  • Page 1 ™ NetworX Series NX-8V2 Control Panel Installation and Startup...
  • Page 2 GE Security. This document contains proprietary information of GE Security, USA and is furnished to its customer solely to assist that customer in the installation, testing, operations, and/or maintenance of the equipment described. This document shall not be reproduced in whole or in part nor shall its contents be disclosed to any third party without the written approval of GE Security.

  • Page 3: Table Of Contents

    Table of Contents GENERAL DESCRIPTION................................. 4 ORDERING INFORMATION ................................4 III. BOARD INSTALLATION ................................... 4 NX-8V2 WIRING DIAGRAM ................................5 TERMINAL DESCRIPTIONS ................................6 NETWORX KEYPAD MAXIMUM WIRE RUN ..........................6 PROGRAMMING THE LED KEYPADS ............................7 KEYPAD ADDRESS AND PARTITION .............................. 7 CHANGING USER CODES: .................................

  • Page 4: General Description

    The NetworX design allows a fully loaded system to be housed in one single metal enclosure, establishing for the first time, a logical solution and design response to modular systems. Up to 32 modules can be added to expand the capabilities of the NX-8V2. For product warranty information, please refer to the GE Security Product Catalog. ORDERING INFORMATION...

  • Page 5: Nx-8V2 Wiring Diagram

    NX-8V2 WIRING DIAGRAM NX-8V2 Control...

  • Page 6: Terminal Descriptions

    TERMINAL DESCRIPTIONS TERMINAL DESCRIPTION House Telephone Ring (Grey). Telephone Ring (Red). Telephone Tip (Green). House Telephone Tip (Brown). EARTH Earth Ground. Connect to a cold water pipe or a 6 to 10 foot driven rod. AC input. Connect to a 16.5V 40 or 50 VA Class ll U.L. approved transformer. If used as a siren output (default), the speaker rating should be 15 watt at 8 or 16 ohm, or 30/40 watt at 4, 8, or 16 ohms.

  • Page 7: Programming The Led Keypads

    PROGRAMMING THE LED KEYPADS KEYPAD ADDRESS AND PARTITION This section describes how to program the address and partition of each keypad as well as the options that are available. The address of the keypad is important because this is how the panel supervises the keypads. The factory default for the Master code is [1]-[2]-[3]-[4] when using a 4-digit code or [1]-[2]-[3]-[4]-[5]-[6] for a 6-digit code.

  • Page 8: Assigning Authority Level

    ASSIGNING AUTHORITY LEVEL: • Enter [r]-[6]-[master code]. The "Ready" LED will flash. • Enter the 2 digit user number. The "Ready" LED will illuminate steady and the "Instant" LED will flash. • Refer to the chart below for the description of each LED. Turn the LED on for the features that you desire. ATTRIBUTES IF LED 8 IS OFF ATTRIBUTES IF LED 8 IS ON Reserved...

  • Page 9: Exiting A Location

    the [MEDICAL] key. To review the data in a location, repeat the above procedure, pressing [r] without any numeric data entry. Each time [r] is pressed, the programming data of the next segment will be displayed for review. EXITING A LOCATION After the last segment of a location is programmed, pressing [r] will exit that location, turn the "Ready"...

  • Page 10: Programming Example

    PROGRAMMING EXAMPLE FIGURE1 (Numerical Data) Zone 1 LED = 1 Zone 2 LED = 2 Data = 9 Data = 66 Zone 4 LED = 8 Zone 7 LED = 64 To change data in a Pressing [#] will exit a segment, enter the location without data followed by [ ]...

  • Page 11: Loading Factory Defaults

    LOADING FACTORY DEFAULTS To load the factory defaults, enter the program mode using the procedure on page 8, then type [9]-[1]-[0]-[#]. The keypad will beep 3 times indicating that the loading is in progress. The loading takes about 6 seconds. ENROLLING MODULES AND KEYPADS For supervision purposes, the NX-8V2 has the ability to automatically find and store in its memory, the presence of all keypads, zone expanders, wireless receivers, and any other module connected to the data terminal.

  • Page 12: Reporting Events To Phone Number 1

    DIAL ATTEMPTS/BACKUP CONTROL FOR PHONE 1 2 ... numerical Segment 1- Dial attempts: Location 3, Segment 1 is used to enter the number of dial attempts (1 to 15 Attempts) the communicator will make to Phone 1 before ending the notification process. Factory default is "8" and the communicator will make eight (8) attempts to the first number.

