  • Page 1 INSTRUCTION MANUAL Ver 1.1 Outdoor High Speed Dome Camera...
  • Page 2 This lightning flash with arrowhead symbol is intended to alert the user to the presence of un-insulated "dangerous voltage" within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE NOTICE Important Safeguard Read Instructions Read all of the safety and operating instructions before using the product. Retain Instructions Save these instructions for future reference. Attachments / Accessories Do not use attachments or accessories unless recommended by the appliance manufacturer as they may cause hazards, damage product and void warranty.

  • Page 4: Table Of Contents

    CONTENTS ○ Introduction Features Product & Accessories Parts Name & Functions ○ Installation DIP Switch Setup Installation using Wall Mount Bracket Installation using Ceiling Mount Bracket Cabling ○ Operation Checking Before Operation Preset and Pattern Function Pre-Check Start OSD Menu Reserved Preset Preset Swing...

  • Page 5: Introduction

    INTRODUCTION Features Camera Specifications → ×22, ×30 Model CCD Sensor : 1/4" SONY Super HAD CCD → ×26 Model 1/4" SONY EXView CCD Zoom Magnification : × 22 Optical Zoom, × 10 Digital Zoom (Max × 220 Zoom) → ×22 Model ×...
  • Page 6 INTRODUCTION OSD(On Screen Display) Menu OSD menu is provided to display the status of camera and to configure the functions interactively. The information such as Camera ID, Pan/Tilt Angle, Alarm I/O and Preset can be displayed on screen. Alarm I/O Functions 4 alarm sensor Inputs and 2 alarm Output relays are available.

  • Page 7: Product & Accessories

    INTRODUCTION Product & Accessories Product & Accessories Main Body * Main Body (Sun-Shield) * Dome Cover Wall mount bracket ** Ceiling Mount Bracket ** Screws Options Pole Mount Adapter Cornor Mount Adapter 7/47 Speed Dome Camera Instruction Manual...

  • Page 8: Parts Name & Functions

    INTRODUCTION Parts Name & Functions Lockup Screw Main Body Cable Mold Line Cabling Terminal Block DIP Switch Main Body Drop Prevention Connector Spring Fuse Main Body Mount Bracket Dome Cover Do not detach protection vinyl from dome cover before finishing all installation process to protect dome cover from scratches or dust.

  • Page 9: Installation

    INSTALLATION DIP Switch Setup Before you install the camera, you should set the DIP switches to configure the camera ID, communication protocol. Communication Protocol Camera ID CAM ID Camera ID Setup ID number of camera is set using binary number. The example is shown bellow.
  • Page 10 INSTALLATION Communication Protocol Setup Select the appropriate Protocol with DIP switch combination. Switch State Protocol/Baud rate (Pin 1) (Pin 2) (Pin 3) PELCO-D, 2400 bps PELCO-D, 9600 bps PELCO-P, 4800 bps PELCO-P, 9600 bps Otherwise Reserved If you want to control using DVR or P/T controller, their protocol must be identical to camera.

  • Page 11: Installation Using Wall Mount Bracket

    INSTALLATION Installation using Wall Mount Bracket ① Install Wall Mount Bracket on wall. ② Wire cables to terminal blocks on the PCB in Wall Mount Bracket. ③ Hook up “Drop Prevention Spring” on main body ④ Line up the mold lines and assemble main body to prevent camera from unexpected drop and to Wall Mount Bracket.

  • Page 12: Installation Using Ceiling Mount Bracket

    INSTALLATION Installation using Ceiling Mount Bracket ① To pass cables to upside of ceiling, please make a ② Wire cables to terminal blocks on the PCB in hole with 50~60mm diameter on the ceiling panel Ceiling Mount Bracket. and attach the Ceiling mount bracket on it. ③...
  • Page 13 INSTALLATION ⑤ Turn main body on its axis in CW(Clockwise) direction and, after assembling them, screw main body to Ceiling Mount Bracket to protect them from separation by vibration or others. 13/47 Speed Dome Camera Instruction Manual...

