1. "POWER ON/OFF" Switch to turn the unit
on or off.
2. "PHONO" Press to play a vinyl record.
3. "AUX" & AUX IN Jack Press "AUX" to
listen to an external source connected to
the AUX IN jack.
4. "FM/AM" Press to listen to the radio. Press
again to switch between AM and FM mode.
5. "CD" Press to play a CD.
6. "TAPE" Press to play a cassette.
7. REMOTE SENSOR. When using the
remote control, point it towards this sensor.
8. RADIO TUNER DISPLAY
9. "TRACK INCREMENT" During recording,
press to separate tracks.
10. "RECORD" Press to enter record pause
mode.
11. LCD DISPLAY
12. "TUNED ST" INDICATOR. Illuminates
when a station is correctly tuned in.
13. STEREO SPEAKERS
14. STOP
Press to stop playback or
recording.
15/16. PLAY/PAUSE
playback, recording, finalizing or erasing.
During playback, press again to pause.
27. CASSETTE FF&EJECT Press halfway to fast forward, press all the way to end and eject the
tape.
Press to start
Left side View
4
17. OPEN/CLOSE
mode, use to open and close the disc tray.
(Note: This button will not work in FM/AM
mode.)
18. "VOLUME" KNOB Turn to adjust volume.
(Note: volume ranges from 00 to 32.)
19. DISC TRAY
20. NEXT/PREVIOUS TRACK
& FF/REWIND
In CD Mode, press once to skip to the
next/previous track. Press and hold to fast
forward/rewind.
21. "REC LEVEL" KNOB In record pause
mode, turn to adjust the recording level.
22. "FINALIZE" Press to finalize a
CD-R/CD-RW disc.
23. "ERASE" Press to erase or unfinalize a
CD-RW disc.
24. RADIO TUNER KNOB In FM/AM mode,
turn to tune in a station.
25. PHONES JACK
Accepts headphone/earphone plugs.
26. MANUAL/AUTO REC Press to select
mode of track number assignment for
recording.
Rear View
In CD, PHONO or AUX
Hide quick links:
Advertisement
Table of Contents
Need help?
Do you have a question about the ITVS-750 and is the answer not in the manual?
Questions and answers
Turntable won’t spin
The Innovative Technology ITVS-750 turntable may not spin due to the tone arm balancer being incorrectly adjusted. The silver screw on the back of the turntable acts as a balancer for both the turntable and the tone arm. Adjust this screw using a coin and test by moving the tone arm to the middle of the spindle. The tone arm should move freely to the end of the record without resistance before using the turntable.
This answer is automatically generated
The turntable won't spin.
The Innovative Technology ITVS-750 turntable may not spin due to the following reasons:
1. Tone Arm Balance Issue – The silver screw on the back of the turntable acts as a balancer for both the turntable and the tone arm. If it's not adjusted correctly, the tone arm may not move freely, preventing the turntable from spinning. Adjust the screw with a coin until the tone arm moves freely to the middle of the spindle.
2. Tone Arm Holder Secured – If the tone arm is still secured with the fixed rope, it will not function properly. Ensure the fixed rope is loosened and the tone arm is uplifted.
3. Protective Needle Cover Attached – The white protective needle cover must be removed before use. Gently pull it towards the front of the unit.
4. Power Connection Issue – Ensure the AC power cord is properly connected to a wall outlet.
If the turntable still does not spin after checking these points, further troubleshooting may be needed.
This answer is automatically generated
Need replace volume control switch
Need volume control #e-696oai-03
You can control the volume on the Innovative Technology ITVS-750 by turning the "VOLUME" knob. The volume ranges from 00 to 32.
This answer is automatically generated
When i turn the power on the screen lights up for 1-2 seconds and then no power. Nothing works. Where should I start ruling out things.
