Related Manuals for Alto Vision 17
Summary of Contents for Alto Vision 17
- Page 1 Electronic Service Manuals This electronic document is provided as a service to our customers. We do not create the contents of the information contained in this docu- ment. Should you have detailed questions pertaining to the information contained in this document, you may contact Michco, or the manufac- turer which provided the original information in this electronic deliver- able.
- Page 2 This book has important information for the use and safe operation of this machine. Failure to read this book prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well.
-
Page 3: Table Of Contents
Brush Gear Box Assembly Drawing & Parts List ............ 34 Brush Motor Drawing & Parts List ................35 115V Electrical Schematic ..................36 115V Connection Diagram ..................37 Parking Brake Kit ....................38 Page -2- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 4: Operator Safety Instructions
Failure to read the Owner's Manual prior to operating or attempting any service or maintenance procedure to your Clarke machine could result in injury to you or to other personnel; damage to the machine or to other property could occur as well. You must have training in the operation of this machine before using it. - Page 5 Do not use this machine as a step or furniture. Do not ride on this machine. CAUTION: Your machine warranty will be voided if anything other than genuine Clarke parts are used on your machine. Always use Clarke parts for replacement.
-
Page 6: Introduction & Machine Specifications
Introduction & Machine Specifications The Vision 17 automatic scrubber increases labor efficiency while providing superior cleaning. This unit dispenses the solution, scrubs the floor and then recovers the soiled solution - all in one pass. The Vision 17E can be adapted to clean any hard floor surface with a variety of floor cleaning accessories including a variety of bassine, steel, polypropylene, and nylon scrub brushes, pads and pad drivers. -
Page 7: Grounding Instructions 115V
If you use an extension cord, use an exten- sion cord with minimum wire size 14 AWG. Do not use an extension cord longer than 50 feet. Do not join two extension cords. Page -6- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 8: Procedures For Transporting Machine
With the aid of another person, carefully guide the machine out of the truck or van onto the unloading ramp slowly. When guiding the machine on the unloading ramp, position yourself to maintain a slow speed. Never stand below machine on ramp. CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -7-... -
Page 9: Machine Controls And Features
For more solution, turn the knob to the right. For less solution, turn the knob to the left. Brush Vacuum Solution Figure #4 Circuit Breaker. Electric Model Brush Motor Circuit breaker only. (located on control panel) Page -8- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... - Page 10 To lower the squeegee, pull the handle to the right and lower. To raise the squee- gee, lift the handle up and push to the left. Figure #7 CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -9-...
-
Page 11: How To Install The Squeegee
4. Push the hair pin through the holes on the squeegee bracket. 5. Attach the squeegee hose to the hose connection on top of squeegee. See figure #12. Figure #12 Page -10- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 12: How To Prepare The Machine For Operation
See Figure #11. 5. While lifting the machine up with the machine lift handle (a), lower the support leg and position like a kickstand (b). See Figure13 Figure 13 CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -11-... - Page 13 "DOWN" position when the machine is not in use can damage the brush or pad driver. Always leave the brush motor in the "UP" position while not in use. Page -12- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V...
-
Page 14: How To Operate The Machine
7. Move the machine forward in a straight and steady direction. If machine is a traverse model, select a speed and then press on the traverse handle switch to activate the traverse. CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -13-... -
Page 15: Shutting Down The Machine
3. After the solution has set on the floor long enough to start cleaning, repeat the pass with the squeegee in the lowered position. 4. If the floor remains dirty, repeat the passes following the steps outlined in "Operating the Machine". Page -14- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 16: Maintenance
Figure #17. Figure #17 5. Make sure the solution and recovery drain hoses are in position on the back of the machine. See figure #18. Secure the hose drain plugs. CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -15-... -
Page 17: Procedures To Perform At The End Of Work
6. Use a clean cloth and wipe the surface of the machine. 7. Remove the brush or pad driver. Rinse clean and allow to dry. Discard the pad if necessary. 8. Store the machine and accessories in a dry building. Page -16- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 18: Accessories
PADS BY CASE Color Vision 17 Color Vision 17 Yellow 979169 Green 976157 White 976052 Brown 976055 976053 Black 976158 Blue 976054 CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -17-... - Page 19 NOTES...
-
Page 20: Section Ii - Parts And Service Manual
Vision 17E 115V Section II Parts and Service Manual (78452B) -
Page 21: How To Correct Problems In The Machine
Have an authorized service person casters or to the solution valve. make the repairs. The motor is not running. Repair the wiring, replace the switch, Service the motor, circuit breaker and the contractor. Page -20- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... - Page 22 NOTES CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -21-...