  • Page 13: Reporting Events To Phone Number 2

    COMMUNICATOR FORMAT FOR PHONE 2 1..... numerical Location 8 contains the communicator format used to transmit to the receiver connected to Phone 2. Consult the instruction manual for your central station receiver to determine which format is compatible, and select from Table XII-1 COMMUNICATOR FORMAT SELECTIONS on page 11.

  • Page 14: Reporting Events To Phone Number 3

    ACCOUNT CODE FOR PHONE 3 6 .... numerical The account code sent when Phone 3 is dialed is programmed in location 13. Program a A10" in the segment immediately after the last digit of the account code. If the account code is 6 digits long, program all 6 segments. If location 6 is left unprogrammed, account code 1 will be used when the Phone 3 is dialed.
  • Page 15 CUSTOM COMMUNICATOR FORMAT (See loc 2, 8, &14) Segment 1: Segment 2: 1 = On for 1800hz transmit; Off for 1900hz. 1 = On for pager format (no handshake required). 2 = On for 2300hz handshake; Off for 1400hz. 2 = On for 1400/2300 handshake. 3 = On for cksum parity;...

  • Page 16: Default Zone Types (Configurations)

    Segment 2: 1 = On enables the LED Extinguish feature. 2 = On enables the Require Code for Bypassing feature. 3 = On enables the Zone Bypassed Sounder Alert feature. 4 = On enables the AC Power/Low Battery Sounder Alert feature. 5 = On enables Bypass toggle.
  • Page 17 DATA DESCRIPTION OF DEFAULT ZONE TYPES KEYSWITCH ZONE - This zone type will arm and disarm the partition or partitions of the control panel that it resides in each time the zone is shorted. Keyswitch arming will report as user #99. INTERIOR FOLLOWER WITH "CROSS ZONE"...
  • Page 18 Segments 1 - 8: 1 = Partition 1 3 = Partition 3 5 = Partition 5 7 = Partition 7 2 = Partition 2 4 = Partition 4 6 = Partition 6 8 = Partition 8 ZONES 9-16 ZONE TYPE 8 ....
  • Page 19 PARTITION SELECT, ZONES 41-48 8..... feature select Location 36 is used to select the partition or partitions that zones 41-48 reside in. A zone may reside in any combination of the 8 partitions. If a burglary zone resides in more than 1 partition it will only be active when all partitions are armed. A zone that resides in more than 1 partition will be reported to its lowest partition.
  • Page 20 Segment 6: 1 = Enable 2 wire smoke. 2 = Reserved. 3 = Enable for Zone Activity in Hours (not Days) 4 = Enable Daylight Savings Time (DST) 5 = Reserved 6 = On to disable Clean Me report (Default is OFF) 7 = On to disable Start/End Test report (Default is OFF) 8 = On enables Auto LED Extinguish (Default is OFF) Segment 7:...
  • Page 21 GO TO PROGRAM CODE 6..... numerical Location 42 contains the "Go To Program Code". This location contains either a 4 or 6-digit code. If the 6-digit code option is enabled in Location 41, THIS CODE MUST CONTAIN SIX (6) DIGITS. If this option is not enabled in location 41, the last 2 segments (digits) will be ignored.
