HOW TO CHANGE FILAMENT
You can change filament at any time when the MakerBot Replicator Mini is not heating up
or printing.
To Load
• I n the print monitor panel, click Change. Then click Load. The Smart Extruder will
•
start to heat up. When the Smart Extruder is fully heated, the extruder motor will
start to turn.
• • When you hear the motor turning, grasp the top of the extruder assembly and push
•
the free end of filamant into the loading tube at the top of the Smart Extruder. Keep
pushing on the filament until you feel the Smart Extruder pulling it in.
•
• Wait until you begin to see plastic emerging from the extruder nozzle. Then click
• Done to stop the process.
To Unload
• I n the print monitor panel, click Change. Then click Unload. The Smart Extruder
•
will start to heat up. When the Smart Extruder is fully heated, it will go through a
two-part unloading process.
•
• Remove the filament from your Smart Extruder only when MakerBot Desktop
• directs you to. Then click Done.
Tips
• B efore loading, cut the end of your filament to create a clean edge.
• B efore removing the current filament spool, unclip the filament guide tube from
the spool pocket.
• Clip the filament guide tube back into place after inserting a new filament spool.
• Clear away any excess extruded filament before printing.
