GE Security NetworX Series Installation And Startup page 42

LOC PG
105 27
Segment 2
1 =
LED extinguish enable
2 =
Require user code for bypassing zones
3 =
Bypass sounder alert
4 =
AC power/low battery sounder alert
Segment 3
1 =
Open/Close
2 =
Bypass
3 =
Restore
4 =
Trouble
Segment 4
1 =Late to Close / Early to Open
2-8 = Reserved
Segment 5 RESERVED
106 27 PARTITION 7 ENTRY/EXIT TIMERS
Segment 1: Entry Time 1
Segment 2: Exit Time 1
Segment 3: Entry Time 2
Segment 4: Exit Time 2
Segment 5 & 6 RESERVED
107 27 PARTITION 8 ACCOUNT CODE
108 27 PARTITION 8 FEATURE AND REPORTING SELECTION
Segment 1
1 =
Quick Arm
2 =
Re-Exit
3 =
Auto Bypass
4 =
Silent Panic
Segment 2
1 =
LED extinguish enable
2 =
Require user code for bypassing zones
3 =
Bypass sounder alert
4 =
AC power/low battery sounder alert
Segment 3
1 =
Open/Close
2 =
Bypass
3 =
Restore
4 =
Trouble
Segment 4
1 =Late to Close / Early to Open
2-8 =Reserved
Segment 5 RESERVED
109 27 PARTITION 8 ENTRY/EXIT TIMERS
Segment 1: Entry Time 1
Segment 2: Exit Time 1
Segment 3: Entry Time 2
Segment 4: Exit Time 2
Segment 5 & 6 RESERVED
110 28 ZONE TYPE 1 ALARM EVENT CODE
111 28 ZONE TYPE 1 CHARACTERISTIC SELECT
Segment 1
1 =
Fire (enable for fire zone)
2 =
24-Hour (enable for non-fire 24 hour)
3 =
Keyswitch zone
4 =
Follower (enable for burg zones that are
instant during non-entry times)
Segment 2
1 =
Keypad audible on alarm.
2 =
Yelping siren on alarm.
3 =
Temporal siren on alarm.
4 =
Chime.
42
DESCRIPTION DEFAULT
5 =
Enables bypass toggle
6 =
Enables silent auto arm
7 =
Enables auto instant
8 =
Reserved
5 =
Tamper
6 =
Cancel
7 =
Recent Closing
8 =
Exit Error
0
0
0
0
10-10-10-10-10-10
5 =
Audible Panic
6 =
Auxiliary 1
7 =
Auxiliary 2
8 =
Multi Keypress Tamper
5 =
Enables bypass toggle
6 =
Enables silent auto arm
7 =
Enables auto instant
8 =
Reserved
5 =
Tamper
6 =
Cancel
7 =
Recent Closing
8 =
Exit Error
0
0
0
0
8
5 =
Delay 1 zone (enable to follow Timer 1 Entry/Exit times)
6 =
Delay 2 zone (enable to follow Timer 2 Entry / Exit times)
7 =
Interior (Enable for auto bypass or stay arming)
8 =
Local Only (enable if zone is not to be reported)
5 =
Bypassable.
6 =
Group Shunt.
7 =
Force armable.
8 =
Entry Guard.
PROGRAMMING DATA
_
_
_
_
_ _ _ _ _ _
_
_
_
_
_
NX-8V2 Control
