Eonis
User Guide
22-inch clinical display
MDRC-2222 (option BL)
MDRC-2222 (option TS)
MDRC-2222 (option WP)
K5902146 (451920612622)/01
12/01/2018

Advertisement

Table of Contents
loading

Related Manuals for Barco Eonis MDRC-2222

Summary of Contents for Barco Eonis MDRC-2222

  • Page 1 Eonis User Guide 22-inch clinical display MDRC-2222 (option BL) MDRC-2222 (option TS) MDRC-2222 (option WP) K5902146 (451920612622)/01 12/01/2018...
  • Page 2 Barco NV Beneluxpark 21, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/en/support Visit us at the web: www.barco.com Registered address: Barco NV President Kennedypark 35, 8500 Kortrijk, Belgium Phone: +32 56.23.32.11 Fax: +32 56.26.22.62 Support: www.barco.com/en/support Visit us at the web: www.barco.com...

  • Page 3: Table Of Contents

    Table of contents TABLE OF CONTENTS 1. Welcome! ..................3 What’s in the box....................4 Product overview.
  • Page 4 Table of contents K5902146 (451920612622) EONIS 12/01/2018...

  • Page 5: Welcome

    Centralized quality assurance Eonis displays come complete with Barco’s cloud-based MediCal QAWeb software, an online service for automated calibration, Quality Assurance and asset management. Praised in hospitals around the world, MediCal QAWeb allows healthcare IT and PACS administrators to centrally and remotely manage image quality across the healthcare organization, at the click of a button.

  • Page 6: What's In The Box

    • 1x CD containing MediCal QAWeb Agent and translated user guides The user guide is available in other languages on www.barco.com/support Keep your original packaging. It is designed for this display and is the ideal protection during transport and storage.
  • Page 7 1. Welcome! 1. Display stand 2. Control wheel - Push long (5 sec): to put display in standby mode - Push short: to exit standby mode to active the OSD menu to confirm selections in the OSD menu - Turn clockwise to scroll down in the OSD menu to increase values in the OSD menu - Turn counter clockwise...
  • Page 8 1. Welcome! 1. Kensington security slot 2. USB-B 2.0 upstream connector 3. USB-A 2.0 downstream connectors (2x) 4. DisplayPort video input 5. Earth pin 6. DVI-I video input 7. 100 - 240 VAC mains power input (IEC C14) 8. Height-adjustable cable routing clip 9.

  • Page 9: Installation

    2. Installation 2. INSTALLATION Read all the important safety information before installing and operating ARNING your monitor. Please refer to the dedicated chapter in this user guide. ARNING Sufficient expertise is required to install this equipment. All devices and complete setup must be tested before taking into operation. When the display is assembled in the medical system, take care of the fixa- AUTION tion of all cables, to avoid unwanted detachment.

  • Page 10: Display Position Adjustment

    2. Installation Image 2-2 3. Connect the mains power input to a grounded power outlet. Image 2-3 4. If necessary for your application, earth the MDRC-2222 by connecting the earth pin to a grounded outlet by means of a yellow/green AWG18 wire (maximum admitted cable length according to national regulation requirements).

  • Page 11: Vesa-Mount Installation

    2. Installation Image 2-5 ARNING The display must be in its highest position before it can be properly pivoted. The standard orientation of the video input is landscape. If you use the display in portrait mode, make sure you change the orientation of the video input via the screen settings of the computer.
  • Page 12 2. Installation 1. Unscrew the four fixation screws to detach the panel from the stand. Image 2-6 2. Use 4 M4 screws to attach the panel to a VESA approved arm. Please respect the following rule to select an appropriate screw length: = T + W + 8 mm = T + W + 14 mm Image 2-7...

  • Page 13: Operation

    To ensure optimal product quality, Barco applies strict selection criteria for its LCD panels. To learn more about LCD technology and missing pixels, consult the dedicated white papers available at www.barco.com/healthcare.

