Summary of Contents for Vook VDT2304SS-B

  • Page 1 VOOK DVR USER ..VDT2304SS-B, VDT2308SS-B, VDT2316SS-B...
  • Page 2 VOOK DVR User Manual CAUTION Please read this user manual carefully to ensure that you can use the device correctly and safely  We do not warrant all the content is correct. The contents of this manual are subject to change without notice ...

  • Page 3: Table Of Contents

    VOOK DVR User Manual Table of Contents 1 Introduction ..............................1 1.1 DVR Introduction ................................1 1.2 Main Features ..................................1 2 Hardware Installation ........................... 4 2.1 Install Hard Drive ................................4 2.2 Front Panel Descriptions ..............................4 2.3 Rear Panel Instructions................................ 5 2.4 Remote Controller ................................
  • Page 4 VOOK DVR User Manual 4.2.3 Mask ........................................19 4.3 Record Configuration ................................ 20 4.3.1 Enable ........................................20 4.3.2 Record Bitrate ......................................20 4.3.3 Time ........................................21 4.3.4 Stamp ........................................22 4.3.5 Recycle Record ......................................22 4.3.6 Snap ........................................23 4.4 Schedule Configuration ..............................23 4.4.1 Schedule .........................................
  • Page 5 VOOK DVR User Manual 4.9.3 Block/Allow list ....................................... 37 5 Search, Playback & Backup ........................38 5.1 Time Search ..................................38 5.2 Event Search ..................................39 5.3 File Management ................................40 5.4 Search by Image ................................41 5.5 Backup .................................... 42 6 Manage DVR ..............................
  • Page 6 VOOK DVR User Manual 7.4.1 Remote Playback ...................................... 55 7.4.2 Remote Backup ......................................61 7.5 Remote System Configuration ............................61 7.6 Tools ....................................62 7.7 Remote Information ................................63 8 Mobile Surveillance ............................. 64 8.1 By Phones with Windows mobile OS ..........................64 8.2 By Phones with Symbian OS .............................

  • Page 7: Introduction

    VOOK DVR User Manual 1 Introduction 1.1 DVR Introduction This model DVR (Digital Video Recorder) is designed specially for CCTV system. It adopts high performance video processing chips and embedded Linux system. Meanwhile, it utilizes many most advanced technologies, such as standard H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote control, mobile view(by phones), etc., which ensure...
  • Page 8 VOOK DVR User Manual RECORD & PLAYBACK  Record modes: Manual, schedule and motion detection alarm recording  Support recycle after HDD full  Resolution, frame rate and picture quality are adjustable  2 audio channels available  Two record search mode: time search and event search ...
  • Page 9 VOOK DVR User Manual NETWORK  Support TCP/IP, DHCP, PPPoE, DDNS protocol  Support IE browser to do remote view  Support setup client connection amount  Support dual stream. Network stream is adjustable independently to fit the network bandwidth and environment.

  • Page 10: Hardware Installation

    VOOK DVR User Manual 2 Hardware Installation Notice: Check the unit and the accessories after getting the DVR. Please don‘t power up the unit till the physical installation is complete. 2.1 Install Hard Drive Notice: 1. This series support one SATA hard drives. Please use the hard drive the manufacturers recommend specially for security and safe field.

  • Page 11: Rear Panel Instructions

    VOOK DVR User Manual Name Description When recording, the light is blue When access to network , the light is blue Power Power indicator, when connection , the light is blue Switch the output between VGA and BNC To connect external USB devices like USB flash, USB HDD for backup or USB port update firmware;...
  • Page 12 VOOK DVR User Manual Item Name Description Network port USB port Connect USB mouse or connect external USB devices DC12V POWER INPUT RS485 Connect to speed dome or keyboard（A is TX+, B is TX-） Fig 2-4 Rear Panel for 8-ch...

