No.
Description
34
ME Recovery Jumper (ME_RECOVERY1)
35
Speaker Header (SPEAKER1)
36
USB 2.0 Header (USB_1_2)
37
Vertical Type A USB 3.0 (USB3_5)
38
USB 3.0 Header (USB3_3_4)
39
System Panel Header (PANEL1)
40
Auxiliary Panel Header (AUX_PANEL1)
41
BMC SMBus Header (BMC_SMB_1)
42
TPM Header (TPM1)
43
BMC SMBus Header (BMC_SMB_2)
44
CPU PECI Mode Jumper (PECI1)
45
Non Maskable Interrupt Button (NMI_BTN1)
46
Chassis ID1 Jumper (Chassis ID1)
47
Chassis ID0 Jumper (Chassis ID0)
48
Front Lan LED Connector (FRONT_LAN_3_4)
49
Chassis ID2 Jumper (Chassis ID2)
50
NCSI Mode Jumper (NCSI_SEL1)
51
PMBUS Mode Jumper (PMBUS_SEL_ALT1)
52
PMBUS Mode Jumper (PMBUS_SEL_CLK1)
53
PMBUS Mode Jumper (PMBUS_SEL_DAT1)
54
PCIE Power Connector (PCIE_PWR1)
55
hunderbolt Connector (TB1)
56
2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_F1, Blue)
57
2 x 288-pin DDR4 DIMM Slots (DDR4_E2, DDR4_F2, White)
58
Rear Fan Connector (REAR_FAN2)
59
Rear Fan Connector (REAR_FAN1)
60
CPU 2 Fan Connector (CPU2_FAN2)
*For DIMM installation and coniguration instructions, please see p.22 (Installation of Memory Modules
(DIMM)) for more details.
**Only PCIE 3 slot supports the hunderbolt Add-in Card. he hunderbolt Add-in Card is only supported on
Windows 8 / 7.
EP2C612D16-4L / EP2C612D16-2L2T
9
