Instruction Manual
2 or 4 Port Dual DVI USB KVM Switch
with Audio and USB 2.0 Hub
SV231DVIDDU
SV431DVIDDU
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 04/25/2014
*SV431DVIDDU Shown
Advertisement
Table of Contents
Related Manuals for StarTech.com SV231DVIDDU
Summary of Contents for StarTech.com SV231DVIDDU
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 04/25/2014...
-
Page 3: Fcc Compliance Statement
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby... -
Page 4: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Computer Side ..................2 Hardware Installation ................4 PC BIOS Notice ............................4 Console Connection ..........................4 Computer Connection ..........................4 Hardware Operation ................5 Front-Panel Push Buttons ........................5 Keyboard Hotkey Commands....................... -
Page 5: Introduction
Introduction This 2 Port Dual DVI USB KVM Switch allows two PCs, each with dual DVI displays, to share two monitors, one microphone (and set of speakers), one keyboard and one mouse as well as two other USB peripherals. An ideal solution for graphic designers, CAD/CAM designers or educational and financial institutions, the Dual DVI USB KVM Switch allows you to instantly switch back and forth between PCs at the touch of a button while maintaining professional level video quality on both DVI monitors, in turn saving money by eliminating redundant... -
Page 6: Computer Side
• One USB A-B Cable with Type-A and Type-B plug per computer • Two 3.5mm audio cables per computer (Optional) • Please Note: In place of using individual cables, StarTech.com offers a 6 ft. 4-in-1 USB, DVI, Audio, and Microphone KVM Switch Cable (USBDVI4N1A6) that can fulfill USB, audio, and video functions in one convenient unit. - Page 7 SV431DVIDDU Front Port Selection Button USB Hub Computer Selection Selection SV431DVIDDU Back Computer Console Connectors DVI Ports USB Hub ports Power Console USB Keyboard/ Mouse ports Console Speaker/MIC ports *SV431DVIDDU shown - actual product may vary from photo Instruction Manual...
-
Page 8: Hardware Installation
Hardware Installation PC BIOS Notice The following BIOS setup changes may be necessary for PC users. 1. In STANDARD CMOS, set HALT ON ERROR to ALL BUT KEYBOARD1. 2. In PNP AND PCI SETUP, set PNP OS INSTALLED to YES and set USB IRQ to ENABLED. Please Note: The KVM provides USB keyboard and mouse switching from one computer to the other. -
Page 9: Hardware Operation
Hardware Operation There are two methods of switch operation for the KVM Switch: Front-Panel Push Buttons, and Keyboard Hotkey Commands. Steps of operation for both are outlined below. Front-Panel Push Buttons 1. Press the front panel button that corresponds with the desired computer. 2. -
Page 10: Hotkey Reference Chart
Hotkey Reference Chart Command Hotkey Sequence Description <ScrLk>+<ScrLk>+<x> Selects which port has Select Active access to the keyboard/ (<x> = Port Number: 1, 2, Computer mouse/monitor. etc.) Selects which port’s <ScrLk>+<ScrLk>+<Fy> Select Audio/Mic speaker and microphone (<Fy> = Function key: output output is active at the F5=Port 1, F6=Port 2, etc.) -
Page 11: Led Information
Automatically cycle Auto-scan <ScrLk>+<ScrLk>+<S> through active ports in sequence every 10 seconds. <ScrLk>+<ScrLk>+<S>+<z> Auto-scan with Auto-scan with a custom (<z>= 0~9: where 1=10sec, programmable set delay time. 2=20sec…9=90sec, delay 0=100sec) Terminate Auto-scan Stop Auto-scan Press any key on keyboard activity. 1. -
Page 12: Specifications
Specifications Computers supported 2 (SV231DVIDDU), 4 (SV431DVIDDU) Front panel push buttons 2 (SV231DVIDDU), 4 (SV431DVIDDU) Automatic scan interval 10 - 60 seconds (in 5 second intervals) Resolution supported 1920 x 1200 (digital), 2048 x 1536 (analog) USB Type B x 4... -
Page 13: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 15 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