  • Page 14: Cabling

    INSTALLATION Cabling IrDA Sensor Door Power COMMON+ PWR+ Switch SEN1 SEN2 Sensor PWR- SEN3 SEN4 VIDEO(+) RELAY1 Moinitor Light VIDEO(-) RS-485+ RELAY2 RS-485- Alarm Buzzer RS-485 Output Devices Braket Terminal Block Controller / DVR Power Connection Please, check the voltage and current capacity of rated power carefully. Rated power is indicated in the back of main unit.
  • Page 15 INSTALLATION Alarm I/O Connection Sensor Input Internal +5V~12V IN COM+ Sensor 1 Output IN 1- Sensor 4 Output IN 4- Before connecting sensors, check driving voltage and output signal type of the sensor. Since output signal types of the sensors are divided into Open Collector and Voltage Output type in general, the cabling must be done properly after considering these typed.

  • Page 16: Operation

    OPERATION Check points before operation Before power is applied, please check the cables carefully. The camera ID of the controller must be identical to that of the target camera. The camera ID can be checked by reading DIP switch of the camera. If your controller supports multi-protocols, the protocol must be changed to match to that of the camera.

  • Page 17: Start Osd Menu

    OPERATION Starting OSD Menu Function Using the OSD menu, Preset, Pattern, Swing, Group and Alarm I/O function can be configured for each application. Enter Menu <Go Preset> [95] Reserved Preset Description Some Preset numbers are reserved to special functions. Function <Go Preset>...

  • Page 18: Preset

    OPERATION Preset Function Max. 127 positions can be stored as Preset position. The Preset number can be assigned from 1 to 128, but 95 is reserved for starting OSD menu. Camera characteristics (i.e. White Balance, Auto Exposure) can be set up independently for each preset.

  • Page 19: Pattern

    OPERATION Pattern Function Pattern Function is that a camera memorizes the path (mostly curve path) by joystick of controller for assigned time and revives the path exactly as it memorized. 4 Patterns are available and Maximum 1200 communication commands can be stored in a pattern.

  • Page 20: Group

    OPERATION Group Function The group function allows running sequence of Presets, Pattern and/or Swings. Max 8 group can be stored. Each group can have max 20 action entities which can be preset, pattern or swing. Preset speed can be set up and the repeat number of Pattern & Swing can be set up in Group setup.

  • Page 21: Other Motion Functions

    OPERATION Other Functions Power Up Action This function enables to resume the last action executed before power down. Most of actions such as Preset, Pattern, Swing and Group are available for this function but Jog actions are not available to resume. Auto Flip In case that tilt angle arrives at the top of tilt orbit(90°), zoom module camera turns on its axis by 180°...

  • Page 22: Osd Display Of Main Screen

    OPERATION OSD Display of Main Screen Action Title Preset Label LABEL12345 PRESET1 Alarm Information I:1--- O:-2 Camera ID CAM 1 15/4/x1/N P/T/Z Information P/T/Z Information Current Pan/Tilt angle in degree, zoom magnification and a compass direction. Camera ID Current Camera ID(Address). Action Title Followings are possible Action Titles and their meaning.

  • Page 23: How To Use Osd Menu

    HOW TO USE OSD MENU General Rules of Key Operation for Menu The menu items surrounded with ( ) always has its sub menu. For all menu level, to go into sub menu, press NEAR key. To go to up-one-level menu, press FAR key. To move from items to item in the menu, use joystick in the Up/Down or Left/Right.

  • Page 24: Display Menu For Main Screen

    HOW TO USE OSD MENU Display Setup This menu defines Enable/Disable of OSD display on Main Screen. If an DISPLAY SETUP item is set to be AUTO, the item is displayed only when the value of it is ------------------------ CAMERA ID changed.

  • Page 25: Privacy Zone Mask Setup

    HOW TO USE OSD MENU PRIVACY ZONE MASK Setup This function availability should be different by models. Select area in image to mask. PRIVACY ZONE ------------------------ MASK NO Mask No [1~8] UNDEFINED DISPLAY Select Mask number. If the selected mask has CLEAR MASK CANCEL already data, camera moves as it was set.

