Chapter 1
FOCUS GC Description
factory set, located on the Main Board. According to the instrument power supply
configuration, the breaker ON/OFF main switch changes as follows:
The high voltage section is provided of a series of protection fuses as reported in
the following table:
34
Power Supply
120 Vac
230 Vac
Fuse
F1 F2A; IEC 127/I; (5 x20 mm)
F2 T1.6A; IEC 127/III; (5 x20 mm)
F3 F2A; IEC 127/I; (5 x20 mm)
F4 F0.63A; IEC 127/I; (5 x 20 mm)
F5 F0.63A; IEC 127/I; (5 x 20 mm)
Breaker
15A
7A
Type
GC Parts Description
Protection
Injector heater element
230 Vac Main power (Breaker)
120 Vac Main power (Breaker)
Auxiliary heater element
Oven fan motor
Oven fan motor
