GE Security NetworX Series Installation And Startup page 43

LOC PG
111 28 Segment 3
1 =
Fast Loop Response.
2 =
Double End of Line Tamper zone.
3 =
Trouble zone (Day zone).
4 =
Cross Zone.
Segment 4
1 = Zone Activity Monitor.
2 = End of Line Resistor Defeat.
3 = Zone acts as Request to Exit input.
Segment 5 RESERVED
EVEN NUMBERED
Contains the event code sent for Contact ID or SIA and chosen from the list on pg 16.
format is being used, the number programmed in this location will be sent as the upper hex digit. The digit should be
from 1 to 15 when using 4+2 formats. The zone ID or user ID will be the lower hex digit of the zone that is in alarm.
ODD NUMBERED
The defaults listed below represent the five segments of each of those locations. Use the data from location 111 (table
above and pg 28)
LOC
112 ZONE TYPE 2 ALARM EVENT CODE
113 ZONE TYPE 2 CHARACTERISTIC SELECT
114 ZONE TYPE 3 ALARM EVENT CODE
115 ZONE TYPE 3 CHARACTERISTIC SELECT
116 ZONE TYPE 4 ALARM EVENT CODE
117 ZONE TYPE 4 CHARACTERISTIC SELECT
118 ZONE TYPE 5 ALARM EVENT CODE
119 ZONE TYPE 5 CHARACTERISTIC SELECT
120 ZONE TYPE 6 ALARM EVENT CODE
121 ZONE TYPE 6 CHARACTERISTIC SELECT
122 ZONE TYPE 7 ALARM EVENT CODE
123 ZONE TYPE 7 CHARACTERISTIC SELECT
124 ZONE TYPE 8 ALARM EVENT CODE
125 ZONE TYPE 8 CHARACTERISTIC SELECT
126 ZONE TYPE 9 ALARM EVENT CODE
127 ZONE TYPE 9 CHARACTERISTIC SELECT
128 ZONE TYPE 10 ALARM EVENT CODE
129 ZONE TYPE 10 CHARACTERISTIC SELECT
130 ZONE TYPE 11 ALARM EVENT CODE
131 ZONE TYPE 11 CHARACTERISTIC SELECT
132 ZONE TYPE 12 ALARM EVENT CODE
133 ZONE TYPE 12 CHARACTERISTIC SELECT
134 ZONE TYPE 13 ALARM EVENT CODE
135 ZONE TYPE 13 CHARACTERISTIC SELECT
136 ZONE TYPE 14 ALARM EVENT CODE
137 ZONE TYPE 14 CHARACTERISTIC SELECT
138 ZONE TYPE 15 ALARM EVENT CODE
139 ZONE TYPE 15 CHARACTERISTIC SELECT
140 ZONE TYPE 16 ALARM EVENT CODE
141 ZONE TYPE 16 CHARACTERISTIC SELECT
142 ZONE TYPE 17 ALARM EVENT CODE
143 ZONE TYPE 17 CHARACTERISTIC SELECT
144 ZONE TYPE 18 ALARM EVENT CODE
145 ZONE TYPE 18 CHARACTERISTIC SELECT
146 ZONE TYPE 19 ALARM EVENT CODE
147 ZONE TYPE 19 CHARACTERISTIC SELECT
148 ZONE TYPE 20 ALARM EVENT CODE
149 ZONE TYPE 20 CHARACTERISTIC SELECT
150 ZONE TYPE 21 ALARM EVENT CODE
151 ZONE TYPE 21 CHARACTERISTIC SELECT
152 ZONE TYPE 22 ALARM EVENT CODE
153 ZONE TYPE 22 CHARACTERISTIC SELECT
154 ZONE TYPE 23 ALARM EVENT CODE
155 ZONE TYPE 23 CHARACTERISTIC SELECT
NX-8V2 Control
DESCRIPTION
LOCATIONS 112 – 169
DESCRIPTION
DEFAULT
5 =
Dialer Delay zone.
6 =
Swinger zone.
7 =
Restore reporting.
8 =
Listen-In.
4 = Zone acts as access entry point
configured with Access Control module)
5 -8 = Reserved.
DEFAULT
2
2-125-78-0-0
7
5-1245-5678-0-0
5
45-125-5678-0-0
5
457-125-5678-0-0
4
0-1245-5678-0-0
0
2-0-78-0-0
1
1-13-378-0-0
7
6-1245-5678-0-0
2
24-5-78-0-0
3
3-0-0-0-0
5
457-125-45678-0-0
4
0-12458-5678-0-0
7
5-12456-5678-0-0
5
457-1256-5678-0-0
4
0-12456-5678-0-0
7
5-1245-25678-0-0
5
457-125-25678-0-0
4
0-1245-25678-0-0
7
6-1245-25678-0-0
15
24-15-78
20
24-15-78
21
24-15-78
PROGRAMMING DATA
(Do not enable this segment unless
4+2 Format Note: If 4+2
PROGRAMMING DATA
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
__
__ __ __ __ __
43