  • Page 14: Standby Switching

    3. Operation Standby switching About • Push the control wheel long (5 sec) to put your display in standby mode • Push the control wheel short (1 sec) to exit standby mode and activate your display OSD menu use To open the OSD menu Shortly push the control wheel during normal operation to open the OSD menu.

  • Page 15: Input Source Selection

    3. Operation To lock the control wheel 1. Bring up the OSD main menu. 2. Navigate to the Adjustments > Settings > Keyboard lock menu. 3. Switch the keyboard lock on or off. 4. Exit the OSD menu to activate the selected option. To unlock the control wheel During normal operation, turn and hold the control wheel counter clockwise for 5 seconds, until the OSD unlocked message appears.

  • Page 16: Qaweb Presets

    DICOM: DICOM (Digital Imaging and Communications in Medicine) is an international standard that was developed to improve the quality and communication of digital images in radiology. In short, the DICOM display function results in more visible grayscales in the images. Barco recommends selecting the DICOM display function for most medical viewing applications.

  • Page 17: White Point Selection

    3. Operation The settings of the display must be adapted to suit the requirements of the visualization software. In case of doubt, please contact the vendor of the visualization software. To select a display function 1. Bring up the OSD main menu. 2.

  • Page 18: Power Save Mode

    3. Operation To adjust the analog video settings 1. Bring up the OSD main menu. 2. Navigate to the Adjustments > Analog menu. 3. Adjust one of the available analog video settings as desired. 3.13 Power save mode About power save mode Enabling power save mode on your MDRC-2222 will optimize the display lifetime by automatically switch- ing off the backlight when no video signal is detected after approximately 10 seconds.

  • Page 19: Factory Reset

    3. Operation 3.16 Factory reset About factory reset A factory reset allows you to fully restore the display to its original factory setting. To perform a factory reset 1. Bring up the OSD main menu. 2. Navigate to the Adjustments > Settings menu. 3.
  • Page 20 3. Operation K5902146 (451920612622) EONIS 12/01/2018...

  • Page 21: Maintenance

    The MDRC-2222 does not require any scheduled maintenance or calibration activities. We recommend to use QAWeb with the Barco default tests and frequencies to calibrate and maintain the display, or to return the display to a Barco approved maintenance organization. In any case of doubts, please contact Barco Healthcare.
  • Page 22 4. Maintenance • Alcohol/solvents at higher concentration > 70% • Strong alkalis lye, strong solvents • Acid • Detergents with fluoride • Detergents with ammonia at higher concentration > 1.6% • Detergents with abrasives • Steel wool • Sponge with abrasives •...

  • Page 23: Important Information

    5. Important information 5. IMPORTANT INFORMATION Safety information General recommendations Read the safety and operating instructions before operating the device. Retain safety and operating instructions for future reference. Adhere to all warnings on the device and in the operating instructions manual. Follow all instructions for operation and use.
  • Page 24 5. Important information Transient over-voltage To fully disengage the power to the device, please disconnect the power cord from the AC inlet. Connections Any external connection with other peripherals must follow the requirements of clause 16 of IEC60601-1 3rd. Ed. or Table BBB.201ofIEC 60601-1-1 for the medical electrical systems. To maintain compliance with EMC Regulation, use only shielded interface cables for the connection to peripheral devices.

  • Page 25: Environmental Information

    For more information about recycling of this product, please contact your local city office or your municipal waste disposal service. For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee K5902146 (451920612622) EONIS 12/01/2018...
  • Page 26 Electronic Products ” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.

  • Page 27: Biological Hazard And Returns

    Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of environ- ment-friendly use period of electronic information products” of Chinese Mainland.