  • Page 22 AUXILIARY OUTPUT 2, EVENT & TIME 2 .... numerical Segment 1: Use Table XIII-1 to select the event that will activate Auxiliary Output 2. Segment 2: Program the timing from 0-255 (minutes or seconds, depending on data programmed in Segment 2, Location 46). Programming a "0"...
  • Page 23 DAYS OF WEEK EACH PARTITION IS OPEN 8..... feature select Location 54 selects which days of the week each partition is open. On these days, Aarm only after close window@ codes will be able to arm and disarm during open window. NOTE: If any partition is not programmed to be opened and is programmed to Auto-Arm (Location 55), the NX-8V2 will try to arm every 45 minutes for the duration of the closed period unless Auto Retry is disabled in location 55.
  • Page 24 SLOW COMMUNICATOR FORMAT CODES SENSOR MISSING COMMUNICATOR CODE 8 .... numerical Location 61 contains the event code for a zone "Sensor Missing" for a 4+2 format. Refer to the box on page 23. Segment 1 = Partition 1 Segment 3 = Partition 3 Segment 5 = Partition 5 Segment 7 = Partition 7 Segment 2 = Partition 2...
  • Page 25 SLOW COMMUNICATOR FORMAT CODES OPENING COMMUNICATOR CODE 8..... numerical Location 77 contains the digit of a 4+2 format if the "Opening Reporting" is enabled. Refer to the box on page 23. Segment 1 = Partition 1 Segment 3 = Partition 3 Segment 5 = Partition 5 Segment 7 = Partition 7 Segment 2 = Partition 2...
  • Page 26 ACCOUNT CODE FOR PARTITION 3 6 .... numerical The account code sent when partition 3 is reported is programmed in location 92. If location 92 is left unprogrammed (all A10") then the account code corresponding to the Phone number dialed will be used. If the account code is less than six digits, program a A10"...
  • Page 27 PARTITION 6 FEATURE & REPORTING SELECTIONS 5..... feature select Location 102 is used to enable certain features that can be accessed or are visible to the user from the keypad of the system. addition, certain communicator reports are enabled in this location. Each of these features can be enabled by partition. This location contains 5 segments, with eight possible features per segment.
  • Page 28 LOCATIONS 110-169 ARE USED TO CHANGE THE ZONE TYPES (Configurations) AS LISTED IN THE TABLE ON PAGE 16. THESE LOCATIONS ARE CONSIDERED ADVANCED PROGRAMMING AND SHOULD ONLY BE CHANGED WITH A THOROUGH UNDERSTANDING OF THE OPERATION OF EACH BIT. ZONE TYPE 1 ALARM EVENT CODE 1 ....
  • Page 29 ZONE TYPE 4 ALARM EVENT CODE 1..... numerical Location 116 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details. ZONE TYPE 4 CHARACTERISTIC SELECT 5.....
  • Page 30 ZONE TYPE 14 ALARM EVENT CODE 1 .... numerical Location 136 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details. ZONE TYPE 14 CHARACTERISTIC SELECT 5 ....
  • Page 31 ZONE TYPE 24 ALARM EVENT CODE 1..... numerical Location 156 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details. ZONE TYPE 24 CHARACTERISTIC SELECT 5.....

