ASROCK EP2C612D16-4L User Manual page 10

Internal Connector
Auxiliary Panel
Header
TPM Header
IPMB Header
Fan Header
ATX Power
USB 3.0 Header
USB 2.0 Header
Type A USB 3.0
Port
hunderbolt
AIC Connector
System BIOS
BIOS Type
BIOS Features
Hardware Monitor
Temperature
Fan
Voltage
4
1 (includes chassis intrusion, location button & LED, front
LAN LED)
1
1
2x CPU Fan, 6x system Fan (4-pin)
1 (24-pin) + 2 (8-pin)
1 ( support 2 USB 3.0)
1 ( support 2 USB 2.0)
1
1
128Mb AMI UEFI Legal BIOS
- Plug and Play (PnP)
- ACPI 2.0 Compliance Wake Up Events
- SMBIOS 2.8 Support
- ASRock Rack Instant Flash
- CPU Temperature Sensing
- System Temperature Sensing
- Card Side Temperature Sensing
- CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow CPU Fan Speed Auto-Adjust by CPU
Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
1.05V_PCH, +BAT, 3VSB, 5VSB
