Summary of Contents for Innovative Technology ITVS-750
- Page 2 CAUTION: To reduce the risk of fire or electric shock, do not expose this appliance to rain or moisture. WARNING: To prevent electric shock, do not use this (polarized) plug with an extension cord, receptacle or other outlet unless the blades can be fully inserted to prevent blade exposure WARNING: Invisible laser radiation when open and interlock failed or defeated.
- Page 4 1. “POWER ON/OFF” Switch to turn the unit 17. OPEN/CLOSE In CD, PHONO or AUX on or off. mode, use to open and close the disc tray. 2. “PHONO” Press to play a vinyl record. (Note: This button will not work in FM/AM 3.
- Page 5 A. FM wire antenna While tuned to a station in FM mode, extend the wire and reposition to adjust for best reception. B. AUX IN jacks For audio sources with RCA jacks, use plug on end of the RCA cable into these jacks and the other into the audio source.
- Page 6 Setup / Basic Operation Setup 1. Remove white protective needle cover by gently pulling towards front of unit. 2. Remove any packaging materials from the unit. 3. Connect the AC power cord to a wall outlet. Note: To prevent interference, avoid bundling audio signal cables together with the AC power cord. Basic Operation 1.
- Page 7 Battery Replacement When the distance required between the remote control unit and main unit decreases, it is necessary to replace the battery with new ones. Battery Precautions Be sure to insert the batteries with correct positive “+” and negative “-” orientation. ALWAYS use batteries of the same type.
- Page 8 4. Select the appropriate speed (4). 5. Gently push tone arm clip (5) to the right to release the tone arm. 6. Raise the cue lever (6) to lift the tone arm off the tone arm support. 7. Move the tone arm gently to the edge of the record (or the starting point of a track). The turntable will begin to turn.
- Page 9 Display Each time the DISPLAY button is pressed, the display mode will cycle between the following options: - Track Number + Track Play Time (Default Display Mode) - Track Play Time Countdown - Track Play Time - CD Play Time Countdown Repeat Playback Each time the REPEAT button is pressed, the repeat mode will cycle through the following options:...
- Page 10 6. “P-02” is displayed. Repeat steps 4 thru 5 to program the additional tracks. 7. When the selection of track numbers has been finished, press the PLAY button ( ) to start program playback. 8. To cancel the program mode, press the STOP ( ). To check the programmed order In the stop mode, press ( ) repeatedly to show the track numbers that have...
-
Page 11: Before Recording
Important: If both the front and rear AUX INs are connected to AUX IN cables at the same time, only the front one will be active. AUX OPERATION Please use this function to record from other sources such as CDs, karaokes and radio. We also recommend using this function to make the cassette tape to CD recording much easier. -
Page 12: Entering Recording (Paused) Mode
Press the AUTO/MANUAL button repeatedly ( or MANUAL/AUTO INCREMENT on the remote) to cycle between the following modes: “AUTO TRACK -20db” A new track will be assigned automatically when the sound level drops below -20db “AUTO TRACK -30db” A new track will be assigned automatically when the sound level drops below -30db “AUTO TRACK -40db”... -
Page 13: Entering Recording (Play) Mode
2. Test play the audio source to be recorded and adjust “REC LEVEL” Knob to set the recording volume so that its loudest output does not exceed the “OVER” indicator on the meter on the lower right of the display. Note: Be sure not to set the recording volume too low –... -
Page 14: Erasing All Tracks
few minutes in some cases. ERASING A CD-RW (CD-RW ONLY) Erasing processes will only work on an unfinalized CD-RW disc. If a CD-RW disc has been finalized, you will need to unfinalize it prior to erasure. With a CD-RW, it is possible to erase either the last recorded track, or the entire disc. All erasing processes are permanent –... - Page 15 Handling Vinyl Records • Do not touch the record’s grooves. Only handle records by the edges or the label with clean hands. Touching the record surface will cause your record’s quality to deteriorate. • To clean a record, use a soft anti-static cloth to gently wipe the record surface. •...
- Page 16 Specifications GENERAL Power Requirements AC 120 V~ 60 Hz Power Consumption 510x300x340mm Dimensions (W x H x D) (approx.) 12 kg Weight . (approx.) AMPLIFIER Output Power 5 W + 5 W Frequency Response 60 to 20, 000 Hz SPEAKER SYSTEM Type 1-way Impedance...
- Page 17 Both AUX in jacks (front and Unplug the front AUX in • • • external audio device rear) are plugged. Jack. plugged into rear AUX in jack. For further assistance with your product, call Innovative Technology at TOLL FREE# 1-877-ITECH-97 (1-877-483-2497).
- Page 20 750110403E...
Need help?
Do you have a question about the ITVS-750 and is the answer not in the manual?
Questions and answers
Turntable won’t spin
The Innovative Technology ITVS-750 turntable may not spin due to the tone arm balancer being incorrectly adjusted. The silver screw on the back of the turntable acts as a balancer for both the turntable and the tone arm. Adjust this screw using a coin and test by moving the tone arm to the middle of the spindle. The tone arm should move freely to the end of the record without resistance before using the turntable.
This answer is automatically generated
The turntable won't spin.
The Innovative Technology ITVS-750 turntable may not spin due to the following reasons:
1. Tone Arm Balance Issue – The silver screw on the back of the turntable acts as a balancer for both the turntable and the tone arm. If it's not adjusted correctly, the tone arm may not move freely, preventing the turntable from spinning. Adjust the screw with a coin until the tone arm moves freely to the middle of the spindle.
2. Tone Arm Holder Secured – If the tone arm is still secured with the fixed rope, it will not function properly. Ensure the fixed rope is loosened and the tone arm is uplifted.
3. Protective Needle Cover Attached – The white protective needle cover must be removed before use. Gently pull it towards the front of the unit.
4. Power Connection Issue – Ensure the AC power cord is properly connected to a wall outlet.
If the turntable still does not spin after checking these points, further troubleshooting may be needed.
This answer is automatically generated
Need replace volume control switch
Need volume control #e-696oai-03
You can control the volume on the Innovative Technology ITVS-750 by turning the "VOLUME" knob. The volume ranges from 00 to 32.
This answer is automatically generated
