Introduction

Specifications

Wingspan
Fuselage Length 900mm
Flying Weight
Motor
Battery
Flight Time

Items required for operation

8 * AA Batteries for the Transmitter

Glossary

Landing gear - Wheels on bottom of aeroplane
Vertical fin - Fin on back of aeroplane
Rudder - Moveable fin on vertical fin
Elevator - Moveable fins of the stabiliser
Fuselage - Main body of the aircraft containing motor, receiver, speed control, servos and battery
Stabiliser - Smaller flat wing on tail of aircraft
General Safety Precautions
• Read and follow this manual completely, observing all instructions and safety directions. Otherwise, serious injury and damage can occur.
Think about your safety, and the safety of others, first.
• Hold the aeroplane securely when the flight battery is plugged in, keep the propeller away from body parts and clothing, even when it isn't
spinning, as it could be turned on by accident. Beware of hair becoming en-tangled in the propeller, especially while launching your aero
plane.
•
Do not fly when it's too windy or you may lose control and crash, causing injury or damage. Never fly near people, vehicles, train tracks,
buildings, power lines, water, hard surfaces or trees. Never allow anyone to attempt to catch the aeroplane while it's in flight or serious
injury may result.
• Adult supervision for flying and battery charging is recommended for pilots age 14 and younger.
•
Only use a battery charger that is Ni-MH compatible to charge the flight battery. Never leave the charger
This will help prevent overcharging and make sure damage does not occur to the battery, charger or any other property. While charging,
place the battery on a heat-resistant surface. Do not lay it on carpet or upholstery while charging.
•
Never cut into the battery, charger, or aeroplane wires or serious injury may occur. Causing the battery to "short out" (crossing negative
and positive bare wires) can cause fire, serious injury and damage.
• When you finish flying your aeroplane, always unplug the battery before you turn off the transmitter.
•
Never fly on the same frequency as another RC aeroplane in your area. The frequency of the aeroplane is shown on the frequency crys
tals.

Recommended Tools

These tools are not included with the product but are recommended for use whilst working or repairing your product :-
Foam Safe Super Glue

Charging the battery pack

Use the supplied charger to charge the supplied battery. Other products are available and if used, you must follow the products instructions to
avoid damage.
The charging time for the battery is 300 minutes.
1. Connect the 240V wall mounted mains charger.
2. Plug the battery into the charge lead connector.
3. When the battery is warm it is charged noting the charge time.
4. Unplug the battery from the charger when finished.
Cautions
•
Use the charger with adult supervision. Do not use the charger near water or when wet.
•
Do not use the charger if the wire is frayed or worn. If the wire is frayed or worn a short circuit can cause a fire or burns.
• If your battery gets hot and exceeds 50 degrees C during charge it may be faulty and should be replaced.
•
If the battery pack bulges during charge or use it is faulty and should be replaced.
•
Never leave your battery on charge unattended.
1380mm Transmitter
Receiver
578g Charger
370 Size brushed Servos
Ni-MH 8.4V 1300 mAh Speed Control Brushed 15A 7.2-8.4V
Approx 20 minutes
Mini Phillips Screwdriver
3
MTX-41 35 MHz 4 Channel
MRX-41 35 MHz 4 Channel
Mains 240V 9V 280mah
2.2Kg.cm 0.2s/90Deg 18g
unattended while charging.
Packing Tape
