Page 1: User Guide
Eonis User Guide 24–inch clinical display MDRC-2224 WP MDRC-2224 BL K5903081/03 19/09/2014... - Page 2 Barco nv President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/esupport Visit us at the web: www.barco.com Printed in Belgium...
-
Page 3: Table Of Contents
Warning signals ....................39 K5903081 EONIS 19/09/2014... - Page 4 Table of contents K5903081 EONIS 19/09/2014...
-
Page 5: Welcome
Barco’s Eonis display. Most unique, however, is the excellent cleanability of the white Eonis display thanks to the toughened and scratch-proof glass. This display model can be disinfected, both front and back, with typical alcohol-based cleaning agents. -
Page 6: What's In The Box
1. Welcome! What’s in the box Overview Your Eonis comes with: • this Eonis user guide • a documentation CD containing multilingual user documentation • a system CD containing MediCal QAWeb Agent • a (set of) AC power cord(s) (depending on the region of operation) •... -
Page 7: Parts, Controls And Connectors
2. PARTS, CONTROLS AND CONNECTORS Front view Overview Image 2-1 1. Front sensor 2. USB downstream connector 3. Left / Decrease key 4. Right / Increase key 5. Menu / Enter key 6. Standby key 7. Power status LED K5903081 EONIS 19/09/2014... -
Page 8: Rear View
2. Kensington security slots 3. Opening for cable routing strap 4. +12 VDC ( ) power input 5. USB downstream connector 6. USB upstream connector 7. VGA input 8. HDMI input 9. DisplayPort input 10. HDMI audio line out K5903081 EONIS 19/09/2014... -
Page 9: Display Installation
Removing the cover To remove the connector compartment cover The connector compartment cover should be removed to get access to the connectors. To remove the cover, gently slide the connector compartment cover upwards and remove it from the display. K5903081 EONIS 19/09/2014... -
Page 10: Connecting The Cables
5. Plug the other end of the external DC ( ) power supply into a grounded power outlet by means of the proper power cord delivered with your display. Image 3-3 For the MDRC-2224 WP, there is a earth stud available in the connector compartment. K5903081 EONIS 19/09/2014... -
Page 11: Re-Attaching The Cover
To make use of the Kensington security slots Your Eonis display has 2 Kensington slots available which allow you to secure the display to a desk or any other fixed object. Moreover, when locking the display with the connector compartment cover attached, you also prevent users from connecting/disconnecting any cables to/from the display. -
Page 12: Vesa-Mount Installation
Never move a display attached to an arm by pulling or pushing the display itself. Instead, make sure that the arm is equipped with a VESA approved handle and use this to move the display. Please refer to the instruction manual of the arm for more information and instructions. K5903081 EONIS 19/09/2014... - Page 13 3. Display installation Use suitable mounting apparatus to avoid risk of injury. AUTION K5903081 EONIS 19/09/2014...
- Page 14 3. Display installation K5903081 EONIS 19/09/2014...
-
Page 15: Daily Operation
QAWeb guarantees optimum and stabilized image quality in every private practice. The front sensor on the Eonis works seamlessly with QAWeb to ensure a consistent image over time. It automatically stabilizes the image from the moment you switch on the display. What’s more, QAWeb provides you with instant feedback on the status of the display. -
Page 16: On/Off Switching
Bringing up the OSD menus About the OSD menu The OSD menu allows you to configure different settings to make your Eonis display fit your needs within your working environment. Also, you can retrieve general information about your display and its current configuration settings through the OSD menu. -
Page 17: Advanced Operation
3. Select one of the available video input sources. Luminance adjustment About luminance adjustment The luminance of your Eonis display is adjustable over a predefined range. When you change the lumi- nance, the display will adjust its backlight to reach the target. To adjust the luminance 1. -
Page 18: Ambient Light Reading Room Selection
Native: The native, unmodified color temperature of the LCD panel. • 6500K (sRGB): Corresponds to a color temperature of 6500 Kelvin (D65). • QAWeb: This white point setting will be automatically selected when white point is defined by MediCal QAWeb. K5903081 EONIS 19/09/2014... -
Page 19: Analog Video Settings
4. Adjust one of the available analog video settings as desired. OSD menu language About the OSD menu language By default, the OSD menu comes up in English. However, there’s a wide range of other languages avail- able for the OSD menu of your Eonis display: • English •... -
Page 20: Power Status Led
DPMS mode About DPMS mode Enabling the Display Power Management System (DPMS) mode on your Eonis display will optimize the displays’ lifetime by automatically switching off the backlight when no video signal is detected for approx- imately 10 seconds. The power status LED will then turn orange. -
Page 21: Self Calibration Frequency
5.10 Self calibration frequency About self calibration The front sensor of your Eonis display measures the output luminance of your screen and allows the display to automatically stabilize its luminance for maximum image quality over the displays’ lifetime. This self calibration is done at an adjustable, predefined frequency: •... - Page 22 5. Advanced operation K5903081 EONIS 19/09/2014...
