the firmware versions and options that are installed.
1. In your browser, in the address bar, type:
http://xxx.xxx.xxx.xxx
where xxx.xxx.xxx.xxx is the IP address of the BladeCenter unit
management-module interface.
Note: The default IP address for the BladeCenter unit management
module is 192.168.70.125.
2. Click GO or press Enter.
The Enter Network Password window opens.
3. In the User Name field, type the initial default user name, USERID. In the
Password field, type the initial default password, PASSW0RD (the sixth
character is a zero, not the letter O). The user name and password are case
sensitive.
The management-module Welcome window opens.
4. In the Inactive session timeout value field, select the timeout value for
this Web session and click Continue.
The management-module main window opens.
5. In the left navigation pane, under I/O Module Tasks, click Management.
The I/O Module Management window opens.
6. Click the link for either 3 or 4.
The BladeCenter Management window opens.
7. Make sure that the IP address is the same in the Current IP Configuration
and New Static IP Configuration sections.