  • Page 13: Remote Controller

    VOOK DVR User Manual Fig 2-5 Rear Panel for 16-ch Item Name Description Audio in 2-CH Audio inputs Video in Video input channels from 1-8 Audio out Audio output, connect to the sound box Video out Connect to monitor HDMI port...
  • Page 14 VOOK DVR User Manual  Replace the battery cover. Note: Remote controller can be selected depending on the product model. Here we will take the bigger remote controller as an example to describe. Fig 2-6 Remote Controller Button Function Switch off—to stop DVR. Use it before turning off the power...
  • Page 15 VOOK DVR User Manual Multi Button To choose multi screen display mode Next Button To switch the live image To enter into auto dwell mode Audio To enable audio output in live mode Switch To switch the output between BNC and VGA...

  • Page 16: Control With Mouse

    VOOK DVR User Manual panel. Then you can press preset, cruise, track, wiper or light button to enable the relevant function. Note: Key points to check in case the remote doesn‘t work. 1. Check batteries polarity. 2. Check the remaining charge in the batteries.

  • Page 17: Use Mouse

    VOOK DVR User Manual 1. Make sure the mouse is plugged in the USB mouse port not the USB port on the front panel. 2. Try with a good know mouse. 2.5.2 Use Mouse During live: Double-click on any camera window for the full screen mode. Double-click again to return to the previous screen mode.

  • Page 18: Basic Function Instruction

    VOOK DVR User Manual 3 Basic Function Instruction 3.1 Startup & Shutdown Please make sure all the connections are done properly before you power on the unit. Proper startup and shutdown are crucial to expanding the life of your DVR.

  • Page 19: Login

    VOOK DVR User Manual 3.2 Login User can login or log off the DVR system. Once logged off the user cannot do any other operation except changing the multi-screen display. Notice: The default user name and password is ― admin‖ and 123456‖...

  • Page 20: Live Playback

    VOOK DVR User Manual 3.3.1 Live Playback Click Play button to play the record. Refer to Figure3-3. User can do complete operation by clicking the buttons on screen. Fig 3-3 Live Playback...

  • Page 21: Main Menu Setup Guide

    VOOK DVR User Manual 4 Main Menu Setup Guide Click right mouse or press FN button on the front panel to display the control bar on the bottom of the screen as Fig 4-1: Fig 4-1 Main Menu Toolbar Click the icon beside the screen display mode to display a channel select dialog.

  • Page 22: Basic Configuration

    VOOK DVR User Manual Fig 4-2 Main Menu Setup 4.1 Basic configuration Basic configuration includes three sub menus: system, date & time and DST. 4.1.1 System Step1: Enter into MenuSetupBasicSystem. Refer to Fig 4-3: Step2: In this interface you can setup the device name, device ID, video format, max network user, VGA resolution and language.

  • Page 23: Date & Time

    VOOK DVR User Manual Max Online Users: To set the maximum number of concurrent user logins in the DVR. Show wizard: If selected, the GUI would launch the startup wizard on every boot, allowing the user to do basic setup.

  • Page 24: Live Configuration

    VOOK DVR User Manual 4.2 Live Configuration Live configuration includes three submenus: live, main monitor and mask. 4.2.1 Live In this interface, user can setup camera name, adjust colors: brightness, hue, saturation and contrast. Step1: Enter into MenuSetupLiveLive tab. Refer to Fig 4-6: Note: A soft keyboard will pop up by clicking the camera name.

  • Page 25: Main Monitor

    VOOK DVR User Manual 4.2.2 Main Monitor Step1: Enter into MenuSetupLiveMain Monitor tab. Refer to Fig 4-8: Step2: Select split mode: 1×1、 2×2、 2×3、 3×3、 4×4 and channel. Click button to setup the previous channel group. Click button to set the latter channel group.

  • Page 26: Record Configuration

    VOOK DVR User Manual 4.3 Record Configuration Record configuration includes six sub menus: enable, record bit rate, time, recycle record, stamp and snap. 4.3.1 Enable Step1: Enter into MenuSetupRecordEnable tab. Refer to Fig 4-10: Parameter Meaning Record To enable/disable recording for...