  • Page 26: Camera Module Setup

    HOW TO USE OSD MENU CAMERA SETUP (×22 Model) Setup the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ FOCUS MODE SEMIAUTO Focus Mode [AUTO/MANUAL/SEMIAUTO] MAX ZOOM x220 FLICKERLESS Sets camera focus mode. COLOR LINE LOCK SEMIAUTO Mode <WHITE BALANCE SETUP>...
  • Page 27 HOW TO USE OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL ------------------------ In Manual mode, Red and Blue level can be set WB MODE AUTO ADJUST up manually BLUE ADJUST Red Adjust [0~255] Blue Adjust [0~255] BACK EXIT 27/47...
  • Page 28 HOW TO USE OSD MENU Auto Exposure Setup Backlight [ON/OFF] AE SETUP - GLOBAL Sets Backlight Compensation. ------------------------ BACKLIGHT DAY/NIGHT AUTO Day/Night [AUTO/DAY/NIGHT] SLOW SHUTTER AE MODE AUTO Slow Shutter [OFF, 2~128 Field] IRIS LEVEL GAIN LEVEL Sets Digital Slow Shutter. The number of piled SHUTTER SPD BRIGHTNESS field can be setup.
  • Page 29 HOW TO USE OSD MENU CAMERA SETUP (×30 Model) Setup the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ FOCUS MODE SEMIAUTO Focus Mode [AUTO/MANUAL/SEMIAUTO] MAX ZOOM x300 FLICKERLESS Sets camera focus mode. COLOR LINE LOCK SEMIAUTO Mode <WHITE BALANCE SETUP>...
  • Page 30 HOW TO USE OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL ------------------------ In Manual mode, Red and Blue level can be set WB MODE AUTO ADJUST up manually BLUE ADJUST Red Adjust [0~255] Blue Adjust [0~255] BACK EXIT Auto Exposure Setup...
  • Page 31 HOW TO USE OSD MENU Note) Backlight Setting The compensation rate of Level 1 is higher than that of Level 2. Value Description Value Description Criteria Area : Center of Image Criteria Area : Center of Image BLC Level : 1 BLC Level : 2 Criteria Area : Left of Image Criteria Area : Left of Image...
  • Page 32 HOW TO USE OSD MENU CAMERA SETUP (×26 Model) Setup the general functions of zoom camera module. ZOOM CAMERA SETUP ------------------------ FOCUS MODE SEMIAUTO Focus Mode [AUTO/MANUAL/SEMIAUTO] DIGITAL ZOOM FLICKERLESS Sets camera focus mode. COLOR LINE LOCK SEMIAUTO Mode <WHITE BALANCE SETUP> <AUTO EXPOSURE SETUP>...
  • Page 33 HOW TO USE OSD MENU White Balance Setup WB Mode [AUTO/MANUAL] WB SETUP - GLOBAL ------------------------ In Manual mode, Red and Blue level can be set WB MODE AUTO ADJUST up manually BLUE ADJUST Red Adjust [0~255] Blue Adjust [0~255] BACK EXIT Auto Exposure Setup...

  • Page 34: Motion Setup

    HOW TO USE OSD MENU Motion Setup Setup the general functions of Pan/Tilt motions. MOTION SETUP ------------------------ Motion Lock [ON/OFF] MOTION LOCK PWR UP ACTION If Motion Lock is set to ON, it is impossible to AUTO FLIP set up and delete Preset, Swing, Pattern and JOG MAX SPEED 120/SEC JOG DIRECTION...
  • Page 35 HOW TO USE OSD MENU Parking Action Setup If Park Enable is set to ON, camera runs assigned function automatically PARKING ACTION SETUP ------------------------ if there is no PTZ command during assigned "Wait Time". PARK ENABLE WAIT TIME 00:10:00 Park Enable [ON/OFF] PARK ACTION HOME...