-
Page 23: Vision 17E 115V Machine Assembly Drawing
CLARKE TECHNOLOGY Vision17 E 115V Model #00370A 115V Machine Assembly 2/01 Page -22- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 24: Parts List
839204 Trim, Frame 77261A Plate, Warning 83010A Rivet 58901A Wire Tie 699202 Wire Tie 77049A Label, Squeegee Lift 77050A Label, Brush Lift 77053A Tag, Hang Instruction 77077A Plate, Warning (Head) CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -23-... -
Page 25: Non Traverse Assembly Drawing & Parts List
87607A Washer, Nylon Nominal 61247A Bracket, axle 59934A Wheel 920346 PAL Nut 601104 Bushing, Pivot 60149A Shaft *NOTE: Place washers as required to center the wheels (Number of washers may vary) Page -24- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 26: Brush Lift Drawing & Parts List 11/98
Brush Lift Drawing & Parts List 11/98 Form #16608A Part No. Description 65424A Lift Brush, Weldment 85600A Screw ¼ - 20 51516A Bushing 608210 Spacer, Handle, Bolt 920208 Nut, ¼-20 CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -25-... -
Page 27: Main Frame Assembly Drawing
CLARKE TECHNOLOGY Vision 17E 115V ASM, Main Frame Drawing 2/01 Form #16923A Page -26- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 28: Parts List 2/01
Bracket, Arm Weldment 85397A Screw 10 - 24 X 66939A Retainer 66961A Retainer Skirt 81112A Nut, 5/16-18 ESNA 84229A Screw, 5/16-18 x .88 980614 Washer, 1/4 Star 49068A Wire, Ground CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -27-... -
Page 29: 115V Brush Motor Assembly Drawing & Parts List
- 16 X 1 Hex Head 67865A Spacer Tilt handle 980638 Lockwasher 3/8 63600A Guide RH 61238A Bracket Motor Lift 84242A Screw ¼ - 20 X 68761A Guide LH 20308A Adapter Motor Page -28- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 30: 115V Control Panel Assembly Drawing & Parts List
Locknut, ½" Conduit 46106A Rectifier, Bridge 920056 Nut, 6 - 32 Elastic 920224 Nut, 10 - 32 Hex 980603 Washer, Shakeproof 54349A Gasket, Panel 170870 Washer 699202 TIE, Wire 49687A Harness, Brush CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -29-... -
Page 31: Squeegee Assembly Drawing & Parts List 4/96
Screw ¼ - 20 X ½ 838201 Spacer, Wheel Guide 839702 Wheel, Brush Guide 962841 Screw, - 18 x 1¼ Blades Available: 30918A Blade, Sq., Front Nitrile/EPDM 30919A Blade, Sq., Rear Nitrile/EPDM Page -30- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 32: Solution Tank Assembly Drawing & Parts List
980651 Washer 38964B Tank, Solution 80031A Bolt, Shoulder 962943 Screw 52755A Cover, Handle 722021 Clamp, Hose 52503A Cable, Solution 833401 Gasket, Drain 36101A Ratchet, Handle 84236A Screw, 6-32 980603 Washer CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -31-... -
Page 33: Recovery Tank Assembly Drawing & Parts List
Cover, Solution Tank 14092A Switch, Float Shut-Off 34256A Gasket, Rec. Drain 56459A Strainer, Relief 85519A Screw, ¼-20 x 39323A Tube, Recovery 81110A Nut 10-24 51828A Strap, Hose 920797 Nut, Drain Valve Lock Page -32- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 34: Vacuum Motor Drawing & Parts List
Stationary Fan 50618A Commutator End Bracket 57904A Fan Shell 638313 Load Spring 980205 Washer 53100A Disc 920329 902679 Ball Bearing 53906A 902648 Ball Bearing 53914A Fan - Rotating 59803A Neoprene Washer CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -33-... -
Page 35: Brush Gear Box Assembly Drawing & Parts List
57846A Ring, Snap 58143A Seal, Oil, Small 52050A Cap End 56668A O - Ring 51176A Bearing, Large 58316A Shaft and Gear 902605 Bearing, Small 54883A Housing 58144A Seal, Oil Large Grease Page -34- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 36: Brush Motor Drawing & Parts List
Brush Board Assembly (w/ Springs & Brushes) 448396 Brush Spring 50516A Brush 55654A Lead Assembly 55655A Lead Assembly 59805A Helical Washer 50515A Thru Bolt 80501A Shaft Key 54238A B.E. Bracket Assembly (Gear Box) CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -35-... -
Page 37: 115V Electrical Schematic
CLARKE TECHNOLOGY Vision 17 E 115V Model #00370A - 115V Electrical Schematic 2/01 Page -36- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... -
Page 38: 115V Connection Diagram
CLARKE TECHNOLOGY Vision 17 E 115V Model #00370A - 115V Connection Diagram 2/01 CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -37-... -
Page 39: Parking Brake Kit
The brake control prevents the movement of the machine. The brake pedal is at the back of the machine in the lower left corner. To activate the brake, push the pedal down. Lift the pedal to release the brake. Page -38- CLARKE TECHNOLOGY Operator's Manual -Vision 17E 115V... - Page 40 +46 31 706 73 00 Customer Service Headquarters and Factory 2100 Highway 265 ALTO Norge A/S, Oslo (Norway) Springdale, Arkansas 72764 Bjornerudveien 24 (501) 750-1000 N-1266 +47 2275 1770 Technical Service CLARKE TECHNOLOGY Operator's Manual - Vision 17E 115V Page -39- 3/98 1-800-356-7274...
- Page 41 This Clarke Industrial/Commercial Product is warranted to be free from defects in materials and workmanship under normal use and service for a period of one year from the date of purchase, when operated and maintained in accordance with Clarke's Maintenance and Operations instructions.
