Moxa PowerTrans Switch
PT-7728/7828

Hardware Installation Guide

Fifth Edition, June 2010
© 2009 Moxa Inc. All rights reserved.
Reproduction without permission is prohibited.
Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan,
R.O.C.
TEL: +886-2-8919-1230
P/N: 1802077280013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PT-7728 and is the answer not in the manual?

Questions and answers

Summary of Contents for Moxa Technologies PT-7728

  • Page 1: Hardware Installation Guide

    Moxa PowerTrans Switch PT-7728/7828 Hardware Installation Guide Fifth Edition, June 2010 © 2009 Moxa Inc. All rights reserved. Reproduction without permission is prohibited. Fl.4, No.135, Lane 235, Pao-Chiao Rd. Shing Tien City, Taipei, Taiwan, R.O.C. TEL: +886-2-8919-1230 P/N: 1802077280013...
  • Page 2: Package Checklist

    Package Checklist The Moxa PowerTrans switch is shipped with the following items. If any of these items are missing or damaged, please contact your customer service representative for assistance. 1 Moxa PowerTrans Switch Hardware Installation Guide CD-ROM with User’s Manual and SNMP MIB file...
  • Page 3: Dimensions (Unit = Mm)

    Dimensions (unit = mm) Rear View Side View Side View Top View Front View Fast Ethernet Interface Modules (for slots 1, 2, and 3) 96.8 96.8 96.8 PM-7200-4MSC2TX/PM-7200-4SSC2TX PM-7200-8TX PM-7200-1LSC6TX 96.8 96.8 96.8 PM-7200-6MSC/PM-7200-6SSC PM-7200-2MSC4TX/PM-7200-2SSC4TX PM-7200-4MST2TX 96.8 96.8 96.8 PM-7200-2MST4TX PM-7200 1MST6TX PM-7200-6MST 96.8...
  • Page 4: Rack Mounting

    WARNING Safety First! Be sure to disconnect the power cord before installing and/or wiring your Moxa PowerTrans Switch. Calculate the maximum possible current in each power wire and common wire. Observe all electrical codes dictating the maximum current allowable for each wire size.
  • Page 5: Wiring The Relay Contact

    Wiring the Relay Contact Each PT switch has one relay output. Refer to the next section for detailed instructions on how to connect the wires to the terminal block connector, and how to attach the terminal block connector to the terminal block receptor. FAULT: The relay contact of the 10-pin terminal block connector are used to detect user-configured events.
  • Page 6: Led Indicators

    LED Indicators Color State Description System LEDs System has passed self-diagnosis test on boot-up and is ready to run. GREEN Blinking System is undergoing the STAT self-diagnosis test. System failed self-diagnosis on boot-up. Power is being supplied to the main module’s power input PWR1.
  • Page 7: Specifications

    The corresponding module port’s Blinking data is being transmitted at 1000 Mbps. The corresponding module port’s data is being transmitted in full duplex mode. FDX/HDX GREEN The corresponding module port’s data is being transmitted in half duplex mode. The corresponding module’s port is the ring or chain port of this PT switch.
  • Page 8: Environmental Limits

    Storage Temp. -40 to 85°C (-40 to 185°F) Ambient Relative 5 to 95% (non-condensing) Humidity. 5 years Warranty Technical Support Contact Information www.moxa.com/support Moxa Americas: Moxa China (Shanghai office): Toll-free: 1-888-669-2872 Toll-free: 800-820-5036 Tel: +1-714-528-6777 Tel: +86-21-5258-9955 Fax: +1-714-528-6778 Fax:...