  • Page 28: Regulatory Information

    The manufacturing country of the product is indicated on the product label (“Made in …”). Importers contact information To find your local importer, contact one of Barco’s regional offices via the contact information provided on our website (www.barco.com). FCC class B This device complies with Part 15 of the FCC Rules.
  • Page 29 5. Important information Emissions test Electromagnetic environment – Compliance Guidance RF emissions Class B The MDRC-2222 is suitable for use in all establishments, CISPR 11 including domestic establishments Harmonic emissions Not applicable: consumption less and those directly connected to than 75W IEC 61000-3-2 the public low-voltage power Voltage fluctuations/ flicker...
  • Page 30 5. Important information Immunity test Electromagnetic IEC 60601-1-2 4 Compliance level edition (2014) environment – guidance Test levels Voltage dips, short < 5% U (> 95% dip in < 5% U (> 95% dip in Mains power quality interruptions and voltage ) for 0.5 cycle ) for 0.5 cycle should by that of a typical...
  • Page 31 5. Important information Immunity test Electromagnetic IEC 60601-1-2 4 Compliance level edition (2014) environment – guidance Test levels level in each frequency range. Interference may occur in the vicinity of equipment marked with symbol: At 80 MHz and 800 MHz, the higher frequency range applies. These guidelines may not apply in all situations.

  • Page 32: Explanation Of Symbols

    5. Important information Rated maximum output Separation distance according to frequency of transmitter power of transmitter 150kHz to 80MHz 80MHz to 800MHz 800MHz to 2.5GHz d=1.2√P d=1.2√P d=2.3√P At 80 MHz and 800 MHz, the separation distance for the higher frequency range applies. These guidelines may not apply in all situations.
  • Page 33 5. Important information Indicates the device is approved according to the EAC regulations Caution: Federal law (United Stated of America) restricts this device to sale by or on the order of a licensed healthcare practitioner. Indicates the USB connectors on the device Indicates the DisplayPort connectors on the device Indicates the legal manufacturer Indicates the manufacturing date...
  • Page 34 5. Important information Stand-by Equipotentiality Protective earth (ground) Symbols on the box On the box of the device, you may find the following symbols (nonrestrictive list): Indicates a device that can be broken or damaged if not handled carefully when being stored.

  • Page 35: Legal Disclaimer

    Barco software products are the property of Barco. They are distributed under copyright by Barco NV or Barco Inc., for use only under the specific terms of a software license agreement between Barco NV or Barco Inc. and the licensee. No other use, duplication, or disclosure of a Barco software product, in any form, is authorized.
  • Page 36 5. Important information Video input signals 1x DVI-I 1x DisplayPort USB ports 1x USB 2.0 upstream (endpoint) 2x USB 2.0 downstream Power rating 100-240 Vac, 50-60 Hz, 0.6-0.4 A Power consumption 20 W (nominal) < 0.5 W (hibernate) < 0.5 W (standby) Dimensions with stand (W Portrait: 337 x 525~602 x 201 mm x H x D)
  • Page 37 5. Important information Supplied accessories User guide System disc DisplayPort cable USB cable AC mains cable (depending on the region) QA software MediCal QAWeb Warranty 3 years Operating temperature 0 °C to 40 °C Storage temperature -20 °C to 60 °C Operating humidity 8% to 85% (non-condensing) Storage humidity...
  • Page 38 5. Important information Power consumption 20 W (nominal) < 0.5 W (hibernate) < 0.5 W (standby) Dimensions with stand (W Portrait: 337 x 525~602 x 201 mm x H x D) Landscape: 514 x 388~498 x 201 mm Portrait: 315 x 514 x 67 mm Dimensions w/o stand (W x H x D) Landscape: 514 x 315 x 67 mm...
  • Page 39 5. Important information Operating humidity 8% to 85% (non-condensing) Storage humidity 5% to 95% (non-condensing) Operating pressure 70 kPa Storage pressure 50 to 106 kPa MDRC-2222 (option WP) Screen technology Active screen size 546 mm (21.5") (diagonal) Active screen size (H x V) 476 x 268 mm (18.7 x 10.5") Aspect ratio (H:V) 16:9...
  • Page 40 5. Important information Net weight w/o stand 4.1 kg Net weight packaged 7.8 kg (without optional accessories) Tilt -5° to +22° Pivot 90° Height adjustment range 110 mm Mounting standard VESA (100 mm) Protective, anti-glare glass cover Screen protection Recommended modalities All digital images, except digital mammography Certifications CE (MDD 93/42/EEC;...
