Instruction Manual
DVI USB KVM Console Extender with
USB 2.0 and Audio - 500m
SV565UTPDUA
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 03/01/2012
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com SV565UTPDUA
Summary of Contents for StarTech.com SV565UTPDUA
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 03/01/2012...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Introduction ....................1 Packaging Contents ..........................1 System Requirements ..........................1 Connecting Your KVM Extender ............2 Preparing Your Site ........................... 2 Local Unit Installation ..........................2 Installing the Remote Unit ........................2 How to Use .....................3 Audio ................................3 LEDs ................................ -
Page 4: Introduction
Introduction Packaging Contents • 1 x Local Unit • 1 x Remote Unit • 2 x Universal Power Adapter • 1 x USB cable • 1 x DVI-D cable • 1 x Instruction Manual System Requirements • USB and DVI-D enabled KVM switch or computer system • A DVI-D (digital) enabled display device (i.e. -
Page 5: Connecting Your Kvm Extender
Connecting Your KVM Extender Preparing Your Site Before you can install the product, you need to prepare your site. 1. Determine where the host computer will be located and set up the computer. 2. Determine where the console devices (mouse, keyboard, monitor) will be located and place them appropriately. -
Page 6: How To Use
5. Connect the UTP cable connection from the Local unit to the RJ45 connector on the Remote unit. If using premises cabling, connect the opposite end of the patch cable to the terminated wall outlet. 6. Connect the power adapters to the Local and Remote units. Each unit uses a specific power adapter (5VDC for Local, 24VDC for Remote), so ensure the correct power adapter is connected, otherwise damage may occur. -
Page 7: Leds
LEDs LEDs Description • Solid green indicates ready status. • Flashing green indicates the unit is Status booting up. • Off indicates no power. • Solid green indicates a connection between the Local and Remote units. Link • Off indicates no connection between the Local and Remote units. -
Page 8: Compatibility
Compatibility The product is compatible with many graphic cards, Operating Systems, and monitors. There is no guarantee that all devices are compatible with the product, as there are a number of different configurations that may impact the operation of the KVM Extender. The product complies with USB 1.1 and USB 2.0 specifications governing the design of USB devices. -
Page 9: Specifications
Specifications Video Signal DVI-D (digital) Local Unit: 1 x 25-pin DVI-D female 1 x USB type B female 1 x RJ45 Ethernet female 1 x DC Power Connectors Remote Unit: 1 x 25-pin DVI-D female 3 x USB type A female 1 x RJ45 Ethernet female 2 x 3.5mm mini-jack Audio female 1 x DC Power... - Page 10 Local Unit: 5VDC, 3000mA, center positive Power Adapter Remote Unit: 24VDC, 1000mA, center positive ESD Protection 4kV Contact, 8kV Air Operating Temperature 0°C ~ 50°C (32°F ~ 122°F) Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F) Humidity 20% ~ 80% RH Dimensions (LxWxH) 175.0mm x 112.0mm x 30.0mm Weight...
-
Page 11: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 12 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
