IC Realtime ICR650VD User Manual

FEATURES
1/3 INCH SONY SUPER HAD CCD II
High Resolution (600 TVL) / High Sensitivity
Upgraded Waterproof Housing (IP68 rating)
0.1Lux at F1.2 (Color) / 0.01Lux (B/W)
OSD Controlled / Day & Night / 2DNR
HLC / Motion / Privacy / Easy Installation / 3Axis
DC Auto IRIS V/F Lens 2.8~12mm
DC Auto IRIS & TDN V/F Lens 2.8~12mm
SPECIFICATION
MODEL
Resolution
Sensor
Total Pixels 811(H) x 508(V) 410K pixels
Effective Pixels 768(H) x 494(V) 380K pixels
Scanning System
S/N (Y signal)
Frequency Horizontal: 15.734KHz / Vertical: 59.94Hz
Video Output
Min.Illumination
White Balance
AUTO / MANUAL
Electronic shutter speed
(1/60sec ~ 1/100,000sec)
O.S.D
Backlight Compensation
AGC (Auto Gain Control)
2DNR (2D Digital
Noise Reduction)
Day & Night
Privacy
Motion Detection
Image Conversion
SHARPNESS
Operating Temperature/
Humidity
Storage Temperature/
Humidity
Power
Above specifications may be changed without any notice.
▶
VANDAL-PROOF DOME CAMERA
VANDAL-PROOF DOME CAMERA
600 TV Line
1/3 INCH SONY SUPER HAD CCD II
795(H) x 595(V) 470K pixels
752(H) x 582(V) 440K pixels
2:1 Interlace
More than 50 dB (AGC Off)
Horizontal: 15.625KHz / Vertical: 50.00Hz
CVBS: 1.0Vp-p / 75ohm
0.1Lux at F1.2 (Color) / 0.01Lux (B/W)
ATW1 / ATW2 / AWC→SET / MANUAL Adjustable
AUTO / MANUAL
(1/50sec ~ 1/100,000sec)
Built-in
OFF / BLC / HLC Selectable
LOW, MIDDLE, HIGH, OFF Selectable
ON / OFF
AUTO / COLOR / BW / EXT
OFF / ON (8 Zone)
OFF / ON (Motion size : 28 x 15, 4 AREA)
ON / OFF
ADJUSTABLE
-10'C ~ +50'C / 30% ~ 80% RH
-20'C ~ +60'C / 20% ~ 90% RH
DC12V [ AC24V / DC12V DualPower (option) ]
DIMENSION
144.64
INSTALLATION
VANDAL-PROOF DOME CAMERA
VANDAL-PROOF DOME CAMERA
100.00
104.4(109.0)
144.64
Screws
VIDEO
DC12V
AC24V / DC12V
DualPower
Screws
