GE Security NetworX Series Installation And Startup page 29

116
Location 116 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
117
Use "Zone Type Characteristic Selections" described in Location 111, page 28
118
Location 118 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
119
Use "Zone Type Characteristic Selections" described in Location 111, page 28
120
Location 120 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
121
Use "Zone Type Characteristic Selections" described in Location 111, page 28
122
Location 122 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
123
Use "Zone Type Characteristic Selections" described in Location 111, page 28
124
Location 124 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
125
Use "Zone Type Characteristic Selections" described in Location 111, page 28
126
Location 126 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
127
Use "Zone Type Characteristic Selections" described in Location 111, page 28.
128
Location 128 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
129
Use "Zone Type Characteristic Selections" described in Location 111, page 28
130
Location 130 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
131
Use "Zone Type Characteristic Selections" described in Location 111, page 28
132
Location 132 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
133
Use "Zone Type Characteristic Selections" described in Location 111, page 28
134
Location 134 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
135
Use "Zone Type Characteristic Selections" described in Location 111, page 28
NX-8V2 Control
ZONE TYPE 4 ALARM EVENT CODE
ZONE TYPE 4 CHARACTERISTIC SELECT
ZONE TYPE 5 ALARM EVENT CODE
ZONE TYPE 5 CHARACTERISTIC SELECT
ZONE TYPE 6 ALARM EVENT CODE
ZONE TYPE 6 CHARACTERISTIC SELECT
ZONE TYPE 7 ALARM EVENT CODE
ZONE TYPE 7 CHARACTERISTIC SELECT
ZONE TYPE 8 ALARM EVENT CODE
ZONE TYPE 8 CHARACTERISTIC SELECT
ZONE TYPE 9 ALARM EVENT CODE
ZONE TYPE 9 CHARACTERISTIC SELECT
ZONE TYPE 10 ALARM EVENT CODE
ZONE TYPE 10 CHARACTERISTIC SELECT
ZONE TYPE 11 ALARM EVENT CODE
ZONE TYPE 11 CHARACTERISTIC SELECT
ZONE TYPE 12 ALARM EVENT CODE
ZONE TYPE 12 CHARACTERISTIC SELECT
ZONE TYPE 13 ALARM EVENT CODE
ZONE TYPE 13 CHARACTERISTIC SELECT
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
1............. numerical
5............. feature select
29
