DVI USB Dual Mode LAN or Cat 5 KVM
Extender with Audio - 330ft (100m)
SV565LANDUA
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 06/06/2012
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SV565LANDUA
Summary of Contents for StarTech.com SV565LANDUA
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 06/06/2012...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Connecting Your KVM Extender ............3 Preparing Your Site ........................... 3 Local Extender Unit Installation ......................3 Remote Extender Unit Installation ...................... 3 Connecting the Local Extender to the Remote Extender ............4 Powering the Units ........................... -
Page 4: Introduction
Introduction The SV565LANDUA Dual Mode USB DVI KVM Console Extender over Cat5 (100m) or LAN lets you control a USB & DVI-D PC or KVM switch over an IP Local Area Network, or by direct Cat5 (or better) cable connection, up to 100 meters (330 feet) away. -
Page 5: Front View
Front View Rear View Instruction Manual... -
Page 6: Connecting Your Kvm Extender
Connecting Your KVM Extender Preparing Your Site Before you can install the product, you need to prepare your site. 1. Determine where the host computer will be located and set up the computer. 2. Determine where the console devices (mouse, keyboard, monitor) will be located and place them accordingly. -
Page 7: Connecting The Local Extender To The Remote Extender
3. Connect a USB keyboard and/or mouse to any of the USB Hub ports on the Remote unit. OPTIONAL: Connect any additional USB peripherals you wish to use to the Remote unit (install any required software as per the manufacturer’s instructions). A powered USB hub may be connected to the Remote unit, if additional USB ports are required. -
Page 8: Leds
NOTE: Allow up to one minute for the initial boot up of your KVM extender product. LEDs Description Solid Green: ready status. Flashing Green: the unit is booting up. Status Off: no power. Solid Green: connection between the Local and Remote extenders. Link Off: no connection between the Local and Remote extenders. -
Page 9: Troubleshooting
Troubleshooting The following table provides troubleshooting tips. The topics are arranged in the order in which they should be executed in most situations. If you are unable to resolve the problem after following these instructions, please contact Technical Support for further assistance. - Page 10 Problem Cause Solution 1. Disconnect all USB devices from the Remote Extender unit. 2. Disconnect the Local Extender unit from the computer. The host computer is not powered on. 3. Disconnect the Local Extender and Remote Extender units from The Local Extender the DC power adapters.
- Page 11 Problem Cause Solution 1. Check that the CMEDIA device is enumerated on the host computer. 2. If the CMEDIA device is enumerated as an unknown device, there is most likely a driver conflict. a. Uninstall all USB audio device drivers (e.g. sound card and webcam).
- Page 12 Problem Cause Solution 1. Disconnect the KVM extender product from the computer. 2. Connect the USB device directly to the USB port on the computer. 3. If the USB device does not operate properly, consult the user documentation for the device. 4.
-
Page 13: Pairing A Local Extender To A Remote Extender
Problem Cause Solution 1. Ensure the latest video drivers are installed. 2. The specific resolution is not Latest video drives Specific resolution listed by the monitors EDID and is are not installed or doesn’t show in the therefore not supported with the resolution is not graphics/video settings. -
Page 14: Audio
Audio The audio component of the extender uses a built-in USB Audio Device to transmit audio from the Host computer to the Remote unit. The Host computer system should detect and automatically install the audio adapter once the USB cable is connected, usually setting it as the default audio adapter for the system. -
Page 15: Specifications
Host Operating Systems • Windows 7 (32 bit & 64 bit) • Windows XP (32 bit) • Windows Vista (32 bit & 64 bit) • Linux • Mac OS X (Leopard/Snow Leopard) Peripherals • Keyboard • Mouse • Mass Storage Device • Speakers • Printer/Scanner • Web Camera • DAQs Specifications Video Signal DVI-D (digital) Local Extender Unit: 1 x 25-pin DVI-D female 1 x USB type B female 1 x RJ45 Ethernet female 1 x DC Power Connectors Remote Extender Unit:... -
Page 16: Specifications Continued
Specifications Continued Maximum Video 1680 x 1050 Resolution Maximum Data Transfer USB 2.0: 480Mbps Rate Audio Support Yes (via built-in USB audio adapter) DDC Support Local Extender Unit: 5VDC, 3000mA, center positive Power Adapter Remote Extender Unit: 24VDC, 1000mA, center positive ESD Protection 4kV Contact, 8kV Air Operating Temperature... -
Page 17: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 18 Instruction Manual...
- Page 19 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
