UNPACKING AND SET UP
Carefully remove the unit from the display carton
and remove all packing material from the unit.
Unwind the AC power cord and extend it to its full
length.
Place the unit on a stable level surface, which is
convenient to an AC outlet out of a strong
magnetic field.
Raise the lid to expose the phonograph. The
phonograph has been secured for shipment with
a transit screw. Use a coin or screwdriver to turn
the transit screw clockwise. This will allow the
turntable to "float"
Remove the opaque white plastic stylus cover
from the phonograph stylus by sliding it in the
direction of the arrow.
During this operation pay attention to the stylus,
because the stylus damage is not covered by
guarantee.
Remove the twist-tie that was used to secure the
tone arm during shipment.
Release the tone arm lock lever.
Connect the plug to your AC 100-240V~5
Unit Leg or Feet Assembly
1.
Take out the unit and the legs, put them on a smooth surface.
2.
Loosen the screws under the unit.
3. Insert the wooden leg into the hole and fix it with the screws
well.
4.
Repeat to fix all of the 4pcs legs.
OR
If you want to place the unit on a shelf:
1. Remove the leg fixings from the bottom side and use instead
the short feet.
2. Repeat to fix all of the 4pcs feet.
PRE PAR ATION FOR USE
0-60
Hz
1
outlet
English Instruction Manual
1.
2.按原孔位装上木腿,将用
拆下的螺丝固定即可。

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VTA80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Innovative Technology VTA80

  • Page 1 English Instruction Manual PRE PAR ATION FOR USE UNPACKING AND SET UP Carefully remove the unit from the display carton and remove all packing material from the unit. Unwind the AC power cord and extend it to its full length. Place the unit on a stable level surface, which is convenient to an AC outlet out of a strong magnetic field.
  • Page 2 English Instruction Manual LOCATIONS OF CONTROLS FRONT PANEL 15 17 18 1. Phonograph Lid 12. Stop Button 2. Phonograph Lid Support Bracket 13. DN F-R Button 3. Speakers UP F-F Button USB Socket 15. Play / Mode Button 3.5mm Phones Socket 16.
  • Page 3: Remote Control

    English Instruction Manual REMOTE CONTROL 24. RECORD Open Close 26. EQ Sound settings MODE VOL – 28. P.MODE / MENU Play/Pause - Track backwards STOP 32. PRESET 33. - 10 34. INFO Information 35. REPEAT RANDOM 37. MODE REPEAT RANDOM VOL + - Track forwards + 10...
  • Page 4: Basic Operations

    English Instruction Manual GE TTING STARTED POWER SOURCE This system is . y l Attempting to operate from any other power source may cause damage to the system, and such damage is not covered by your warranty. NOTE : If this plug will not fit into your outlet you probably have an outdated non-polarized AC outlet.
  • Page 5: Fm Radio Operation

    English Instruction Manual FM RADIO OPERATION ANTENA For FM reception there is a 75ohm FM antenna socket (22) and insert the antenna into the socket, move around to obtain the best reception signal. OPERATION 1. Switch ON the MODE/STANDBY BUTTON (10). The Display (19) will light up. 2.
  • Page 6: Turntable Operation

    English Instruction Manual TURNTABLE OPERATION VERY IMPORTANT VERY IMPORTANT! To prevent dam ages from transportation , a transit screw is located at the upper right side of the turntable platform TRANSI T Before start playing use a screwdriver and turn the transit screw in clockwise direction (screw going down) completely SCREW In case of transportation, remember to clock again this screw...
  • Page 7: Playing Compact Discs

    English Instruction Manual PLAYING COMPACT DISCS To start 1. Press MODE/STANDBY BUTTON (10) to select “CD“ mode. 2. Press “open/close” button (9) to open the CD door (8). 3. Place a CD with the printed side facing up inside the tray & then close the co door. 4.
  • Page 8: Bluetooth Operation

    English Instruction Manual BLUETOOTH OPERATION 1. Press MODE/STANDBY (10) button to select “BT” mode, the BT BLUE indicator will light up. 2. Select from your portable device (Smartphone, Tablet...) the ID Bluetooth tagged as “DL-P25” then confirm connection. 3. Now you can transfer the music to the DL-P25. 4.
  • Page 9: Specifications

    English Instruction Manual DELETE USB 1. During USB mode, press DELETE BUTTON (36) one time from Remote Control,“ DEL-ONE” will show on the display. You can delete the playing track. 2. Press UP F.F BUTTON (14) one time and “DEL-FOLD” will show on the display. You can delete the current playing folder.
  • Page 10 FCC Caution This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 11 IC Caution: This device complies with Industry Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) This device may not cause interference; and (2) This device must accept any interference, including interference that may cause undesired operation of the device. To maintain compliance with RF exposure guidelines, this equipment should be installed and operated with a minimum distance of 20cm between the radiator and your body.