  • Page 27: Time

    VOOK DVR User Manual Parameter Meaning Range from: 1-30（NTSC）1-25(PAL) Rate Resolution Support CIF , HD1, D1 Quality The higher the value is, the clearer the recorded image is. Six options: lowest, lower, low, medium, higher and highest. Encode VBR and CBR...

  • Page 28: Stamp

    VOOK DVR User Manual 4.3.4 Stamp Stamp： This provides an option to enable or disable the Camera Name and the Time stamp on the video. You can also choose a position for the stamp on the screen. Step1: Enter into MenuSetupRecordStamp interface. Refer to Fig 4-13: Step2: Checkmark camera name and time stamp;...

  • Page 29: Snap

    VOOK DVR User Manual 4.3.6 Snap In this tab, user can set up Resolution, quality, snap interval, snap number. 4.4 Schedule Configuration Schedule configuration includes two sub menus: schedule and motion. 4.4.1 Schedule This tab allows defining schedule for normal recording for seven days of a week, 24 hours of a day. Every row denotes an hourly timeline for a day.

  • Page 30: Motion

    VOOK DVR User Manual 4.4.2 Motion This tab allows to setup schedule for motion based recording. Step1: Enter into MenuSetupScheduleMotion tab. Refer to Fig 4-16: Step2: The setup steps for schedule for motion based recording are similar to normal schedule setup. You can refer to 4.4.1 Schedule for details.
  • Page 31 VOOK DVR User Manual Step3: Enter into Alarm Handling tab and select hold time and then click Trigger button. A dialog box will pop-up as Fig 4-18: Step4: Enter into alarm tab to select the options to handle alarm and then click OK.

  • Page 32: Video Loss

    VOOK DVR User Manual Step8: Select ― All‖ to setup all channels with the same parameters. Step9: Click ― Apply‖ button to save the settings. Step10: Enter into Schedule tab. The setup steps for schedule for motion based alarm are similar to normal schedule setup; Please refer to 4.4.1 Schedule for details.

  • Page 33: Alarm Out

    VOOK DVR User Manual If the threshold value is reached, the system will trigger the Disk Full Alarm. Click ― Apply‖ to save settings; Click ― Exit‖ to exit the current interface. 4.5.4 Alarm Out To setup alarm out: Enter into MenuSetupAlarm out tab. Refer to Fig 4-23: It is an inbuilt alarm output device.

  • Page 34: Sub-Stream

    VOOK DVR User Manual Then the device will distribute IP address, subnet mask, and gateway IP and DNS server. If you want to configure your own settings, please input the IP address, Subnet mask, Gateway DNS server manually. You can also check the PPOE checkbox to enable this feature and then enter username and password.

  • Page 35: Email

    VOOK DVR User Manual 4.6.3 Email Step 1: Enter into MenuSetupNetworkEmail tab. Refer to Fig 4-26: SMTP Server/Port: The name and port number of SMTP server. Check the SSL checkbox if the server requires a secure connection (SSL); user can setup mail servers (such as Gmail) as required.

  • Page 36: Other Settings

    VOOK DVR User Manual 4.6.5 Other Settings If your DVR is setup to use PPPoE as its default network connection, you may setup DDNS to be used in connection. The setting steps are as follows: Step 1: Select Other Settings tab. Enable DDNS server.
  • Page 37 VOOK DVR User Manual Click‖ Create Account‖ button to create user account. After that, you shall provide your card number, card expiration and security code as well as billing address. Finally click ― sign up for trial‖ button. Now, according to the domain name registration of ― DDNS‖，the domain name for DVR is ― abc.dyndns.tv‖, username is ― bcd‖ and password is ―...