  • Page 32: Programming Worksheets

    XIV. PROGRAMMING WORKSHEETS (Factory defaults for segments are in bold italics text and "Quick Start" locations are identified with the L symbol.) DESCRIPTION DEFAULT PROGRAM DATA PHONE 1 14-14-14-14-14-14-14-14-14-14- __ __ __ __ __ __ __ __ __ __ 14-14-14-14-14-14-14-14-14-14 __ __ __ __ __ __ __ __ __ __ PHONE 1, ACCOUNT CODE 10 - 10 - 10 - 10 - 10 - 10...
  • Page 33 DESCRIPTION DEFAULT PROGRAM DATA PHONE 3, SELECTING WHICH PARTITIONS REPORT TO PHONE 3 Segment 1 (Circle Numbers To Program) 1 = Partition 1 3 = Partition 3 5 = Partition 5 7 = Partition 7 2 = Partition 2 4 = Partition 4 6 = Partition 6 8 = Partition 8 FORMAT OVERRIDE...
  • Page 34 DESCRIPTION DEFAULT PROGRAM DATA ZONES 1-8, PARTITION SELECTION (Segment 1=Zone 1 thru Segment 8=Zone 8) Segments Partition 1 Partition 2 Partition 3 Partition 4 Partition 5 Partition 6 Partition 7 Partition 8 ZONES 9-16, ZONE TYPES 6-6-6-6-6-6-6-6 _ _ _ _ _ _ _ _ ZONES 9-16, PARTITION SELECTION (Segment 1=Zone 9 thru Segment 8=Zone 16) Segments Partition 1...
  • Page 35 DESCRIPTION DEFAULT PROGRAM DATA SIREN AND SYSTEM SUPERVISION Segment 1 (Circle Numbers To Program) Siren sounds for telephone line cut while armed. Siren sounds for telephone line cut while disarmed. Siren blast at arming. Siren blast at exit delay expiration. Siren blast at closing kissoff.
  • Page 36 DESCRIPTION DEFAULT PROGRAM DATA KEYPAD SOUNDER Segment 1 (Circle numbers to program) 1 = Keypad sounds for Telephone Line Cut when in the Armed state. 2 = Keypad sounds for Telephone Line Cut when in the Disarmed state. 3 = Keypad sounds upon AC Power Failure. 4 = Keypad sounds upon Low Battery Detection.
  • Page 37 DESCRIPTION DEFAULT PROGRAM DATA AUXILIARY OUTPUTS 1-4 SPECIAL TIMING Segments Aux output timed in minutes. Aux output to latch. Aux output to stop timing upon user code entry. Aux output to activate only between closing & opening time. Aux output to activate only between opening & closing time. Invert auxiliary output (0 Volts going to 12V when activated).
  • Page 38 COMMUNICATOR CODES FOR SLOW SPEED FORMATS ONLY The digit programmed in each of the following locations will be sent as the upper HEX digit in place of the alarm event code. The zone ID or user ID will always be reported as the lower HEX digit (1-F). For example, if the zone ID or user ID is 15, the 4+2 lower digit will be “F”.
  • Page 39 DESCRIPTION DEFAULT PROGRAMMING DATA AUXILIARY 2 KEYPAD PANIC KEYPAD MULTIPLE CODE ENTRY TAMPER BOX TAMPER / BOX TAMPER RESTORE 0-0-0-0 _ _ _ _ AC FAIL / AC RESTORE 0-0-0-0 _ _ _ _ LOW BATTERY / LOW BATTERY RESTORE 0-0-0-0 _ _ _ _ POWER SHORT / POWER SHORT RESTORE...
  • Page 40 DESCRIPTION DEFAULT PROGRAMMING DATA PARTITION 2 ENTRY/EXIT TIMERS Segment 1: Entry Time 1 Segment 2: Exit Time 1 Segment 3: Entry Time 2 Segment 4: Exit Time 2 Segment 5 & 6 RESERVED PARTITION 3, ACCOUNT CODE 10-10-10-10-10-10 _ _ _ _ _ _ PARTITION 3, FEATURE AND REPORTING SELECTION Segment 1 Quick Arm...
  • Page 41 DESCRIPTION DEFAULT PROGRAMMING DATA PARTITION 5, FEATURE AND REPORTING SELECTION Segment 1 Quick Arm Audible Panic Re-Exit Auxiliary 1 Auto Bypass Auxiliary 2 Silent Panic Multi Keypress Tamper Segment 2 LED extinguish enable Enables bypass toggle Require user code for bypassing zones Enables silent auto arm Bypass sounder alert Enables auto instant...
  • Page 42 DESCRIPTION DEFAULT PROGRAMMING DATA Segment 2 LED extinguish enable Enables bypass toggle Require user code for bypassing zones Enables silent auto arm Bypass sounder alert Enables auto instant AC power/low battery sounder alert Reserved Segment 3 Open/Close Tamper Bypass Cancel Restore Recent Closing Trouble...
  • Page 43 DESCRIPTION DEFAULT PROGRAMMING DATA Segment 3 Fast Loop Response. Dialer Delay zone. Double End of Line Tamper zone. Swinger zone. Trouble zone (Day zone). Restore reporting. Cross Zone. Listen-In. Segment 4 1 = Zone Activity Monitor. 4 = Zone acts as access entry point (Do not enable this segment unless 2 = End of Line Resistor Defeat.
  • Page 44 DESCRIPTION DEFAULT PROGRAMMING DATA ZONE TYPE 24 ALARM EVENT CODE ZONE TYPE 24 CHARACTERISTIC SELECT 1-13-378 __ __ __ __ __ ZONE TYPE 25 ALARM EVENT CODE ZONE TYPE 25 CHARACTERISTIC SELECT 248-45-0-0-0 __ __ __ __ __ ZONE TYPE 26 ALARM EVENT CODE ZONE TYPE 26 CHARACTERISTIC SELECT 467-125-5678-0-0 __ __ __ __ __...
  • Page 45 ZONE WORKSHEET NX-8V2 Control...

