Page 1: Table Of Contents
Media Player Front Panel ������������������ E-2 Media Player Back Panel ������������������ E-3 MP 2050 Front ��������������������������������� E-3 MP 2050 Back ��������������������������������� E-4 MP 2000 ������������������������������������������ E-5 MP 2150 ������������������������������������������� E-5 MP 2050 ������������������������������������������ E-5 External Hard Drive �������������������������������E-6 Troubleshooting Your Media Gateway ���E-6... -
Page 2: Media Gateway Hardware
Media Gateway Hardware Manage the features and configuration of your Media Gateway� Your Media Gateway is not only the central hard drive for recorded content enabling Whole Home DVR, it is also an advanced cable modem and wireless router supporting WOW! Internet and WOW! Phone�... -
Page 3: Media Gateway Back Panel
Media Gateway Back Panel 1. tEL 1/ tEL 2 5. ESAtA Where you connect a DVR-certified 2. rESEt eSATA external hard drive� 3. CoAx 6. CABLECArD 4. USB 7. EtHErnEt The USB port is not active� 8. PowEr Media Player Front Panel 1. -
Page 4: Media Player Back Panel
Media Player Back Panel 1. CoAx 7. USB 2. CoMPoSitE 8. EtHErnEt 3. CoMPonEnt 9. ir BLAStEr 4. DiGitAL AUDio CoAx 10. rESEt 5. DiGitAL AUDio oPtiCAL 11. PowEr 6. HDMi MP 2050 Front 1. PowEr LiGHt 2. MoCA LiGHt MEDIA GATEWAY HARDWARE... -
Page 5: Mp 2050 Back
MP 2050 Back 1. CoAx 5. USB 2. rESEt 6. ir ExtEnDEr 3. HDMi 7. PowEr 4. EtHErnEt MEDIA GATEWAY HARDWARE... - Page 6 MP 2000 MP 2150 MP 2050 MP 2000 MP2150 MP 2050 Full HD 3D graphics HD/SD, MPEG4-10/H�264, MPEG-2 Ethernet connector USB 2�0 Host ports F connector (MoCA 1�1) One HDMI connector 1�3b 1�4 1�4 (supporting up to 1080p: 24/30/50/60 Hz)
-
Page 7: External Hard Drive
External Hard Drive The Ultra TV hard drive is 500GB and will store up to 300 hours of SD programming or 75 hours of HD programming� You can expand the amount of hard drive storage on your Media Gateway by connecting a DVR-certified eSATA external hard drive� When you first insert the external drive into the Media Gateway, you’ll see a dialog on all connected Media Players indicating that the drive needs to be formatted�... -
Page 8: Frequently Asked Questions
• Check to see if your Media Gateway is connected to the WOW! network� Look at your Media Gateway and confirm that the lights are correct per the table above� • If you checked the connections and you are still experiencing problems, press and release the Reset button to reboot the Media Gateway�... -
Page 9: Battery Replacement
1. remove the Battery Compartment Door a� Press your thumbs firmly against the front of the battery compartment door (on the front left side of the Media Gateway where it reads ARRIS)� Slide the door slightly to the left until it stops�... - Page 10 b� Apply even pressure on both ends of the battery pack with your thumbs until the battery pack slides over the raised stops and snaps firmly into place� 3. replace the Door a� Push the door straight onto the front of the Media Gateway until the tabs on the door insert into the matching slots on the battery compartment�...