  • Page 38: User Management Configuration

    VOOK DVR User Manual DDNS server DDNS server Website provided by dynamic domain name supplier. The optional: www.meibu.com ，www.dyndns.com, www.no-ip.com and mintdns type. User name User name for log in the website of domain name supplier Password Password for log in the website of domain name supplier Host domain The domain name user registered at the supplier‘s website.

  • Page 39: Configuration

    VOOK DVR User Manual Fig 4-31 Add User-Authority If you want to delete the user, please select the user you want to delete in the user list box and then click ― Delete‖ button. If you want to modify the user, please select the user you want to modify in the user list box and then click ― Setup‖ button to modify its general information and authority.
  • Page 40 VOOK DVR User Manual Fig 4-32 P.T.Z Configuration-Serial Port Definitions and descriptions of network stream: Parameter Meaning Address The address of the PTZ device Baud rate Baud rate of the PTZ device. Range form: 110, 300, 600, 1200, 2400, 4800, 9600, 19200, 34800, 57600, 115200, 230400, 460800, 921600.
  • Page 41 VOOK DVR User Manual Fig 4-33 P.T.Z Configuration-Advanced Fig 4-34 Advanced-Preset Step 3: In the preset setting tab, while clicking Setting button, a dialog will pop-up as Fig 4-35: User can control the dome by rotating up, down, left, right and adjust ...

  • Page 42: Advanced

    VOOK DVR User Manual Click Add icon to set the speed and time of preset point; select a preset point and then click Delete icon to delete that  preset point; click Modify icon to modify the setting of a preset point. User can click icons to adjust the position of preset point.

  • Page 43: Reset

    VOOK DVR User Manual 4.9.1 Reset This would reset the system to factory defaults and reboot the DVR. 4.9.2 Import/Export User can export the data files into mobile storage devices as backup and can also import specified data files from mobile storage device to DVR.

  • Page 44: Search, Playback & Backup

    VOOK DVR User Manual 5 Search, Playback & Backup Search configuration includes four submenus: time search, event search, file management and image. 5.1 Time Search Step1: Enter into MenuSearch Time search tab. Refer to Fig 5-1: Fig 5-1 Search Configuration-Time Search Step2: Select date and channels on the right hand side and press ―...

  • Page 45: Event Search

    VOOK DVR User Manual Step4: Select the channel display mode and click button to play record. Use the playback toolbar to control the playback. Playback buttons Note: When the monitor resolution is set to VGA800*600, Part of the time search interface will be hidden. Click the ― Expand to‖ button to expand the whole interface.

  • Page 46: File Management

    VOOK DVR User Manual Fig 5-2 Search Configuration-Event Search Step 2: Select date and channels on the right hand side. A data with highlighted borderline indicates presence of data. Step 3: Then checkmark Motion. You can search for motion based recording.

  • Page 47: Search By Image

    VOOK DVR User Manual Fig 5-3 Search Configuration-File Management Step 2: Select date and channels. The date with highlighted borderline indicates presence of data. Step 3: Press ― Search‖ button to display the searched files in the file list box.

  • Page 48: Backup

    VOOK DVR User Manual Note: In order to take images on alarm, the snapshot feature should be activated in ― Alarm Handling‖ for different kind of alarms. Please refer to 4.5 Alarm Configuration for details. 5.5 Backup This unit supports backup by USB flash drive. User also can make backup by IE browser via internet. Refer to 7.3.2 Remote backup.

  • Page 49: Manage Dvr

    VOOK DVR User Manual 6 Manage DVR 6.1 Check System Information Check system information includes five submenus: system, event, log, network and online user. 6.1.1 System nformation In this tab, user can check the hardware version, MCU version, kernel version, device ID, etc.

  • Page 50: Record Information

    VOOK DVR User Manual Disconnect: Disconnect the online users to access DVR. If this function is used by the admin, the particular PC will not be able to access the device for five minutes. . 6.1.6 Record nformation In this tab, a user can check resolution, ftp and record status including motion based recording, manual recording or schedule recording.

