LOCATIONS 110-169 ARE USED TO CHANGE THE ZONE TYPES (Configurations) AS LISTED IN THE TABLE ON PAGE 16.
THESE LOCATIONS ARE CONSIDERED ADVANCED PROGRAMMING AND SHOULD ONLY BE CHANGED WITH A THOROUGH
UNDERSTANDING OF THE OPERATION OF EACH BIT.
110
Location 110 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 16. The zone ID will be that zone that is in alarm.
4+2 Format Note: If 4+2 format is being used, the number programmed in this location will be sent as the upper hex digit. The digit in
location 110 should be from 1 to 15 when using 4+2 formats. The zone ID or user ID will be the lower hex digit of the zone that is in
alarm.
111
Segment 1:
1 = Fire (turn on if this is a fire zone).
2 = 24 hour (turn on for non-fire 24 hour zones).
3 = Keyswitch zone. (normally open switch)
4 = Follower (turn on for burglary zones that are Instant during non-entry times).
5 = Delay 1 zone (follows timer 1 entry and exit times).
6 = Delay 2 zone (follows timer 2 entry and exit times).
7 = Interior (turn on if this zone should Automatically Bypass or Bypass for Stay Arming).
8 = Local only (turn on if this zone should not be reported).
Segment 2:
1 = On if Zone Type will beep the keypad for alarm.
2 = On if Zone Type will sound the yelping siren for alarm.
3 = On if Zone Type will sound the temporal siren for alarm.
4 = On if Zone Type will chime.
5 = On if Zone Type can be bypassed.
6 = On if Zone Type is included in the group shunt.
7 = On if Zone Type is force armable.
8 = On if Zone Type is entry guard.
Segment 3:
On enables Fast Loop Response. (50mS)- Off= 500mS
1-
On enables Double End Of Line Tamper zone. (Mainly used for tamper on wireless zones)
2-
On enables Trouble Reporting zone. (Day zone and Fire zones)
3-
On if Zone Type is a Cross Zone.
4-
On enables Dialer Delay zone. (See location 40, page 20)
5-
On if Zone Type will swinger shutdown. (See location 38, page 20)
6-
On enables Restore reporting.
7-
On enables Listen-In. (See location 40, page 20)
8-
Segment 4:
1 = On enables Zone Activity Monitor. (See location 40, page 20)
2 = On enables End of Line Resistor Defeat on Non-Fire/Non-Keyswitch zones.
3 = On enables zone to act as request to exit input / disables for alarm activation.
4 = On enables zone to act as access entry point (Refer to NX-1700E card reader instruction manual. Do not enable this segment
unless configured with Access Control.)
5-8 = Reserved.
Segment 5: Reserved.
112
Location 112 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
113
Use "Zone Type Characteristic Selections" described in Location 111, page 28
114
Location 114 contains the event code sent for a Contact ID or SIA report. The desired event code should be chosen from the list on
page 50. The zone ID will be that zone that is in alarm. If 4+2 format is being used, refer to Location 110 on page 28 for details.
115
Use "Zone Type Characteristic Selections" described in Location 111, page 28
28
ZONE TYPE 1 ALARM EVENT CODE
ZONE TYPE 1 CHARACTERISTIC SELECT
ZONE TYPE 2 ALARM EVENT CODE
ZONE TYPE 2 CHARACTERISTIC SELECT
ZONE TYPE 3 ALARM EVENT CODE
ZONE TYPE 3 CHARACTERISTIC SELECT
1 ............ numerical
5 ............ feature select
1 ............ numerical
5 ............ feature select
1 ............ numerical
5 ............ feature select
NX-8V2 Control
