REPAIR PARTS
AUGER HOUSING / IMPELLER ASSEMBLY
1
2
3
NOTE: All component dimensions given in U.S. inches.
IMPORTANT: Use only Original Equipment Manufacturer (O.E.M.) replacement parts.
Failure to do so could be hazardous, damage your snow thrower and void your warranty.
CRAFTSMAN SNOW THROWER - MODEL NO. 254880
2
01.07.019-A
1
01.07.024-B
KEY
PART
NO.
NO.
1
420497X479
2
420498X479
2
1
KEY
PART
NO.
NO.
1
420478
2
411939
3
179582
1 inch = 25.4 mm
2
DESCRIPTION
AUGER ASSEMBLY 30 LH
AUGER ASSEMBLY 30 RH
DESCRIPTION
AUGER BEARING
BEARING PLUG
SCREW 5/16−18 X 1.00
3