  • Page 51: Logoff

    VOOK DVR User Manual Step 2: Connect the USB flash drive to the USB port. Step 3: Enter MenuUpgrade tab. Then the upgrade software name would be displayed in the upgrade list box. Step 4: Select that software and then click upgrade button. It will upgrade automatically.

  • Page 52: Remote Surveillance

    VOOK DVR User Manual 7 Remote Surveillance 7.1 IE Remote Surveillance In order to view the DVR from a network it must be connected to a LAN/WAN or internet. The network setup should be done accordingly. Please refer to 4.6 Network Setup. This DVR supports IE browser, on Windows XP and Vista platform.
  • Page 53 VOOK DVR User Manual Step 3: Open IE browser, input IP address, or dynamic domain name and enter. If HTTP port is not 80, add the port number after IP address or domain name. Step 4: IE will download ActiveX automatically. Then a window pops up and asks for user name and password. Input name and password correctly, and enter to view.

  • Page 54: Remote Surveillance Through Apple Pc

    VOOK DVR User Manual Step 2: When accessing the remote interface of DVR, user can input WAN IP to access directly (user can enter into Main menuInformationNetwork interface to check IP address). Step 3: If users want to utilize dynamic domain name, please apply for a domain name in a DNS server supported by the DVR or router.

  • Page 55: On Lan

    VOOK DVR User Manual Third: Select ― open in 32- bit mode‖. 7.2.1 On LAN Step 1: After starting Apple computer, click Apple icon. The following window will pop up. Please select ― System Preferences‖‖Internet &Wireless‖click ― Network‖ Step 2: Enter into Network interface and then click ― Ethernet Connected‖ to check the internet connection of Apple PC.
  • Page 56 VOOK DVR User Manual Step 3: After acquiring the IP address, Subnet Mask and so on, please enter into the DVR‘s Main MenuSetupNetwork interface to manually input IP address, Subnet Mask and Gateway according to the configuration of PC. The network segment should be the same as the PC.

  • Page 57: On Wan

    VOOK DVR User Manual the following window will pop up： Input the name and password of Apple PC and then click ― OK‖ to install this Active X control. Step 6: After finishing installing the Active X control, please quit from the Safari browser. Right click Safari icon on the desktop and then select ―...

  • Page 58: Remote Preview

    VOOK DVR User Manual 7.3 Remote Preview Fig 7-2 Remote Live Preview Symbol and function Definitions: Channel indicator Screen display mode Volume ① ② ③ Snapping picture Start manual record Start IE record ④ ⑤ ⑥ Bidirectional talk Playback Color ⑦...
  • Page 59 VOOK DVR User Manual Note: Click button to record manual and the record file will be saved in user’s PC. Screen display mode: Click the icon beside the screen display mode, channel select dialog will appear as below: Take 8-channel view for example: user can checkmark 8 channels form 1-ch to 16-ch at random to display the live pictures.
  • Page 60 VOOK DVR User Manual Buttons Description means the dome rotate up. means the dome rotate up left. means the dome rotate up right means the dome rotate down. means the dome rotate left down. means the dome rotate right down.