-
Page 23: Maintenance
6. MAINTENANCE General maintenance information The Eonis does not require any scheduled maintenance or calibration activities. We recommend to use QAWeb with the Barco default tests and frequencies to calibrate and maintain the display or return the display to a Barco approved maintenance organization. In any case of doubts, contact the Barco Health- care Division. - Page 24 6. Maintenance K5903081 EONIS 19/09/2014...
-
Page 25: Important Information
The equipment should be installed near an easily accessible outlet. • The equipment is intended for continuous operation. Transient over-voltage If the device is not used for a long time, disconnect it from the AC inlet to avoid damage by transient over-voltage. K5903081 EONIS 19/09/2014... -
Page 26: Power Cords
+ A2:10), CAN/CSA-C22.2 No. 60601-1:08, DEMKO - EN 60601-1:2006, EN 60601-1-2:2007, EN 60601-1:2006+A11:2011, KC, VCCI, FCC class B, ICES-001 Level B, FDA Class I device, RoHS National Scandinavian Deviations for CL. 1.7.2: Finland: "Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan" Norway: "Apparatet må tilkoples jordet stikkontakt" K5903081 EONIS 19/09/2014... -
Page 27: Environmental Information
MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”. 零件项目(名称) 有毒有害物质或元素 Component name Hazardous substances and elements 铅 镉 汞 六价铬 多溴联苯 多溴二苯 醚 Cr6+ PBDE 印制电路配件 Printed Circuit Assemblies 液晶面板 LCD panel 外接电(线)缆 External Cables K5903081 EONIS 19/09/2014... - Page 28 Friendly Use Period” of Chinese Mainland. China Energy Label If there is a China Energy Label on your packaging or product, the product meets the following energy requirements corresponding with the energy efficiency level on the label. K5903081 EONIS 19/09/2014...
-
Page 29: Regulatory Compliance Information
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. Canadian notice This ISM device complies with Canadian ICES-001. Cet appareil ISM est conforme à la norme NMB-001 du Canada. K5903081 EONIS 19/09/2014... -
Page 30: Emc Notice
Using another can result in a decrease of the immunity level of the device. Electromagnetic emissions The Eonis is intended for use in the electromagnetic environment specified below. The customer or the user of the Eonis should assure that it is used in such an environment. - Page 31 (W) according to the transmitter manufacturer and d is the recommended 1. is the a.c. mains voltage prior to application of the test level. 2. Eonis doesn’t contain susceptible components to magnetic fields K5903081 EONIS 19/09/2014...
- Page 32 RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the Eonis is used exceeds the applicable RF compliance level above, the Eonis should be observed to verify normal operation.
-
Page 33: Explanation Of Symbols
Indicates the device is approved according to the VCCI regulations Indicates the device is approved according to the KC regulations Indicates the device is approved according to the BSMI regulations Indicates the USB connectors on the device K5903081 EONIS 19/09/2014... - Page 34 Indicates the storage direction of the box. The box must be transported, handled and stored in such a way that the arrows always point upwards. 6. Values for xx and yy can be found in the technical specifications paragraph. K5903081 EONIS 19/09/2014...
-
Page 35: Legal Disclaimer
- graphical, electronic, or mechanical including photocopying, taping or information storage and retrieval systems - without written permission of Barco. © 2014 Barco N.V. All rights reserved. 7. Values for xx and yy can be found in the technical specifications paragraph. K5903081 EONIS 19/09/2014... -
Page 36: Technical Specifications
8.38 kg Net weight w/o stand 5 kg Net weight packaged with 12.38 kg stand Height adjustment range 100 +/- 5.0 mm Tilt -5° / +20° Swivel -45° / +45° Pivot Mounting standard VESA (100 mm) Screen protection K5903081 EONIS 19/09/2014... - Page 37 Storage & transport altitude 5500 m 70 kPa - 106 kPa Operating pressure 50 kPa - 106 kPa Storage & transport pressure MDRC-2224 WP Product acronym MDRC-2224 WP Screen technology TFT Color LCD IPS Active screen size (diagonal) 611.3 mm (24.1”) Active screen size (H x V) 518.4 mm x 324.0 mm (20.41”...
- Page 38 +10°C / +35°C Storage & transport -20°C / +60°C temperature Operating humidity 10% - 90% (non-condensing) Storage & transport humidity 5% - 90% (non-condensing) at 39 deg ambient Operation altitude 3000 m Storage & transport altitude 5500 m K5903081 EONIS 19/09/2014...
- Page 39 7. Important information 70 kPa - 106 kPa Operating pressure Storage & transport pressure 50 kPa - 106 kPa K5903081 EONIS 19/09/2014...
- Page 40 7. Important information K5903081 EONIS 19/09/2014...
-
Page 41: Troubleshooting
Problem: No signal This message means that the display has been powered on but it cannot receive any signal from the computer graphics card. Check all the power switches, power cables, and VGA signal cable. K5903081 EONIS 19/09/2014... - Page 42 This message means that the signal of the computer graphics card is not compatible with the display. When the signal is not included in the compatibility mode we have listed in the appendices of this manual, the display will show this message. K5903081 EONIS 19/09/2014...