  • Page 46: Glossary

    GLOSSARY Abort If enabled, the NX-8V2 will wait the programmed number of seconds in location 40 prior to sending an alarm. During this delay time, the “Cancel” LED will flash. To abort the report, type in a code and press the Cancel key. The LED will extinguish. If the report is not aborted within the allotted time, the LED will extinguish when the report is sent.
  • Page 47 Dual / Split / Multiple Reports The NX-8V2 can send communication reports to three different phone numbers for dual, split or multiple reports selectable by event or partition. (Loc 4, 10, & 16, pg 12, 13, 14) Duress Code If a duress code is programmed the NX-8V2 will send a duress signal whenever the panel is armed or disarmed with this code. If open/close reports are sent, the user code will be 254.
  • Page 48 Keyswitch Arm/Disarm Any zone on the NX-8V2 can be programmed as a keyswitch zone. If this is done, a momentary short on this zone will arm/disarm the control. If opening/closing reports are sent, the user code will be 99. (See "Default Zone Types", pg 16) LED Extinguish This feature will extinguish all LEDs on the keypad, except the "Power"...
  • Page 49 Tone Sniff Answering Machine Defeat If enabled, only one call is required to defeat the answering machine. To use this feature you must have a Hayes 1200 Smart Modem. From the computer, call the panel as normal. When the answering machine answers, the panel will hear the tones from the modem and seize the phone line for a download.

  • Page 50: Xvi. Appendix 1

    XVI. APPENDIX 1 REPORTING FIXED CODES IN CONTACT ID AND SIA The table below lists the event codes sent for the following reports (if enabled) when using CONTACT ID or SIA formats. REPORT CONTACT ID AC FAIL (device number) ............301 ..........AT AC RESTORE (device number) ..........301 ..........

  • Page 51: Xvii. Appendix 2

    XVII. APPENDIX 2 REPORTING ZONE CODES IN SIA OR CONTACT ID The NX-8V2 has the ability to report SIA level 1 transmissions to either or both phone numbers. Each report in SIA consists of an Event Code and a Zone or User ID. The Zone ID will be the zone number that is in alarm. The event code will come from the chart below and be programmed in the zone type event code.

  • Page 52: Xviii. Appendix 3

    XVIII. APPENDIX 3 EXPANDER NUMBERS FOR REPORTING EXPANDER TROUBLE The tables below list the device numbers that will be reported for trouble conditions. Device Device # reported NX-8V2 Control Panel See page 50 for possible report codes. NX-534E Two Way Listen-In NX-540E “Operator”...

  • Page 53: Xix. Appendix 4

    XIX. APPENDIX 4 USER ID OR ZONE ID HEX DIGIT FOR 4+2 FORMATS The following appendix applies only to slow formats (locations 56- 83 lower digit). The digit programmed in the locations will be sent as the upper HEX digit in place of the alarm event code. The zone ID or user ID will always be reported as the lower HEX digit (1- F) as shown in the chart below.

  • Page 54: Local Telephone Company Interface Information

    If the problem is with the device, the customer shall discontinue use until it is repaired. EQUIPMENT INFORMATION Manufacturer Of Connecting Equipment: GE SECURITY, INC. FCC Registration Number: US:GCQAL01BNX-V2, RINGER EQUIVALENCE: 0.1 B XXI. INDUSTRY CANADA INFORMATION NOTICE: The Industry Canada label identifies certified equipment.

  • Page 55: Notices

    XXII. NOTICES Network Compatibility Declaration (Applies to products which have the CE mark attached) We declare under our sole responsibility that this product is designed to work with the networks in the countries marked with a check ( ) and may have interworking problems with the Declaration Of Conformity countries that are not checked.

  • Page 56: Underwriters Laboratories Information

    XXIII. UNDERWRITERS LABORATORIES INFORMATION The NetworX NX-8V2 holds the following listings from Underwriters Laboratories (US and Canadian): UL294 Access Control System Units UL365 Police Station Connected Burglar Alarms UL609 Local Grade A Mercantile, Police Station Connect with Basic Line Security CAN/ULC-S303-M91 * requires #NX-003-C enclosure UL985...
  • Page 57 MINIMUM SYSTEM CONFIGURATIONS FOR UL INSTALLATIONS (Residential Fire, Residential Burglary, Commercial Burglary) • The NetworX NX-8V2 panel is necessary to initiate Residential and Commercial installations. • At least one compatible keypad is needed for all applications. • At least one bell fixture is required for all applications, except Grade C Central Station. For Grade A Local, the AD10-12 bell and Grade A bell housing shall be used.
  • Page 59 SYSTEM NOTES...

  • Page 60: Specifications

    XXV. SPECIFICATIONS OPERATING POWER 16.5 VAC 40, or 50 VA Transformer AUXILIARY POWER w/25 VA Transformer 12 VDC Regulated 500 mA w/40 or 50 VA Transformer 12 VDC Regulated 1 AMP w/NX-320E Power Supply 12 VDC Regulated 2 AMPS + Control Panel Power LOOP RESISTANCE Standard Loop...