  • Page 61: Remote Playback & Backup

    VOOK DVR User Manual Fig 7-4 Right Key Sub Menu Stream: this DVR supports master stream and sub stream. Master stream has higher frame rate, max 25 fps （ PAL） /30 fps （NTSC） for every channel, but it needs higher network bandwidth; second stream has low frame rate, max 6FPS （PAL） /7FPS（NTSC） for every channel, but it requires low network bandwidth as compared to the master stream.
  • Page 62 VOOK DVR User Manual Fig 7-5 Play Record File Interface This DVR supports remote time search, event search and file management. By Time Search: Step1: Enter into SearchTime search. Refer to Fig 7-6:...
  • Page 63 VOOK DVR User Manual Fig 7-6 Time Search Interface Step2: The highlight date in the area② indicates recorded data. Select the date in the area ② and record channels in area③ Step3: Click ― Search‖ button. The record data will be displayed in the data information list box;...
  • Page 64 VOOK DVR User Manual Fig 7-7 Time Search Playback By Event Search: Step1: Enter into SearchEvent Search. Refer to Fig 7-8:...
  • Page 65 VOOK DVR User Manual Fig 7-8 Event Search Interface Step 2: Click the highlight date and select record channels. Step 3: Checkmark the event type: motion. Step 4: The events will be display in the event list box by clicking Search button.
  • Page 66 VOOK DVR User Manual File Management Step 1: Enter into SearchFile management. Refer to Fig 7-9: Step 2: Select highlighted date and channels. Step 3: Click ― Search‖ button to search the recorded files. Fig 7-9 File Management Interface Lock: Select certain file item in the file list box and then click ― Lock‖ button to lock this file that ca not be deleted or overlaid Unlock: Select a locked file and then click ―...

  • Page 67: Remote Backup

    VOOK DVR User Manual 7.4.2 Remote Backup Click Backup button to enter into backup interface. Refer to Fig 7-10: Fig 7-10 Remote Backup Interface Step1: Select channels, set the start and end time and then click ― search‘ button to display the file information in the file list box Step2: Select backup files and click ―...

  • Page 68: Tools

    VOOK DVR User Manual configuration, alarm configuration, network configuration, PTZ configuration and user configuration. You should select an option from the menu list on the left and then setup the relative parameters. Only one user can do configuration setup at a given point of time. Click Config...

  • Page 69: Remote Information

    VOOK DVR User Manual 7.7 Remote Information The Info tab provides a web based interface to access the general information pertaining to the DVR‘s settings. It includes five submenus: System, Event, Log, Network and Online users. The sub menu list and the options in every menu are similar to that of the DVR. Please refer to Chapter 6 System information for more details.

  • Page 70: Mobile Surveillance

    VOOK DVR User Manual 8 Mobile Surveillance This DVR supports mobile surveillance by phones with Windows mobile, symbian, android, Iphone and Blackberry OS. At the same time, it supports 3G network. We tested Dopod D600 (WM5) and Dopod S1 (WM6), which work fine with the DVR.

  • Page 71: By Phones With Symbian Os

    VOOK DVR User Manual Step6：Camera 1 is the default channel after login. Change the channel in rolling-down menu of ― Channel‖. Refer to the below picture on the right: Notice: User name password here are the same with that used on the DVR.
  • Page 72 VOOK DVR User Manual Step3：A welcome window will pop up and requires a package. Click the software name to download. Refer to the picture on the right: Step4：A security windows will pop up after downloading and ask if install the package. Click YES to install.

  • Page 73: By Phones With Iphone Os

    VOOK DVR User Manual 8.3 By phones with iPhone OS 1. Install through iPhone. Step 1. Open App Store function of iPhone. Step 2. Enable ―s earch‖ function to search ― Superlive‖.
  • Page 74 VOOK DVR User Manual Step 3: Click Superlive-pro, enter into ― introduce‖ interface and then click ― FREE‖, it will change into ― INSTALL‖ Step 4: Input iTunes Store password and then click ― OK‖. The software will be installed automatically.
  • Page 75 VOOK DVR User Manual Note: If it is the first time for user to operate, please enter user ID; if there is no Store account, user needs to apply for one. 2. Install through PC. Step 1: Install iTunes store in PC and then login...
  • Page 76 VOOK DVR User Manual Step 3: Enable ―s earch‖ function to search ― Superlive-pro‖ Step 4: Click ― free application‖ button Step 5: Input apple ID and password, then click ― acquire‖ Step 6: Checkmark ― synchronously apply program‖ and ― Superlive-pro‖, and then click ― Apply‖ button...
  • Page 77 VOOK DVR User Manual Enter server‘s IP address (or domain name), user name and password Click ― Remember server‖ to save the setting; click button can quick input saved server address, user name and password. Main Interface Image view Four channel...
  • Page 78 VOOK DVR User Manual Upward rotates the PTZ Downward rotates the PTZ Leftward rotates the PTZ Rightward rotates the PTZ Stop rotating the PTZ Zoom In/Focus In/Iris Add Zoom Out/Focus Out/Iris Sub To enter into the next interface To return to the previous interface...
  • Page 79 VOOK DVR User Manual Playback Click icon to enter into the playback interface. Then click ‗Search‘ button, select the time and channel to playback and click button. Now you can see the local file list. Select a file and click play button to playback. You can also copy or delete the file. Finally, click ‗Close‘...
  • Page 80 VOOK DVR User Manual Server list Click button to enter into server list interface. You can click icon to add a server list. After you add the list, you can click icon to edit the server information and click icon to delete this server information.

