Ethernet
Interface EP2C612D16-2L2T:
10G by Intel X540 ; 1000 /100 /10 Mbps by Intel i210
EP2C612D16-4L:
1000 /100 /10 Mbps by Intel i350 / Intel i210
LAN EP2C612D16-2L2T:
2 x RJ45 GLAN by Intel® i210
2 x RJ45 10G base-T by Intel® X540*
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Eicient Ethernet 802.3az
- Supports Quad LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
EP2C612D16-4L:
2 x RJ45 GLAN by Intel® i210
2 x RJ45 GLAN by Intel® i350
1 x RJ45 Dedicated IPMI LAN port
- Supports Wake-On-LAN
- Supports Energy Eicient Ethernet 802.3az
- Supports Dual LAN with Teaming function
- Supports PXE
- LAN1 supports NCSI
Management
BMC Controller ASPEED AST2400
IPMI Dedicated - 1 x Realtek RTL8211E for dedicated management GLAN
GLAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2400
VRAM DDR3 16MB
Rear Panel I/O
VGA Port 1 x D-Sub
USB 3.0 Port 2
Lan Port - 4 + 1 (IPMI) Lan port (RJ45)
- LAN Ports with LED (ACT/LINK LED and SPEED LED)
Serial Port 1 (COM1)
EP2C612D16-4L / EP2C612D16-2L2T
3