  • Page 36: Preset Setup

    HOW TO USE OSD MENU PRESET Setup Preset Number [1~128] PRESET SETUP ------------------------ If a selected preset is already defined, camera PRESET NO. moves to pre-defined position and preset CLR PRESET CANCEL characteristics such as Label and Relay Outputs <EDIT SCENE> <EDIT LABEL>...
  • Page 37 HOW TO USE OSD MENU Edit Preset Scene Using Joystick, move camera to desired position. ○ EDIT SCENE - PRESET 1 ------------------------ By pressing NEAR key, save current PTZ data. ○ Press FAR key to cancel. ○ MOVE TO TARGET POSITION [NEAR:SAVE /FAR:CANCEL] Edit Preset Label...
  • Page 38 HOW TO USE OSD MENU Relay Out Setup Relay Out × [ON/OFF] RELAY OUT - PRESET 1 ------------------------ Sets Relay Outputs for assigned preset. RELAY OUT 1 RELAY OUT 2 BACK EXIT 38/47 Speed Dome Camera Instruction Manual...

  • Page 39: Swing Setup

    HOW TO USE OSD MENU Swing Setup Swing Number [1~8] SWING SETUP ------------------------ Selects Swing number to edit. If a selected Swing SWING NO. 1ST POS. NOT USED has not defined, "NOT USED" is displayed in 1st 2ND POS. NOT USED Position and 2nd Position SWING SPEED 30/SEC...

  • Page 40: Pattern Setup

    HOW TO USE OSD MENU Pattern Setup Pattern Number [1~4 ] PATTERN SETUP ------------------------ Selects Pattern number to edit. PATTERN NO. UNDEFINED If a selected pattern number is not defined, CLR PATTERN CANCEL <EDIT PATTERN> "UNDEFINED" will displayed under selected pattern number. Clear Pattern [CANCEL/OK] BACK...

  • Page 41: Group Setup

    HOW TO USE OSD MENU Group Setup Group Number [1~8] GROUP SETUP ------------------------ Selects Group number to edit. GROUP NO. UNDEFINED If a selected Group number is not defined, CLEAR GROUP CANCEL <EDIT GROUP> "UNDEFINED" will be displayed under selected Group number.
  • Page 42 HOW TO USE OSD MENU ④ Set up items such as Action, ###, Dwell and OPT. EDIT GROUP 1 ------------------------ NO ACTION ### DWELL OPT ------------------------ 1 NONE 2 NONE 3 NONE 4 NONE 5 NONE ------------------------ BACK :MOVE CURSOR] CANCEL [ :CHANGE VAL.] ⑤...

  • Page 43: System Initialization

    HOW TO USE OSD MENU System Initialization Clear All Data Deletes all configuration data such as display, SYSTEM INITIALIZE camera, motion setup and so on. ------------------------ CLEAR ALL DATA CLR DISPLAY SET Clear Display Set Initializes Display Configuration CLR CAMERA SET CLR MOTION SET CLR EDIT DATA Clear Camera Set...

  • Page 44: Specifications

    SPECIFICATIONS Specifications Appearance ×22 Model Video Signal System NTSC 1/4'' SONY Super HAD CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. 480 TV Line S/N Ratio 48 dB ×22 Optical Zoom, ×10 Digital Zoom Zoom Focal length F1.6, f=3.9(Wide)~85.8(Tele)mm...
  • Page 45 SPECIFICATIONS Specifications Appearance ×30 Model Video Signal System NTSC 1/4'' SONY Super HAD CCD Max. Pixels 811(H)×508(V) 410K 795(H)×596(V) 470K Effective Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. 480 TV Line S/N Ratio 48 dB ×30 Optical Zoom, ×10 Digital Zoom Zoom Focal length F1.6~3.2, f=3.3(Wide)~99(Tele)mm...
  • Page 46 SPECIFICATIONS Specifications Appearance ×26 Model Video Signal System NTSC 1/4'' SONY EXView CCD Max. Pixels 768(H)×494(V) 380K 752(H)×582(V) 440K Horizontal Res. 470 TV Line 460 TV Line S/N Ratio 50 dB ×26 Optical Zoom, ×12 Digital Zoom Zoom Focal length F1.6~3.8, f=2.5(Wide)~91(Tele)mm Camera Min.

  • Page 47: Dimension

    SPECIFICATIONS Dimension Main Body Ceiling Mount Bracket 1-1/2" NPT 158.2 Main Body (Sun-Shield) 227.2 Wall Mount Bracket 3/4" NPT Unit (mm) 47/47 Speed Dome Camera Instruction Manual...