  • Page 81: By Phones With Android Os

    VOOK DVR User Manual Click icon to enter into information view interface. You can check the information of system, network and online users. In the system interface, you can see the information of device name, device ID, hardware version, MCU version and so on. In the network interface, you can see the information of http port, server port, IP address, gateway, network status, etc.
  • Page 82 VOOK DVR User Manual Step 3: Press ― Install‖ button Step 4: Click ― OK‖ button Step 5: User can view the download and install process in notifications; Once finishing downloading, the software will install automatically. Login...
  • Page 83 VOOK DVR User Manual Enter into server‘s IP address (or domain name), user‘s ID and password. Click ― Remember server‖ to save the setting; click button can quick input saved server address, user name and password. Main menu playback record file image view 【Playback】...
  • Page 84 VOOK DVR User Manual Live view Stop playing Single channel display Screen mode Four channels display Snap Talk Record Live audio Hide Image view The first picture The previous picture Next picture The last picture Zoom in Zoom out Delete...
  • Page 85 VOOK DVR User Manual Record playback Play/Pause Stop Fast forward Slow play Click Playback icon in the Main Menu interface to enter into the playback interface. First, choose channel. Second, select the record file and click it to playback. Finally, click ‗Return‘ button to return to the previous interface.

  • Page 86: By Phones With Blackberry Os

    VOOK DVR User Manual If Audio alarm is enabled, when Video Loss/Motion happen，sound alarm will be triggered; If shake Alarm is Alarm setting enabled, when Video Loss/Motion happen， shake alarm will be triggered. User can setup the relevant parameters of mobile video.
  • Page 87 VOOK DVR User Manual 2. Click ― Supercam‖ to link 3. Click ― Download‖ button on the popup interface and the download progress will be shown. 4. Finished downloading, the software will be installed automatically. Note: If the software fails to download, please check in accordance with the following steps:...
  • Page 88 VOOK DVR User Manual Note：When user used the Supercam software in mobile phone with touch screen, there will be compatible problem. Solution: Enter into Options Menu->Advance options->Applications->Supercam and click ― Disable Compatibility‖ button. This problem will be solved. Login Enter server‘s IP address (or domain name), user‘s ID and password.
  • Page 89 VOOK DVR User Manual Live view Note: User can click Return button on the Blackberry phone to return the previous interface.
  • Page 90 VOOK DVR User Manual Mark 1 Current viewing channel Mark 2 Channel status Switch channels PTZ, click to switch to Fig 2 interface Snap Full screen Background alarm Stop rotating the PTZ Upward rotates the PTZ Downward rotates the PTZ...
  • Page 91 VOOK DVR User Manual Software configuration Information view...

  • Page 92: Appendix A Faq

    VOOK DVR User Manual Appendix A FAQ Q1. Why the DVR doesn’t turn on even after connecting to the power? a. The power adapter could have gone bad. Please change a new power adapter b. The power from the adapter may be not enough for operating the DVR. Please use the power adaptor supplied along with the DVR.
  • Page 93 VOOK DVR User Manual a. Make sure the HDD was formatted prior to use. b. Maybe the user hasn‘t enabled the record function or has done incorrect setup. Please refer to Chapter 5. c. Maybe HDD is full and thus the DVR is not able to record. Check HDD information from Disk management and if required, please enable the recycle function.
  • Page 94 VOOK DVR User Manual b. Other plug-ins or anti-virus may block ActiveX. Please disable or do the required settings. Fig 8-1 Fig 8-2 Q9: DVR displays “please wait…”all the time a.HDD power cable and data cable may not be well connected. Please check the connections for HDD.
  • Page 95 VOOK DVR User Manual Q11: A hard disk is being identified as a new device however it was being used with another DVR of same model. Should it be formatted prior use? It is possible to migrate an HDD from one DVR to another provided that the DVRs are of the same model and that the HDD being migrated would be used as the sole disk in the new DVR.
  • Page 96 VOOK DVR User Manual GMA3100/NVIDIA GeForce 8400/ ATI RADEON HD3450 Windows 2000(SP4 above) /Windows XP(SP2 above) VISTA DirectX Q14: How to handle the situation that the codec Control is blocked when downloading in the VISTA or Win7 system? This problem can be fixed in two ways: Enter Control PanelUser Account and Family Safety ...
  • Page 97 VOOK DVR User Manual After you install it, open this player and click ― Open Path‖ button to open your backup file. Next, click play button to play the backup file. Double click the image and then right click to enable audio. If you save your backup files in AVI format, you can directly...

  • Page 98: Appendix B Calculate Recording Capacity

    VOOK DVR User Manual Appendix B Calculate Recording Capacity Users can calculate the size of hard disk according to the saving time and DVR recording settings. The DVR uses fixed video bit rate. The below are the details at different settings.

  • Page 99: Appendix C Compatible Devices

    VOOK DVR User Manual Appendix C Compatible Devices 1. Compatible USB drive after test. Brand Capacity 512MB, 1G, 2GB Netac Kingston Aigo Smatter vider SanDisk 2. Compatible HDD list Brand Capacity Seagate Barracuda 80G/160G/250G/320G /1.5T/2TB Seagate SV35.3 Seagate Pipeline HD.2...

  • Page 100: Appendix D 4-Ch Specifications

    VOOK DVR User Manual VDT2304SS-B 4-CH Specifications Compression format Standard H.264 Video output Composite：1.0V p-p/75Ω BNC×1 , VGA×1，HDMI×1 Video input Composite：1.0V p-p/75Ω BNC×4 HDMI/VGA Resolution 1920*1080/1280*1024 /1024*768/ 800*600 Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC) Display Frame Rate 100FPS (PAL), 120FPS (NTSC)

  • Page 101: Appendix E 8-Ch Specifications

    VOOK DVR User Manual VDT2308SS-B 8-CH Specifications Compression format Standard H.264 Video output Composite：1.0V p-p/75Ω BNC×1 , VGA×1，HDMI×1 Video input Composite：1.0V p-p/75Ω BNC×8 HDMI/VGA Resolution 1920*1080/1280*1024 /1024*768/ 800*600 Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC) Display Frame Rate 200FPS (PAL), 240FPS (NTSC)

  • Page 102: Appendix F 16-Ch Specifications

    VOOK DVR User Manual VDT2316SS-B 16-CH Specifications Compression format Standard H.264 Video output Composite：1.0V p-p/75Ω BNC×1, VGA×1，HDMI×1 Video input Composite：1.0V p-p/75Ω BNC×16 HDMI/VGA Resolution 1920*1080/1280*1024 /1024*768/ 800*600 Record Resolution 352*288/704*576 (PAL), 352*240/704*480(NTSC) Display Frame Rate 400FPS (PAL), 480FPS (NTSC) Record Frame Rate...
  • Page 103 VOOK...
